Model : WM1610-DT2
Item No : D1651-13 (Oscar Corner Table)
IMPORTANT NOTE :
*
PLACE ALL WOODEN PARTS ON A CLEAN AND SMOOTH SURFACE SUCH AS A RUG OR CARPET TO AVOID THE PARTS FROM
BEING SCRATCHED.
*
BEFORE YOU BEGIN, KINDLY FOLLOW THE ASSEMBLY INSTRUCTIONS STEP BY STEP.
JCBB M8 x 70mm + S/W 5/16"
+ F/W 5/16" x 22mm
A
B
ALLEN KEY M5
PART LIST
1
TABLE TOP
2
TABLE LEG
ASSEMBLY INSTRUCTIONS
6PCS
1PC
1PC
3PCS
2
B
A
COMPLETED TABLE ASSEMBLY.
1
1
2
2
2
