- Page 1 Standard Upper and Lower Body Exerciser INSTRUCTION MANUAL 10-0708...
-
Page 2: Safety Precautions
Thank you for your purchase of the Standard UBE Trainer At CanDo®, our goal is to provide high-quality and affordable products for Health, Wellness, Fitness & Active Aging. The Standard UBE Trainer can be used as an Upper Body Trainer or a Bike and will give you a versatile cardio workout while strengthening your muscles. -
Page 3: Assembly Overview
Assembly Overview: When you receive your new Standard UBE Trainer, some assembly is required. Assembly consists of attaching the support tubes, pedals/handles, and display. The following instructions explain the assembly. There are also detailed instructions on the display. Please Note: All of the parts and screws needed for assembly are already in place on the unit. -
Page 4: Exploded Drawing
EXPLODED DRAWING... -
Page 5: Parts List
PARTS LIST No. Qty Description NO. Qty Description Frame Console adjustable holder Nut trim -PU, black (with Nut-M8 M8 nut) Screw cap - M8 Screw round flat (umbrella head) -M8x70L Plastic Cover - left cover - Washer Black Plastic Cover - Right Drive shaft cover - Black Mid-circle cover - Blue... - Page 6 NOTE All of the parts and screws needed for assembly are already in place on the unit. TOOL SET: Screwdriver 1 pc 4mm Allen Key 1 pc...
- Page 7 ASSEMBLY Step 1 - Installing the front tube 1. Use carriage screws (NO.11) and place the front tube set (NO.9) to be assembled with frame (NO.1). 1. Insert two AAA batteries into the back of the Step 2 - installation of console display meter.
- Page 8 ASSEMBLY 1. Place the pedal set (NO.40) into the crank L (NO.38) Step 3 – installation of hand/pedal set by turning counterclockwise. 2. Place the pedal set (NO.41) into crank R (NO.39) by turning clockwise.
-
Page 9: Computer Instructions
COMPUTER INSTRUCTIONS 1. MAIN DISPLAY 2. CONSOLE SPECIFICATION CADENCE BAR GRAPHIC: 0 - 199 rpm per bar RPM : 0 - 199 RPM SPEED : 0 - 99 KM/H PULSE : 30 - 240 BPM Time : Count down setting range 1 - 99 Minutes Count up range 00:01 - 99:59 IMPORTANT SAFETY INSTRUCTIONS WARNING... -
Page 10: Battery Installation
Battery Installation: 1. Remove the battery cover from the back of the computer. 2. Insert 2 AAA batteries into the battery compartment and reinstall the battery cover. 3. When battery working voltage is low, the ‘Low Battery’ indicator will show up on the console display. DISPLAY WINDOW TIME “Time”... -
Page 11: Alarm Setting
rate will be automatically shown after 3 seconds if the console cannot detect the current heart rate. QUICK Start In Power Saving Mode, press any Key to bring the CONSOLE to ‘QUICK START’ active state. Power Saving Mode QUICK START Mode MODE SELECT Press ‘MODE’... - Page 12 Resetting all measured values To clear all the measured values, press and hold ‘SET’ key under the TIME Mode for 3 seconds. All the measured values for AVG SPEED, AVG PULSE, TIME, DIST, KCAL will reset to zero. TIMER Setting The TIMER displays the user’s exercise time.
-
Page 13: Troubleshooting
Press the ‘SET’ key to increase maximum heart rate limit. After setting the maximum heart rate, press the MODE key to adjust the minimum heart rate limit. PERSONAL DATA SETTING Accurate personal data will make the calories burned more accurate. Under SPEED or DISTANCE MODE, hold the ‘SET’... - Page 14 Use of any caustic cleaning solutions will void the warranty. 3. The console is NOT waterproof; only water resistant. Any excessive exposure to water will void the warranty. CanDo is a trademark of Goldberg. © 2021 FEI, all rights reserved. rev1121...
