BALA
CORNER CHAIR
PRODUCT NO. 088-0601-2
MODEL NO. YD-BALAC
ASSEMBLY INSTRUCTIONS
HAVING TROUBLE?
TOLL-FREE:
1-888 -670 -6684
IMPORTANT: Please read this manual carefully
before beginning assembly of this product.
Keep this manual for future reference.

Advertisement

loading
Need help?

Need help?

Do you have a question about the BALA YD-BALAC and is the answer not in the manual?

Questions and answers

Summary of Contents for Canvas BALA YD-BALAC

  • Page 1 BALA CORNER CHAIR PRODUCT NO. 088-0601-2 MODEL NO. YD-BALAC ASSEMBLY INSTRUCTIONS HAVING TROUBLE? TOLL-FREE: 1-888 -670 -6684 IMPORTANT: Please read this manual carefully before beginning assembly of this product. Keep this manual for future reference.
  • Page 2 We believe in the power of décor and its ability to make up the fabric of your home. CANVAS™ That’s why collections draw inspiration from Canadians and the way they live. From on-trend furniture pieces to holiday décor and all your outdoor living essentials, CANVAS™...
  • Page 3 TABLE OF CONTENTS Parts List Hardware List Step-by-step Guide Caring for Your Item Warranty WARNING! TO REDUCE THE RISK OF SERIOUS INJURY, READ THE FOLLOWING SAFETY INSTRUCTIONS BEFORE ASSEMBLING AND USING THE PRODUCT. Maximum weight limit: 250 lb (113.3 kg) per chair. Please read and understand this entire manual before attempting to assemble, operate, or install the product.
  • Page 4 PARTS LIST ITEM DESCRIPTION THUMBNAIL QUANTITY Arm panel Back panel Seat panel Left back cushion Right back cushion Seat cushion BALA CORNER CHAIR...
  • Page 5 EXPLODED PARTS BALA CORNER CHAIR...
  • Page 6 HARDWARE LIST ITEM DESCRIPTION THUMBNAIL QUANTITY M6x50 mm bolt Washer Tools D1/D2/D3 Clip BALA CORNER CHAIR...
  • Page 7 STEP-BY-STEP GUIDE STEP 1 Place the back panel onto a non-abrasive surface, such as a carpet. Insert the hook on back panel into arm panel illustrated by the picture below on the right. Fasten the arm panel to the back panel with bolts washers and nuts...
  • Page 8 STEP 2 Fasten the seat panel to the arm panel with bolts washers and nuts NOTE: Do not tighten screws all the way until you have assembled the chair. Once assembly is complete, tighten each screw. BALA CORNER CHAIR...
  • Page 9 STEP-BY-STEP GUIDE STEP 3 Fasten the seat panel to the back panel with bolts , washers and nuts . Secure all of the bolts D1, D2 using wrenches Make sure that all of the bolts have been tightened completely. BALA CORNER CHAIR...
  • Page 10 STEP 4 Turn the chair to an upright position. Place cushions onto the chair. Securing Clips Please use the clips to connect and secure each section together. Use of the clips is optional and dependent upon the user's personal preference. BALA CORNER CHAIR...
  • Page 11 CARING FOR YOUR ITEM CLEANING: OFF SEASON: WARRANTY INFORMATION 5-YEAR LIMITED WARRANTY* and a one (1) year warranty 088-0601-2 BALA CORNER CHAIR...
