D-ILA PROJECTOR
DLA-HD950/DLA-HD990
For Customer use :
Enter below the serial No. which is
located on the side of the cabinet.
Retain this information for future
reference.
Model No.
Serial No.
0809TTH-AO-AO
ENGLISH
INSTRUCTIONS
DLA-HD950
DLA-HD990
PC007182399-1
