Summary of Contents for Autel Robotics EVO II Dual 640T
- Page 1 QUICK GUIDE For EVO II Dual 640T...
-
Page 3: Table Of Contents
Contents ........... 1 1. WELCOME TO THE EVO II Dual 640T ......... 1 2. AIRCRAFT FRONT, REAR, & LEFT VIEWS ........2 3. AIRCRAFT RIGHT, TOP, & BOTTOM VIEWS ........... 4 4. FLIGHT LED INDICATORS ........... 5 5. REMOTE CONTROL ...... -
Page 4: Welcome To The Evo Ii Dual 640T
45mph, 33-minute hover time, 38-minute flight time and an operating distance of 5.6 miles. In-flight performance is just the start. The EVO II Dual 640T has a radiometric thermal sensor and it’s stabilized 3-axis camera allows you to shoot at up to 8K/25 fps, and view the live feed at up to 1080p on your mobile device or the remote control’s built-in OLED screen. -
Page 5: Aircraft Right, Top & Bottom Views
Propellers Landing Gear Motors Forward Vision System Front LED Indicators Camera Gimbal Rear Side Power Button Rear LED Indicators Rear Vision System Left Side Left Vision System SD Card Port 3. AIRCRAFT RIGHT, TOP & BOTTOM VIEWS 15 16 Right Side... - Page 6 Right Vision System Aircraft Battery Fan Exhaust USB Port Remote Control Pairing Button/Pairing Indicator Top Side Top Vision System Bottom Side Ultrasonic Sensor Downward Vision Lighting LED Downward Vision System...
-
Page 7: Flight Led Indicators
4. FLIGHT LED INDICATIONS A LED indicator is located on the end of each aircraft arm. The front LEDs will light up solid red to help you identify the direction of the aircraft's nose. The rear LEDs will display the current flight status of the aircraft. The chart below shows the meaning of each status indicator. -
Page 8: Remote Control
Calibration is failed R - Solid Light Gesture Commands R - Fast Flashing Gesture command has been received 5. REMOTE CONTROL With a 180° adjustable viewing angle Mobile Device Holder for optimum visibility Displays the flight status, warning Flight Information Panel messages and live video feed Control the orientation and movement Command Sticks... -
Page 9: Charging The Aircraft & Remote Control
Screen Navigation Dial Scrolls around the OLED screen When the mobile device is disconnected, press this button for 1 second to enter/exit the Image Screen Navigation Button Transmission screen on the remote control Takes photos. When Burst Mode is in use, several images will be taken Shutter Button with one press. -
Page 10: Installing The Autel Explorer
1) Aircraft Battery: Plug the charging connector into the battery’s charge port. 2) Remote Control: Open the protector on the USB port and plug in the provided charging cable. NOTE • Always fully charge the aircraft and remote control battery before flying. •... -
Page 11: Installing New Propellers
2) Unfold the arms and propellers IMPORTANT Ensure the aircraft is powered off before folding the arms. Fold in the rear arms and propellers first, and then the front arms. 9. INSTALLING NEW PROPELLERS The propellers come already attached to the aircraft, the following instructions only apply if you need to reinstall the propellers. -
Page 12: Preparing The Remote Control
Legend Lock Direction: Fasten the propeller by rotating it as indicated. Unlock Direction: Unfasten the propeller by rotating it as indicated. Black-coded propeller > Pairs with > Black-coded motor White-coded propeller > Pairs with > White-coded motor WARNING Power off the aircraft before attaching or detaching propellers. IMPORTANT Wear protective gloves when attaching or detaching propellers. -
Page 13: Powering Up
11. POWERING UP 1.Turn on the remote control. Press and hold power button for 2 seconds. 2. Turn on the aircraft. Press and hold the aircraft power button for 3 seconds. The current battery level will clearly displayed. 12. TAKEOFF 1. -
Page 14: Command Stick Controls(Mode 2)
13. COMMAND STICK CONTROLS(MODE 2) Left Command Stick Ascend/Descend Left Side View Left Side View Ascend Descend Upward Downward Rotate Left/Right Nose Rotates Left Nose Rotates Right Rotate Left Rotate Right Right Command Stick Forward/Backward Left Side View Left Side View Forward Backward Rear... - Page 16 2020-2021 Autel Robotics Co., Ltd. All Rights Reserved...
