Retro Antenna PA-02 Installation Instructions

www.retromanufacturing.com
7470 Commercial Way
Henderson, NV 89011

Warranty

If your product does not work properly because of defects in materials or workmanship, Retro Manufacturing, LLC (collectively referred to
as the "warrantor") will for the length of One Year, which starts with the date of original purchase ("warranty period"), at its option either
(a) repair your product with new or refurbished parts, or (b) replace it with a new or refurbished product. The decision to repair or replace
will be made by the warrantor.
To handle warranty issues, contact us at support@retrosound.com or call 702.483.2222. All returns and warranty issues must be
accompanied by a Return Authorization (RA) number along with a copy of your original purchase receipt. Once an RA number is issued,
send the product along with the original sales receipt to the address above. Any items sent to us without a RA number and copy of the
receipt will be refused.
702.483.2222
INSTALLATION INSTRUCTIONS
PA-02 / PA-04

Welcome

Thank you for purchasing a RetroAntenna power antenna. This antenna features fully automatic operation. This unique antenna allows you
®
to mount the motor separately from the antenna, which facilitates installation for vehicles with limited space. Care must be taken during the
installation to make sure that the anntena mast functions properly before finalizing the install. Please note that this antenna does not work
with antenna systems requiring a switch.
Our antenna uses a standard end designed to fit most applications. Some factory radios for 1995 and newer Fords, 1988 and newer GMs and
some imports use a unique connector at the the radio, and an adapter may be needed. Contact a local car audio shop for the correct
adapter part if one is needed.

1. Removing the Old Antenna

a) Disconnect the battery before you begin. Gain access to the underside of the fender area through the trunk, fender, splash panel, etc.
b) Remove and disassemble the old antenna and base. Retain the old base and mounting parts for your reference. In some cases you
can reuse them if you wish to keep the old look. Remove the mounting bracket, drain tube, electrical wires and antenna coaxial cable.
When removing electrical wires and the coaxial cable from the antenna, follow the wire's path to the closest connector and
disconnect. DO NOT CUT THE COAXIAL CABLE
c) Remove the old antenna from below the fender.
