- Page 1 Remote Control Pedalboard O W N E R ’ S M A N U A L...
- Page 2 Important Safety Instructions 1. Read these instructions. 2. Keep these instructions. 3. Heed all warnings. 4. Follow all instructions. 5. Do not use this apparatus near water. 6. Clean only with dry cloth. 7. Only use attachments/accessories specified by the manufacturer. 8. Refer all servicing to qualified service personnel. 9. This apparatus shall not be exposed to dripping or splashing, and no object filled with liquids, such as vases, shall be placed on the apparatus. Table of Contents Introduction ..........................3 Connection........................3 PB-1 Features ..........................4 PB-1 Specifications ........................6 PB-1 Limited Warranty ......................7 Service ............................8 Part No.
- Page 3 Introduction Connection Thank you for choosing the Mackie Hotwire The PB-1 comes with a 25-foot Cat5 Ether- PB-1 multi-function remote pedalboard for the net cable (the same cable used to connect a Hotwire VT12 professional guitar amplifier. computer to a network). Simply connect the cable between the “PEDAL”...
- Page 4 PB-1 Features Read on to learn more about each of the between the last two taps of the button. The features that you can control with the PB-1 LED above the button blinks in time with the pedalboard. delay time setting. 1.
- Page 5 need to practice this a few times to get a You can change the mode of the pedal by seamless loop, but it gets easier once you get pressing firmly all the way down on the pedal the hang of it. to activate the mode switch.
- Page 6 SERIAL NUMBER MANUFACTURING DATE PB-1 Specifications LOUD Technologies Inc. is always striving Connectors to improve our products by incorporating Amplifier: RJ45 new and improved materials, components, Pedal: 1/4" TS and manufacturing methods. Therefore, we reserve the right to change these Connecting Cable specifications at any time without notice. Cat5 Ethernet cable (straight-through “Mackie.”, “Hotwire,” and the “Running cable, not a crossover cable) Man” are registered trademarks of LOUD Technologies Inc. All other brand names Physical Dimensions and Weight mentioned are trademarks or registered Height: 3.3 in/84 mm trademarks of their respective holders, (including feet) and are hereby acknowledged. Width: 21.8 in/554 mm ©2008 LOUD Technologies Inc. Depth: 7.0 in/178 mm All Rights Reserved.
- Page 7 B. For faster processing, register online at www. ship or drop-off the unit to an authorized service mackie.com, or you may fill out and mail in the center. The return ground shipment is covered for product registration card included along with this those units deemed by us to be under warranty.
- Page 8 Non-warranty repair for Mackie products is available at a factory-authorized service center. To locate your nearest service center, visit www.mackie.com, click “Support” and select “Locate a Service Center.” Service for Mackie products living outside the United States can be obtained through local dealers or distributors.
