Mackie HDR 24 Operation Manual
24 track/24 bit, digital audio hard disk recorder and editor
Hide thumbs
Also See for HDR 24:
- Quick start manual (56 pages) ,
- Editing manual (28 pages) ,
- Hook-up manual (9 pages)
Related Manuals for Mackie HDR 24
Summary of Contents for Mackie HDR 24
-
Page 1: Operation Guide
HDR 24 HDR 24 HDR 24 HDR 24 HDR 24/96 Operation Guide 24 TRACK/24 BIT, DIGITAL AUDIO HARD DISK RECORDER AND EDITOR... -
Page 2: Important Safety Instructions
13. Power Precaution — Unplug the HDR 24/96 during lightning storms or The exclamation point within an equilateral triangle is intended to when unused for long periods of time. Note that this Mackie product is not alert the user of the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance. -
Page 3: Table Of Contents
Autopunch ------------------------------------ 46 Footswitch Operation ---------------------- 47 Delete Last ------------------------------------ 48 Manual Part No. 820-225-00 Rev. C1 10/02 Saving Projects --------------------------------48 © 2002 Mackie Designs Inc. All rights reserved Project Backup / Restore ------------------ 49 Printed in the U.S.A. Operation Guide... -
Page 4: Introduction
1. If you collect ten HDR24/96 boxes, Greg will come over for dinner (this offer does not apply to dealers or distributors). In the unlikely event that you should need to send the HDR24/96 back to Mackie for service, please use the shipping box it came in. This box has been specially designed to minimize damage to the HDR24/96 during shipping, so that it won’t... -
Page 5: Conventions
Conventions The HDR24/96 Operation Guide uses the following conventions to help you find information quickly: Text Conventions a) Keyboard Keys (example: SHIFT) b) Keyboard keys you hold at same time (example: CTRL+SHIFT+6) c) File or folder names (example: C:\HDR Projects\Ode To Masters\Ode To Masters.hdr) d) Software or hardware controls (example: Punch) e) Proper names of objects in GUI or front/rear panel (example: Transport) -
Page 6: Overview
• Interfaces with any analog or digital console. The HDR24/96 uses the same I/O cards as the Mackie Digital 8•Bus console: the AIO•8 (24-bit analog A/D and D/A), DIO•8 (TDIF/ADAT Optical), PDI•8 (AES/EBU), and low-cost OPT•8 (ADAT Optical). -
Page 7: Setup & Configuration
Of course, there’s more to a studio than a recorder and some musicians. At a minimum, you’ll need the following to make the HDR24/96 feel at home: • Three Mackie 8-channel I/O (input/output) cards. • A console with a minimum of 24 tape sends (buses or direct outputs) and returns (line inputs or monitor returns). -
Page 8: I/O Cards & Cables
DB25 AES/EBU cables for mating with your console, are readily available. PDI• 8 The PDI•8 is the only Mackie I/O card that currently supports 88.2 or 96 kHz operation. At these Sample Rates the PDI•8 card runs in “double- wide” (dual-wire) mode. In double-wide mode, the PDI•8 carries four mono channels of digital I/O by transmitting two consecutive 88.2/96k samples... - Page 9 “Hookups” (page 21). Be sure to come right back here when you’re done. Note: Note: Note: Always hand tighten the thumbscrews Note: Note: at the top and bottom of all I/O cards be- fore operating the HDR 24/96. Operation Guide...
-
Page 10: Sync Card & Cables - Word Clock And Digital Synchronization
For example, if your HDR24/96 Inputs and Outputs are connected to the Tape Inputs and Outputs of a Mackie Digital 8 Bus console using TDIF, either the HDR24/96 or D8B can be the •... - Page 11 Note: Note: Note: Note: If you are using an HDR24/96 with the Mackie Digital 8•Bus console, you may need to turn on the Digital 8•Bus first. The Clock I/O on the D8B prefers not to see an active signal at its Word Clock input when it powers up.
-
Page 12: Mackie Media (Optional)
90 and • Mackie Media PROJECT drives. Both drives come complete with a plug-in tray for quick removal and a nifty storage case for shelving and transporting the drives. Trays can be purchased separately if you want to use your own UDMA IDE drives. -
Page 13: Monitor / Mouse / Keyboard (Optional)
Monitor / Mouse / Keyboard (Optional) Most of the HDR24/96 editing features require a monitor, mouse and keyboard. Here’s how to install them: 1. Connect a color SVGA monitor to the HDR24/96 Video connector. The monitor should support a 1024x768 screen resolution at a 60 Hz vertical scan rate, and for the best picture, should have at least a 17"... -
Page 14: Remote 24 / Remote 48 (Optional)
Footswitch functionality is ing an HDR24/96 assigned in the front panel System menu or the GUI General Setup window. See with the Mackie Digi- the Technical Reference Guide for more details. tal 8•Bus console,... -
Page 15: Configuration
Configuration Before starting a Project, you need to configure the HDR24/96 I/O card options and synchronization parameters. These parameters determine where the sample clock is coming from, how fast the sample clock runs, and how many bits are recorded in every sample. Some options, like sample rate and bit depth, will become “standards”... - Page 16 The input and output settings on the DIO•8 card need not be the same. For example, you can use outboard A/D converters with ADAT Optical outputs and a console with TDIF inputs without problems. Just remember to correctly set up Word Clock. HDR 24/96...
- Page 17 PDI•8 Card The PDI•8 card options include sample rate conversion for each stereo AES/EBU input, and status bit control (pro/consumer mode) for each output. When a PDI•8 card is first installed, its default settings are for sample rate conversion Off, and channel status bits set to indicate the Pro (AES/EBU) format.
- Page 18 (e.g., from 44.1k to 48k), or when no other means exist to establish clock synchronization with the device(s). See the Technical Ref- erence Guide for details. HDR 24/96...
