- Page 1 PIVOT 3U WHOLE ROOM CIRCULATOR OWNER’S GUIDE READ AND SAVE THESE INSTRUCTIONS vornado.com...
- Page 2 We expect this If it is not, we product to be will make it perfect. right. vornado.com 800.234.0604 help@vornado.com English...
-
Page 3: Table Of Contents
CONTENTS Important Safety Instructions ......................4 Features ............................7 Getting Started ..........................8 Controls ............................10 Cleaning ............................11 Troubleshooting ..........................13 Warranty ............................14 English... -
Page 4: Important Safety Instructions
Please keep all documents for future reference and pass these documents on, together with the product, to any future owner. See www.vornado. com/circulators-manuals to view, download and print the most current version of these instructions. - Page 5 Do not use gasoline, thinners, solvents, ammonias or other chemicals for cleaning. Refer to the CLEANING instructions provided. - Do not open appliance housing while product is plugged in. To avoid risk of shock, all service and/or repairs must be done by a Vornado Authorized Service Center. English...
- Page 6 2. Grasp the plug (not the cord) and disconnect from the outlet. 3. Risk of Fire. Replace fuse only with 2.5 Amp, 125 Volt fuse as approved by Vornado Consumer Service. For an authorized replacement fuse, please contact Vornado Consumer Service.
-
Page 7: Features
FEATURES Save energy by maximizing the performance of heating and cooling systems. When you use a Vornado Circulator, you will not have to set your summertime thermostat as low or your win- tertime thermostat as high. FINGER FRIENDLY DESIGN REMOVABLE GRILLE For easy cleaning. -
Page 8: Getting Started
GETTING STARTED BASE ASSEMBLY - DISC CHANGING Your style is uniquely yours, and the customizable base lets Pivot 3U be you. 1. Hold your PIVOT 3U upside down. 2. Twist knob (A) on bottom of base plate (B) coun- terclockwise to remove. Set knob aside. - Page 9 3U following disc changing instructions on the previous page. custom disc template (keep for future customization) TIP: Get creative with your PIVOT 3U! You NOTE: UNPLUG PRODUCT Find more printable designs at can use the mylar template to create your PRIOR TO CUSTOMIZATION vornado.com/PivotYourStyle.
-
Page 10: Controls
CONTROLS POWER ON/OFF Select High (III), Medium (II), Low (I) fan speed or power off (O) 10 English... -
Page 11: Cleaning
The excessive heat can distort the plastic. 3. To reattach - position the Front Grille so the Vornado logo in the center of the Front Grille is straight. Replace all the screws. Use the brush attachment on your house-... - Page 12 CLEANING BLADE REMOVAL Pliers recommended. WARNING: To reduce the risk of electrical shock and injury to persons, unplug the circulator before removing blade. Remove Nut 1. First, remove the nut from the shaft Clockwise by turning the nut clockwise to loosen.
-
Page 13: Troubleshooting
Under certain conditions, it is possible for a reset GFCI (Ground Fault Circuit Interrupter) outlet to trip when the user is changing speeds on a Vornado circulator. In this event, change to an outlet that is not connected to a GFCI device. It could also indicate a weak or defective GFCI outlet. -
Page 14: Warranty
Vornado for warranty service. To file a contactless warranty claim, visit vornado.com/contact-us. After receiving the RA form, ship your Product to: Vornado Air LLC Attn: Warranty & Repair 415 East 13th Street Andover, KS 67002. For your convenience, please have your model number and serial number when contacting Vornado with service inquiries. - Page 15 The contents of this manual may differ slightly from the actual product. Observe any additional supplements. © 2021 Vornado Air LLC Andover, KS 67002 Specifications subject to change without notice. Vornado® is a trademark owned by Vornado Air LLC.
- Page 16 Vornado Air, LLC 415 East 13th Street, Andover, Kansas 67002 800.234.0604 | vornado.com CL3-0904 R-, V00...
