Page 33: Table Of Contents
Contents Introduction Table of the technical characteristics Registration Important Safety Instruction Identification of Parts Installation Climatic class Installation Starting Set stoppers Operation Display Panel for Temperature Control Refrigerator Freezer Function Super/Express Freezer Vacation Memory feature Door Alarm Child Lock Ice Making Defrosting Water Dispenser Suggestion On... - Page 34 Introduction N ote Technical characteristics of the refrigerator can be changed...
-
Page 35: Registration
Introduction Registration The model, serial number and production date are found on the outer side of this unit. This number is unique to this unit and not available to others. You should record requested information here and retain this guide as a permanent record of your purchase. Staple your receipt here. - Page 36 Introduction This fridge-freezer must be properly installed and WARNING! located in accordance with the Installation Instruction before it is used. Do not disassemble, repair or alter the appliance. It may cause fire or abnormal operations, which way lead to injury. To reduce the risk of fire, electric shock, or injury to persons when using your product, basic safety precautions should be followed.
- Page 37 Introduction Do not pull out the cord or touch the power plug with wet hands. It may cause electric shock Remove water or dust from the power plug and insert it with the ends of the pins securely connected. Dust, water or unstable connection Make sure of grounding.
- Page 38 Introduction Do not install the fridge-freezer in the wet place or the place which water or rain splashes. Deterioration of insulation of electric Do not use or store inflammable materials ether, benzene, alcohol, medicine, LP gas, spray or cosmetics near orin the fridge-freezer.
- Page 39 Introduction Use the submerged fridge-freezer after checking it. When gas is leaked, do not touch the fridge-freezer or the outlet and ventilate the room immediately. friendly refrigerant, even a small its When the gas is leaked by the severe damage during delivering,installing or For further operation, contact the service center Do not spray water at the outside...
- Page 40 Introduction When any strange smell or smoke is detected from the fridge-freezer, Service center disconnect the power plug immediately and contact to the service center. Do not allow any person except the qualified engineer to disassemble, repairor alter the fridge-freezer. It may cause injury, electric shock Do not use the fridge-freezer for non-domestic purpose (storing...
- Page 41 Introduction Violating this direction may cause injury or damage CAUTION! house or furniture. Always be careful, please. When you want to dispose the fridge-freezer, contact to the down-block office. Down-block office The refrigerant and insulation blowing gas used in the appliance require special of the pipes on the back of the appliances Do not touch food or containers at the freezer with wet hands.
- Page 42 Introduction This appliance is not intended for use by persons CAUTION! (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety Children should be supervised to ensure that they do not play with the appliance...
-
Page 43: Identification Of Parts
Introduction Identification of Parts with dispenser Models: GA-F3*9B*QA; GA-F4*9B*QA Dairy Corner, movable (Optional) Removable Door Basket Glass Shelf Lamp Multi-air Flow Duct Tray Egg (1 or 2) Tray Meat (Optional) Refrigerator Water Tank Temperature Control Vegetable Drawer Handle 2L Bottle Door Basket Tray Ice Freezer... - Page 44 Introduction Identification of Parts Models: GA-B3*9 GA-B3*9TG** ; GA-B3*9P*CA; GA-B4*9B*QA; GA-B3*9U*CA; GA-B4*9P*QA; GA-B3*9B*QA; GA-B4*9U*QA; GA-B3*9P*QA; GA-B4*9U*CA; GA-B3*9U*QA; GA-B4*9TG** Dairy Corner, movable Display Board (Optional) (Optional) Rotatable Removable Door Basket Glass Shelf Lamp Multi-air Flow Duct Tray Egg (1 or 2) Tray Meat (Optional) Refrigerator...
-
Page 45: Installation
Installation Climatic class The appliance is designed to operate in a limited range of ambient temperature, depend on climatic zones. You are not allow to go for any lower, either from the top of the range. Climatic class of your appliance marked on the Label specification with technical description in inner side of the refrigeration compartment. -
Page 46: Set Stoppers
Installation Set stoppers Front Back picture 1 Push 2 (Stopper) to the part of 1 until the end. picture 2 After attaching 2 , push the refrigerator to the end of the wall. This part must be installed for efficiency of WARNING! refrigerator. -
Page 47: Operation Display Panel For Temperature Control
Operation Temperature Control Refrigerator If you want an inside temperature slightly less cold or colder, turn the TEMP. CONTROL When the surrounding temperature is low, Display Panel For Temperature Control GA-B3*9B*QA; GA-B3*9P*QA;GA-B3*9U*QA GA-F3*9B*QA; GA-F4*9B*QA GA-B4*9B*QA; GA-B4*9P*QA;GA-B4*9U*QA LED (88) LED (BAR) Total No Frost Total No Frost GA-B3*9TG**;... -
Page 48: Freezer
Operation < Interior Type > < LED 88 Type > Models: FRZ. TEMP. SUPER FRZ./VACATION GA-B3*9 GA-B3*9U*CA; GA-B3*9P*CA; GA-B4*9U*CA Temperature adjustment button Super Freezer Button/ for freezer compartment Vacation Button Freezer < Exterior Type > < LED 88 Type > Models: GA-F3*9B*QA;... -
Page 49: Function
Operation Note The actual inner temperature varies depending on the food status, as the indicated setting temperature is a target temperature, not actual temperature Please adjust temperature as above after using Function This function is used when you want to freeze the Super/Express Freezer once, and then the quick freezer operation starts with... -
Page 50: Memory Feature
Operation < Exterior Type > Models: GA-F3*9B*QA; GA-F4*9B*QA; GA-B3*9B*QA; GA-B4*9B*QA; GA-B3*9P*QA; GA-B4*9P*QA; In selecting «On» In selecting «Off» GA-B3*9U*QA; GA-B4*9U*QA; Models: GA-B3*9TG**; GA-B4*9TG** In selecting «On» In selecting «Off« < Interior Type > Models: GA-B3*9 GA-B3*9U*CA; «off» GA-B3*9P*CA; GA-B4*9U*CA In selecting «On» In selecting «On»... -
Page 51: Child Lock
Operation Child Lock < Exterior Type > Models : GA-F3*9B*QA; GA-F4*9B*QA; GA-B3*9B*QA; GA-B4*9B*QA; GA-B3*9P*QA; GA-B4*9P*QA; In selecting In selecting GA-B3*9U*QA; GA-B4*9U*QA; «Child Lock On» «Child Lock Off» Models : GA-B3*9TG**; GA-B4*9TG** In selecting In selecting «Child Lock On» «Child Lock Off» Ice Making tray to the water level and place (depending on model) -
Page 52: Water Dispenser
Operation Water Dispenser Models: GA-F3*9B*QA; GA-F4*9B*QA Features Dispenser Pad Grille Drip Tray Handle Tank Cap Tank (Small) Cap Tank (Big) Water Tank Valve Assembly Install Please assemble the Valve Assembly after correctly Filling of Water Tank Water Tank installed at the Door, Open the CapTank (Small) * Fill water while watching a sight glass on the front of the Wa * Water up to 3,0 L... - Page 53 Suggestions on food storage Storing Food Thisprevents moisture from evaporating, and helps food doors warm up temperature in the chambers which leads Note frequently open its door or put a lot of vegetables in it, dew may form in it, which has no effect on its...
- Page 54 Suggestions on food storage Removing / To ensure good air circulation in the appliance, insert · Installing the freezer drawers freezer drawers If large quantities of food are to be stored in the freezer · the middle drawer of the freezer compartment can be taken out of the appliance and food can be stored right To remove one of the freezer drawer do the following: ·...
-
Page 55: Care And General Information
Care and Maintenance General Information Power Failure If You Move inner movable parts (shelves, drawers and door basket) securely in order to prevent any shock and fall inside vehicle during o not expose refrigerator to impact forces during load handling Anti-Condensation Anti-Condensation Pipe Pipe... -
Page 56: Lamp Replacement
Care and Maintenance Lamp Replacement driver in the underside of the lamp The new lamp should have same WARNING! Remove the shelf from refrigerator, at first – lift up it (1), Remove/Install shelf of the shelf, the damages of inner surfaces of refrigerator front side of the shelf at the angle (3) and then insert... -
Page 57: Removing/Installing Bottom Drawer
Care and Maintenance Removing/Installing To remove the bottom drawer from the refrigerator do bottom drawer the following: of refrigerator 1) Remove the lower basket from the door by lifting it up; 2) Pull the drawer until it stops and slightly lifting it up pull it to take it out;... -
Page 58: Cleaning
Care and Maintenance Cleaning Before Cleaning Be sure to unplug Exterior Interior As above Grille and Drip Remove the Grille, wipe moisture out around the Door Tray Exterior Dispenser Wipe moisture etc out outside of Dispenser and on the Water Tank rinse the inside/outside part of the Water Tank by Cap Tank Clean and fully rinse the Cap Tank (Big... -
Page 59: Trouble Shooting Trouble Shooting
Trouble Shooting Before calling for service, check this list or call in Support service of clients. It may save your time and expense. This list includes common occurrences that are not the result of defective workmanship or materials in this appliance. Problem Possible Causes Fridge-Freezer... -
Page 60: Disposal Of Your Old Appliance
Note For more information about refrigerator service and use, you can find at the official site of LG at «Frequently Asked Questions» (www.lg.com/ru/refhelp Disposal of your old appliance product it means the product is covered by the Europe an... -
Page 61: To Reverse The Doors
To Reverse the Doors Precaution Before reversing the door, first of all,you should take out food and accessories likeshelves or trays which are not fixed Use Torque Wrench or Spanner of 10 mm to fix or remove the bolt 1. Only for models with exterior door handles How to Reverse the Door To remove door handle... - Page 62 7. For all models Unscrew bolts of the middle hinge , rise up Take off cap cover After unscrewing the screws connecting the cover Unscrew bolts of lower hinge rotating it by opposite Unscrew the bolts , which is fixing lower hinge bolt on the case of the refrigerator Unscrew the screw on the bottom of the case which is fixated support...
