Service Manual
Color Television
CHASSIS : CN-220N
Model : DTQ - 20D5FSN / FSPN
SPECIFICATIONS
MODEL
ITEM
TV STANDARD
POWER INPUT
POWER CONSUMPTION
TUNING SYSTEM
TUNING RANGES
SOUND OUTPUT
SPEAKER
ANTENNA INPUT
IMPEDANCE
AUXILIARY INPUT
TERMINAL
INTERMEDIATE
FREQUENCIES
REMOTE CONTROL
SPECIAL FUNCTIONS
DAEWOO ELECTRONICS CO., LTD
http : //svc.dwe.co.kr
S/M No. : TCN220NTEF1
DTQ - 20D4SSPS / SSFN / SCN
DTQ - 20D4ASN / ASPN / SSN / SSPN
DTQ - 14D4SSN / SSPN / SSFN
DTQ-20D5FSN
DTQ-20D5FSPN
NTSC-M
120V 60HZ
220V 60HZ
84W
Frequency Synthesizer (FS) Tuning System
VHF : 2 ~ 13 (12)
UHF : 14 ~ 69 (56)
A~W, A- 5 ~ A-1, W + 1 ~ W + 84
5W + 5W
8 ohm 5W x 2EA
75 ohm Unbalanced
Front : Video, Audio, Earphone
Rear: Video, Audio, (R,L)
Picture IF Carrier Frequency : 45.75 MHZ
Sound IF Carrier Frequency : 41.25 MHZ
Color Sub-Carrer Frequency : 3.579545 MHZ
R - 40
AV only PIP
ICON MENU TYPE
STEREO / SAP
3 - Language OSD
with Caption
20D4SSPS
220V 60HZ
ICON MENU TYPE
STEREO / SAP
3 - Language OSD
with Caption
Apr. 2002
