Service Manual
Color Television
CHASSIS : CN-001N
Model :
DTQ-14V1FCN/20V1FCN
DTQ-14V5FCN/20V4FCN
DTQ-14J4FCGN/FCCN
DTQ-14V1SCN/15U5SC
DTQ-20U1SSN/20V1SSN
DTQ-14V1FSN/20V1FSN
DTQ-14V5FSN/20V4FSN
DTQ-14V3FSN/20V3FSN
DTQ-14U1FSN/20U1FSN
DTQ-14V1FSPN/20V1FSPN
DTQ-14V5FSPN/20V4FSPN
DTQ-14U1FSPN/20U1FSPN
DTQ-14V3SSN/20V3SSN
DTQ-14V5SSPN/15U5SSPN
DTQ-14V1FCN
DTQ-14V5FCN
DAEWOO ELECTRONICS CO., LTD
http : //svc.dwe.co.kr
S/M No.:CN001N-010R1
U.S.A
Canada
Middle America
( AC 110V)
Mexico,Chile ,
Peru ( AC 220V)
DTQ-20V4FCN
DTQ-14V3FCN
N
DTQ-14U1FS
Jun. 2002
