Service Manual
Color Television
CHASSIS : CN-220B/C
Model : DTQ - 20D5FS / FSP
DTQ - 20D5FC
DTQ - 20D4AS
DTQ - 20D4ASP
SPECIFICATIONS
MODEL
DTQ-20D5FS
ITEM
TV STANDARD
NTSC-M
POWER INPUT
120V 60HZ
POWER CONSUMPTION
84W
TUNING SYSTEM
Frequency Synthesizer (FS) Tuning System
VHF : 2 ~ 13 (12)
TUNING RANGES
UHF : 14 ~ 69 (56)
A~W, A- 5 ~ A-1, W + 1 ~ W + 84
SOUND OUTPUT
5W + 5W
SPEAKER
8 ohm 5W x 2EA
ANTENNA INPUT
75 ohm Unbalanced
IMPEDANCE
AUXILIARY INPUT
Front : Video, Audio, Earphone
TERMINAL
Rear: Video, Audio, (R,L)
Picture IF Carrier Frequency : 45.75 MHZ
INTERMEDIATE
Sound IF Carrier Frequency : 41.25 MHZ
FREQUENCIES
Color Sub-Carrer Frequency : 3.579545 MHZ
REMOTE CONTROL
R - 40
AV only PIP
ICON MENU TYPE
SPECIAL FUNCTIONS
STEREO / SAP
3 - Language OSD
with Caption
DAEWOO ELECTRONICS CO., LTD
http : //svc.dwe.co.kr
S/M No. : TCN220NTEF0
DTQ-20D5FSP
20D5FC
120V 60HZ
220V 60HZ
JUL. 2000
Advertisement
Table of Contents
Related Manuals for Daewoo DTQ - 20D5FS
Summary of Contents for Daewoo DTQ - 20D5FS
-
Page 1: Service Manual
S/M No. : TCN220NTEF0 Service Manual Color Television CHASSIS : CN-220B/C Model : DTQ - 20D5FS / FSP DTQ - 20D5FC DTQ - 20D4AS DTQ - 20D4ASP SPECIFICATIONS MODEL DTQ-20D5FS DTQ-20D5FSP 20D5FC ITEM TV STANDARD NTSC-M 120V 60HZ POWER INPUT... -
Page 2: Circuit Block Diagram
CIRCUIT BLOCK DIAGRAM... -
Page 4: Exploded View
EXPLODED VIEW... - Page 5 EXPLODED VIEW...
-
Page 6: Service Parts List
SERVICE PARTS LIST is a recommendable part for stock. Caution is safety component, so it must be used the same component. PART NAME PART DESCRIPTION REMARK PART NAME PART DESCRIPTION REMARK ZZ100 TRANSMITTER REMOCON R-40C03 10000 D807 DIODE RGP30J 10000 ZZ110 ACCESSORY AS DTQ-20D5FS 10000... - Page 7 SERVICE PARTS LIST PART NAME PART DESCRIPTION REMARK PART NAME PART DESCRIPTION REMARK Z501 FILTER CERA TPS-4.5MB TRAP (TAPPING) 10000 CC756 C CHIP CERA 50V CH 220PF J 2012 10000 ZZ200 PCB CHIP MOUNT B AS DTQ-20D5FS 10000 CC757 C CHIP CERA 50V X7R 0.033MF K 2012 10000 CC151 C CHIP CERA...
- Page 8 SERVICE PARTS LIST PART NAME PART DESCRIPTION REMARK PART NAME PART DESCRIPTION REMARK RC509 R CHIP 1/10 1K OHM J 2012 10000 RC751 R CHIP 1/10 470 OHM J 2012 10000 RC510 R CHIP 1/10 390 OHM J 2012 10000 RC752 R CHIP 1/10 470 OHM J 2012 10000...
- Page 9 SERVICE PARTS LIST PART NAME PART DESCRIPTION REMARK PART NAME PART DESCRIPTION REMARK C670 C ELECTRO 16V RSS 470MF (10X12.5)TP 10000 C107 C ELECTRO 50V RSS 0.22MF (5X11) TP 10000 C681 C ELECTRO 25V RUS 2200MF (16X25) TP 10000 C201 C ELECTRO 16V RSS 220MF (8X11.5) TP 10000...
- Page 10 SERVICE PARTS LIST PART NAME PART DESCRIPTION REMARK PART NAME PART DESCRIPTION REMARK C705 C ELECTRO 50V RSS 3.3MF (5X11) TP 10000 SW702 SW TACT SKHV17910A 10000 C706 C ELECTRO 16V RSS 100MF (6.3X11) TP 10000 SW703 SW TACT SKHV17910A 10000 C707 C MYLAR...
- Page 11 SERVICE PARTS LIST PART NAME PART DESCRIPTION REMARK PART NAME PART DESCRIPTION REMARK J023 WIRE COPPER AWG22 1/0.65 TIN COATING J524 WIRE COPPER AWG22 1/0.65 TIN COATING J024 WIRE COPPER AWG22 1/0.65 TIN COATING J525 WIRE COPPER AWG22 1/0.65 TIN COATING J025 WIRE COPPER AWG22 1/0.65 TIN COATING...
- Page 12 SERVICE PARTS LIST PART NAME PART DESCRIPTION REMARK J804 WIRE COPPER AWG22 1/0.65 TIN COATING J805 WIRE COPPER AWG22 1/0.65 TIN COATING J807 WIRE COPPER AWG22 1/0.65 TIN COATING J808 WIRE COPPER AWG22 1/0.65 TIN COATING J809 WIRE COPPER AWG22 1/0.65 TIN COATING J810 WIRE COPPER AWG22 1/0.65 TIN COATING...
- Page 13 DIFFENENT PARTS LIST...
-
Page 14: Different Parts List
DIFFERENT PARTS LIST CN-220C Different Part List DTQ-20D5FS DTQ-20D4AS DTQ-20D4ASP LOC PART NAME PART CODE PART DESC. PART CODE PART DESC. PART CODE PART DESC. C201 C ELECTRO CEXF1C221V 16V RSS 220MF (8X11.5) TP C202 C ELECTRO CEXF1H100V 50V RSS 10MF (5X11) TP C203 C ELECTRO CEXF1H109V 50V RSS 1MF (5X11) TP C220 C ELECTRO... - Page 15 DIFFERENT PARTS LIST CC217 C CHIP CERA HCFK474ZCA Y5V 50V 0.47MF Z 2012 CC220 C CHIP CERA HCBK103KCA 50V X7R 0.01MF K 2012 CC501 C CHIP CERA HCQK470JCA 50V CH 47PF J 2012 CC502 C CHIP CERA HCQK200JCA 50V CH 20PF J 2012 CC650 C CHIP CERA HCFK104ZCA 50V Y5V 0.1MF Z 2012 CC651 C CHIP CERA...
- Page 16 DIFFERENT PARTS LIST J551 WIRE COPPER 85801065GY AWG22 1/0.65 TIN COATING J556 WIRE COPPER 85801065GY AWG22 1/0.65 TIN COATING J606 C CERA SEMI CBZF1H104Z 50V F 0.1MF Z J611 WIRE COPPER 85801065GY AWG22 1/0.65 TIN COATING AWG22 1/0.65 TIN J612 WIRE COPPER 85801065GY COATING J613 WIRE COPPER...
- Page 17 DIFFERENT PARTS LIST R651 R CARBON FILM RD-2Z121J- 1/2 120 OHM J R680 R CARBON FILM RD-4Z201J- 1/4 200 OHM J 7W 3.3 OHM J R801 R CEMENT RX07C229JF 7W 2.2 0HM J 15MM 4P RX07C339JF 15MM 4P R802 R CARBON FILM RD-4Z394J- 1/4 390K OHM J RD-4Z514J-...
- Page 18 DIFFERENT PARTS LIST RCA12 R CHIP HRFT101JCA 1/10 100 OHM J 2012 RCA13 R CHIP HRFT224JCA 1/10 220K OHM J 2012 1/10 0 OHM 2012 RCA14 R CHIP HRFT914JCA 1/10 910KOHM J 2012 HRFT000-CA RCA18 R CHIP HRFT473JCA 1/10 47K OHM J 2012 RCA19 R CHIP HRFT102JCA 1/10 1K OHM J 2012 RCA20 R CHIP...
- Page 19 DAEWOO ELECTRONICS CO., LTD 686, AHYEON-DONG MAPO-GU SEOUL, KOREA C.P.O. BOX 8003 SEOUL, KOREA TELEX : DWELEC K28177-8 CABLE : “ DAEWOOELEC” E-mail : leesk@web.dwe.co.kr TEL : 82-2-360-7802 FAX : 82-2-360-7877...
