OWNER'S
OWNER'S
MANUAL
MANUAL
Remote Control
Allows remote control
operation of basic
thermostat functions
Unique 'Warmer & Cooler'
commands
Compatible with thermostat models:
33CS450-01, 33CS420-01 &
33CS400-01
for a complete list contact Carrier
Complete Control from
Carrier Corporation - 01/06 - Patents Pending
P/N
P/N 33CSIRRCVR-01
33CSIRRCVR-01
Thermostat
Thermostat
Remote Control
& Receiver
& Receiver
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Carrier 33CSIRRCVR-01
Summary of Contents for Carrier 33CSIRRCVR-01
- Page 1 Allows remote control operation of basic thermostat functions Unique ‘Warmer & Cooler’ commands Compatible with thermostat models: 33CS450-01, 33CS420-01 & 33CS400-01 for a complete list contact Carrier Complete Control from Carrier Corporation - 01/06 - Patents Pending P/N 33CSIRRCVR-01 33CSIRRCVR-01...
- Page 2 The Warmer and Cooler buttons use a ‘fuzzy logic’ algorithm to decide whether to turn the heat or cool on or off. The Warmer or Cooler operational control sequence varies depending on whether the thermostat is set to be a MANUAL or an AUTO changeover thermostat. Page 2...
- Page 3 - cooling system will operate as outlined in pages 4 through 8. If the thermostat was off prior to a Warmer or Cooler button press, the system will turn on in the last mode (Auto or Manual changeover) of operation prior to pressing Off.
- Page 4 (button press) through the remote control and the heater is not running, the set point will be raised above the room temperature to start the heater operation. This occurs even if the thermostat was Off. When the thermostat receives a Warmer command and the heater is running, the set point will be raised 2 degrees above the present set point.
- Page 5 Warmer & Cooler Commands in Manual Changeover If the thermostat is configured for Manual Heat/Cool changeover: COOLER button press while in Cool or Off mode: When the thermostat receives a Cooler command (button press) through the remote control and the...
- Page 6 (button press) and the air conditioner is running, the set points will be raised so that the Cool set point is the same as the present room temperature which will then turn off the air conditioner. The thermostat will not accept another Warmer button press for 10 seconds.
- Page 7 (button press) and the heater is running, the set points will be lowered so that the Heat set point is the same as the present room temperature which will then turn off the heater. The thermostat will not accept another Cooler button press for 10 seconds. Page 7...
- Page 8 The following 3 examples illustrate operation when the thermostat is Off. Example #1 The thermostat was turned off the prior day while in Auto changeover mode. The following will occur if the Warmer button is pressed while the thermostat is off: The thermostat changes from Off to Auto.
- Page 9 Accessory release button Accessory jack located on thermostat bottom To connect the IR Receiver to the thermostat; insert the IR receiver plug into the accessory Jack of the thermostat. The receiver will ‘lock’ into the ventilation slots of the thermostat.
- Page 10 Remote Control Battery Replacement Front View Rear View Battery Door Replace battery with CR 2025 or equivalent. Page 10...
-
Page 11: Warranty
Warranty One-Year Warranty - This Product is warranted to be free from defects in material and workmanship. If it appears within one year from the date of original installation, whether or not actual use begins on that date, that the product does not meet this warranty, a new or remanufactured part, at the manufacturer’s sole option to replace any defective part, will be provided without charge for the part itself provided the defective part is returned to the distributor through a qualified servicing dealer.
