Dale Tiffany TR90030 Assembly Instructions

ASSEMBLY INSTRUCTIONS:

Item No: TR90030

1. Place the base (A) on a level surface.

2. Screw lower column (B) onto base (A).

3. Screw center column (C) onto lower column (B).

4. Screw upper column (D) onto center column (C).

5. Place shade (E) over socket and tighten socket ring (F),

securing shade in place.

To connect the Reading Light

1. Remove the steel washer (H) and socket ring (I) from the

socket.

2. Place the shade (G) over the socket assembly and replace

the steel washer and socket ring to tighten the shade.

3. Insert bulb into the socket.

Recommended (1) maximum 100 WATT, Type "A" Bulb

Or (1) maximum 23Watt CFL Bulb and (1) maximum 60Watt,

Type "A" Bulb or (1) maximum 13Watt, CFL Bulb

(Bulbs not included)

Unplug lamp, wipe with a damp cloth.

Do not use abrasives

*SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.

Made in China

FOR RETURN SHIPPING PURPOSES:

PLEASE RETAIN ORIGINAL PACKAGING

TO MINIMIZE DAMAGE.

Revision – 11/07/12
