iHome IB24 User Manual

Model: iB24
Noise-Isolation, In-Ear Stereo Headphones
with iPod/iPhone Volume Control

Using Your iHome Headphones

The earpieces are marked "L" and "R". Place the "L" earpiece in
your left ear and the "R" earpiece in your right ear for proper fit
and best sound. If the earpieces are inserted incorrectly they will not fit properly in your ears and the sound
quality will not be satisfactory. When worn properly the iPod/iPhone controller will be positioned on your
right side, closer to the right ear bud.
NOTE: Your iB24 headphones are supplied with three different size silicon tips (S-M-L) for maximum
comfort and to seal out unwanted noise. The "M" (medium) size tips were installed at our factory. If you
find that the installed tips are too small or too large for your ears, you may remove them and replace them
with the larger or smaller size accessory tips. To replace the tips simply pull them off the earpieces. To
install different size tips, push them on to the earpieces and make sure they are fully seated on each
earpiece so that they do not come off when you remove the earpiece from your ear. If one of the tips
remains in your ear when you remove the headphones, remove the tip carefully and avoid pushing it further
into your ear canal. Seek medical assistance if one of the tips becomes lodged in your ear and you are
unable to remove it.
Connect the headphone plug to the headphone jack of your music player. Be sure that the plug is fully
inserted into the jack. If the plug is not fully inserted you may only hear sound from one earpiece.
To protect your hearing, always start listening with the In-Line Volume Control set to a low level and
gradually increase the volume to a comfortable listening level.
Note: The iPod/iPhone controller on the cable performs the same functions as the controls on your iPod
or iPhone. It is not necessary to make separate volume adjustments on your iPod/iPhone and on the
controller.

Using the iPod/iPhone Controller

Note: This controller is designed specifically for use with
Apple iPod and iPhone models. The controller will not
work with other MP3 players, CD players, or other audio
products that include a headphone jack.
The iPod/iPhone controller with microphone is
compatible with the following iPod and iPhone models:
iPhone 3GS – 16GB, 32GB
nd
iPod touch, 2 generation – 8GB, 16GB, 32GB
th
iPod nano, 5 generation, video camera - 8GB, 16GB
rd
iPod shuffle, 3 generation – 2GB, 4GB
iPod classic – 120GB, 160GB (2009)
To Do This
Activate voice control*
Answer or end a call
Ignore an incoming call
Answer a second incoming call
and place original call on hold
Answer a second incoming call,
and end original call
Switch between two calls
Play or Pause
Skip Track or Chapter Forward
Skip Track or Chapter Back
Increase Volume
Decrease Volume
Activate VoiceOver**
Navigate Playlists using VoiceOver**
Click to Increase
Click to Play/Pause
Click to Decrease
Action Required
Depress the Master Control for 2 seconds
Press the Master Control once to answer call
Press the Master Control again to end call
Depress the Master Control for 2 seconds
Press the Master Control once to answer second call
Press the Master Control again to return to first call
Depress the Master Control for 2 seconds
2 low tones will confirm end of original call.
Press the Master Control once to switch between calls
Press Master Control once to Play, again to Pause
Press Master Control 2 times quickly
Press Master Control 3 times quickly
Press the "+" button
Press the " - " button
Press and hold the Master Control to hear title and
artist of currently playing song
Press and hold the Master Control until tone is heard,
then release. When the name of the desired playlist is
heard, press the Master Control once to select it.
Master Control
Volume
Click x2 for Next Track
Click x3 for Previous Track
Press + Hold for iPod
Volume Shuffle VoiceOver
