Fluke Express 3 Quick Start Manual

Your Network Time Machine (NTM) comes with the software already installed and licensed.
After you have unpacked it from its shipping container, proceed as follows:
1. Install the NTM in a 19-inch rack.
2. Connect cables as shown in the figure below.
3. Turn on the AC power and wait for the server to boot up.
4. When the Windows 2008 Server login screen appears, login with username operator and
password ClearSight1.
5. Start the NTM application by selecting Start > All Programs > ClearSight Distributed >
ClearSight Network Time Machine Distributed Agent Manager.
6. After it launches, add the Agent:
! Host: localhost
! Username: Admin
! Password: (leave blank)
7. Connect to the Agent.
monitor here.
Connect these Ethernet
ports to the network(s)
from which you want to
monitor, capture frames,
and perform analysis.
Network Time Machine
Quick Start Guide: Express 3 Model
Connect a
Connect a USB
keyboard and ports to your control network for
mouse here.
Connect one of these Ethernet
remote operation of this NTM.
Connect the
power cables
here.
