BP5
OWNER/OPERATOR
MANUAL
BACKPACK SPRAYER
WARNING
This sprayer is not designed to
be used with acids of any kind,
corrosive products like caustic
soda, gasoline, materials
capable of generating heat,
hot fluids, explosive or highly
volatile products.
USE OF THESE AND OTHERS
EXPOSE USERS TO SERIOUS
INJURY AND EVEN DEATH.
WARNING
Before using our products,
please read this manual
carefully to understand the
proper use of your unit.
BP5
U
S
US-1

Advertisement

   Also See for Husqvarna BP5

   Related Manuals for Husqvarna BP5

   Summary of Contents for Husqvarna BP5

  • Page 1

    OWNER/OPERATOR MANUAL BACKPACK SPRAYER WARNING This sprayer is not designed to be used with acids of any kind, corrosive products like caustic soda, gasoline, materials capable of generating heat, hot fluids, explosive or highly volatile products. USE OF THESE AND OTHERS EXPOSE USERS TO SERIOUS INJURY AND EVEN DEATH.

  • Page 2: Table Of Contents

    Instructions contained in warnings within this manual and warning seals marked with a into consideration to prevent possible serious bodily injury, and for this reason you are requested to read all such instructions carefully and follow them without fail. Note that there may be times when warning seals peel off or become soiled and impossible to read.

  • Page 3: Parts Location

    1. Parts location 2. Specifications Type ············································································Back Pack Model Name··········································································BP5 Dimensions (LxWxH) ·························566x375x220 (22.3x14.8x8.7) mm (in) Dry Weight································································6.05 (12.1) kg (lbs) Tank Capacity···························································17.4 (4.6) litter (Gal) Max. Pressure ···················································11.76 (168) kgf/cm (psi) Working Pressure·····································1.05 – 5.6 (15 – 80) kgf/cm (psi) Sealed/O rings····································································VITON/Nytril...

  • Page 4

    4. For safe operation WORKING CONDITION 1. Refrain from operating the sprayer if you are tired, ill, or upset, or if you are under the influence of alcohol, drugs or medication. 2. To reduce the risk of injury when filling, using and/or cleaning the sprayer, always wear eye protection.

  • Page 5

    5. When replacing any other part, or any lubricant, always be sure to use only Husqvarna products or products which have been certified by Husqvarna for use with the Husqvarna product. 6. In the event that any part must be...

  • Page 6: Set Up

    5. Set up Hose clamps are not completely tight. Please tighten hose clamps prior to using. Hose clamps are left loose to extend life of gaskets and fittings. Oil cap gasket before using and lubricate weekly so the gasket will seal properly and prevent chemical leaks.

  • Page 7: Pre Operation

    6. Pre-operation Hose clamps are not completely tight. Please tighten hose clamps prior to using. Hose clamps are left loose to extend life of gaskets and fittings. Oil cap gasket before using and lubricate weekly so the gasket will seal properly and prevent chemical leaks. Oil check valve and keep breather hole clear of debris.

  • Page 8: Maintenance

    It will permanently damage pump system. In the event that any part must be replaced or any maintenance or repair work not described in this manual must be performed, please contact a Husqvarna authorized servicing dealer for assistance. SPRAYER MAINTENANCE TABLE System/Component...

  • Page 9: Limited Warranty

    THE PURCHASER SHALL NOT BE CHARGED FOR DIAGNOSTIC LABOR WHICH LEADS TO THE DETERMINATION THAT A WARRANTED PART IS DEFECTIVE, IF THE DIAGNOSTIC WORK IS PERFORMED AT THE Husqvarna DEALER. THE PURCHASER OR OWNER IS RESPONSIBLE FOR THE PERFORMANCE OF THE REQUIRED MAINTENANCE AS DEFINED BY THE MANUFACTURER IN THE OWNER/OPERATOR MANUAL.
