ABSOLUTE OZONE®
OPERATOR'S MANUAL
1A. Description
The ATLAS/TITAN/MAGNUM 30-200 are Ozone Generators that produce from 1 to 200
grams of ozone per hour respectively, with ozone concentration up to 22% by weight or
as specified in attached test report.
The ATLAS/TITAN/MAGNUM 30-200 are designed to produce ozone for variety of
applications.
1B. Specifications
Model
Ozone Production
(g/h)
Nominal Working Pressure
(psig)
Concentration
(% by weight O3)
Power Requirements
ATLAS®
30 g/h - 100g/h
20psig
5%-22%
1
20 V ~ ±3%, 50/60 Hz,
Single Phase, 5.0-9.0 A
220 V ~ ±3%, 50/60 Hz,
Single Phase, 3.5-7.0 A
Maximum Power
Consumption: 350-650W
-4-
TITAN®
30g/h - 100 g/h
20psig
5%-12%
1
20 V ~ ±3%, 50/60 Hz,
Single Phase, 5.0-9.0 A
220 V ~ ±3%, 50/60 Hz,
Single Phase, 3.5-7.0 A
Maximum Power
Consumption: 350-650W
For more information about this product visit our
website at, http://www.absoluteozone.com
Section 1
MAGNUM®
160 g/h - 200 g/h
40psig
6-12%
208/210/220/230 VAC ~
±3%, 50/60 Hz, Three Phase,
8.0-10.0 A
Maximum Power
Consumption: 1600-1700 W
