Hunter 21321 Parts Manual

Hardware
(Drawn to Scale)
x 2
x 2
x 4
x 3
x 11
x 16
x 16
x 3
Balancing
x 1
Kit
x 3
Wire
x 4
Connector
3" Wood Screw
1.5" Wood Screw
Hanger
Bracket
Assembly
Flat Washer
Canopy Screw
Screw, Blade
Blade
Iron Armature
Assembly
Blade Grommet
Screw, Blade
Assembly
Screw,
Machine, 6-32
Switch
Housing
Screw, Switch
Assembly
Housing Assembly
Fan Parts
(Not Drawn to Scale)
PARTS GUIDE
PARTS GUIDE
Using this Parts Guide, make sure all Using this Parts Guide, make sure all
parts are included in the box. parts are included in the box.
If parts are missing, DO NOT RETURN If parts are missing, DO NOT RETURN
THIS ITEM TO THE STORE, call 888-830-1326 for assistance. THIS ITEM TO THE STORE, call 888-830-1326 for assistance.
THIS PARTS GUIDE IS FOR REFERENCE ONLY. THIS PARTS GUIDE IS FOR REFERENCE ONLY.
REFER TO THE INSTALLATION MANUAL FOR FULL ASSEMBLY INSTRUCTIONS. REFER TO THE INSTALLATION MANUAL FOR FULL ASSEMBLY INSTRUCTIONS.
Model # 21321

Parts List

Asm. Dwg. # 98899-01
Finish New Bronze
Item Name Qnty Part #
Ceiling Plate 1 98900-01
Trim Ring 1 77047-01
Motor Housing 1 98902-01
Housing Cover Screw 3 74506-04
Blade Iron Set 1 98832-05
Blade Set 1 76697-29
Screw, Blade Iron Armature 11 63755-05
Switch Housing Assembly 1 99034-30
Globe/Shade 1 88703-01
Light bulb / Bulb 2 77646-04
Bottom Cap 1 65932-01
Finial 1 65397-01
Hardware Kit 1 98899-00-860
Blade Grommet
Blade Assembly Screw
Screw, Machine, 6-32
Wire Connector
Screw, Switch Housing Assembly
Dummy Terminal, Male 1 08198-01
Dummy Terminal, Female 2 08200-01
Cap, Switch Housing 1 73853-01
Plug Button 1 73854-01
Balancing Kit 1 07570-01
