Simplex 4098-9687 Installation Instructions Manual page 11

Electrical Specifications,
4098-9687
STAND ALONE
DUCT DETECTOR
1 2 3 4 5 6 7
A P -
24V TEST
LED
NOT
USED
A P -
TEST
LED
1 2 3 4 5
4098-9842
DUCT CONTROL STATION
Figure 3. Wiring the 4098-9687 Stand Alone Duct Detector for 120 VAC Operation
Continued
TB1 TB2
8 1 2 3 3
NO C NC 120
6
Notes:
1. Stand Alone Duct Detector wiring is 12 to 18 AWG.
2. Maximum allowable wire run from Stand Alone Duct Housing to Duct
Control Station is 500 feet.
3. All relay contacts rated 5 amp at 24 VDC/VAC; or 120 VAC resistive
nonpower-limited.
4. Loop ground wire around green ground screw.
5
firealarmresources.com
UNIT
BEING
CONTROLLED
TB3
4 5
GND NEU
GREEN
GROUND
SCREW
(SEE NOTE 4)
TO 120 VAC
SOURCE
FUSED
CONNECT GROUND TO
GROUND SCREW PROVIDED
ON DUCT HOUSING
SEE NOTE 3
TURNS OFF (OPEN CONTACTS)
ON ALARM OR DETECTOR REMOVAL
OR LOSS OF POWER
