Model No.WLEVSY98110
Serial No.
Write the serial number in the
space above for reference.
Serial Number Decal (under seat)
QUESTIONS?
As a manufacturer, we are
committed to providing com-
plete customer satisfaction. If
you have questions, or if there
are missing or damaged parts,
please call:
08457 089 009
Or write:
ICON Health & Fitness, Ltd.
Unit 4
Revie Road Industrial Estate
Revie Road
Beeston
Leeds, LS118JG
UK
email: csuk@iconeurope.com
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manual
for future reference.
All manuals and user guides at all-guides.com
USER'S MANUAL
Visit our website at
www.iconeurope.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the gym 1000 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Weslo gym 1000

Summary of Contents for Weslo gym 1000

  • Page 1 All manuals and user guides at all-guides.com USER'S MANUAL Model No.WLEVSY98110 Serial No. Write the serial number in the space above for reference. Serial Number Decal (under seat) QUESTIONS? As a manufacturer, we are committed to providing com- plete customer satisfaction. If you have questions, or if there are missing or damaged parts, please call:...

  • Page 2: Table Of Contents

    ORDERING REPLACEMENT PARTS ..........Back Cover Note: A PART IDENTIFICATION CHART is attached in the centre of this manual. Remove the PART IDENTIFI- CATION CHART before beginning assembly. WESLO is a registered trademark of ICON Health & Fitness, Inc.

  • Page 3: Important Precautions

    All manuals and user guides at all-guides.com IMPORTANT PRECAUTIONS WARNING: To reduce the risk of serious injury, read the following important precau- tions before using the weight system. 1. Read all instructions in this manual and in 12. Always stand on the foot plate when per- the accompanying literature before using the forming an exercise that could cause the weight system.

  • Page 4: Before You Begin

    Customer Service ® Department at 0845 089 009. To help us assist you, 1000 weight system. The GYM 1000 weight system offers a selection of weight stations designed to devel- please note the product model number and serial op every major muscle group of the body.

  • Page 5: Assembly

    All manuals and user guides at all-guides.com ASSEMBLY • As you assemble the weight system, make sure Make Things Easier for Yourself all parts are oriented as shown in the drawings. Everything in this manual is designed to ensure • For help identifying small parts, use the PART that the weight system can be assembled suc- IDENTIFICATION CHART in the centre of this cessfully by anyone.
  • Page 6 All manuals and user guides at all-guides.com 2. Refer to drawing 2a. Press a 25mm Round Inner Cap (49) into each end of the weight tube on the Weight Carriage (19). Note: Make sure the Square Slider Bushings (70) are assembled to the Weight Carriage and Weight Stop (67).
  • Page 7 All manuals and user guides at all-guides.com ARM ASSEMBLY 4. Press a 25mm Plastic Bushing (26) onto each welded spacer on the Press Frame (17). Slide the Press Frame onto the Base (4) so the Plastic Lubricate Bushings are aligned with the indicated tube in the base.
  • Page 8 All manuals and user guides at all-guides.com 7. Lubricate both axles on the Top Frame (55). Slide the Right Arm (48) onto the right axle of the Top Frame (55). Note: Be careful not to con- fuse the Right Arm with the Left Arm (47); refer to step 6 to identify the Right Arm.
  • Page 9 All manuals and user guides at all-guides.com 10. Wrap the Long Cable (58) around a “V”-Pulley (6). Attach the Pulley and a Long Cable Trap (50) to the bracket on the Front Upright (42) with an M10 x 60mm Bolt (7) and an M10 Nylon Locknut (21).
  • Page 10 All manuals and user guides at all-guides.com 14. Wrap the Long Cable (58) under a 90mm Pulley (15). Attach the Pulley and a pair of Pulley Covers (73) to the upper hole in the Long “U”- Bracket (57) with an M10 x 50mm Bolt (12) and an M10 Nylon Locknut (21).
  • Page 11 All manuals and user guides at all-guides.com 17. Locate the Short Cable (23). Route the Short Cable through the bracket on the Press Frame (17), as shown. Make sure that the Cable is routed over the crossbar. Hold a 90mm Pulley (15) inside of the bracket on Bracket the Press Frame (17).
  • Page 12 All manuals and user guides at all-guides.com 21. Attach the end of the Short Cable (23) to the Long “U”-Bracket (57) with an M8 Nylon Locknut (3) and an M8 Washer (68). Do not completely tighten the Nylon Locknut; it should be threaded onto the end of the Cable until two threads are showing above the Nylon Locknut, as shown in the inset drawing.
  • Page 13 All manuals and user guides at all-guides.com 23. Press a 38mm Square Inner Cap (32) into the Seat Frame (36). Insert the M6 x 50mm Carriage Bolt (38) into the centre hole in the Seat Plate (37). Attach the Seat Plate to the Seat (13) with two M6 x 16mm Screws (18).
  • Page 14 All manuals and user guides at all-guides.com 26. Press two 19mm Round Inner Caps (34) into the ends of both Pad Tubes (28). Insert one Pad Tube (28) into the Seat Frame (36). Slide a Foam Pad (30) onto each end of the Pad Tube.

  • Page 15: Adjustment

    All manuals and user guides at all-guides.com ADJUSTMENT The instructions below describe how each part of the weight system can be adjusted. IMPORTANT: When attaching the lat bar or nylon strap, make sure that the attachments are in the correct starting position for the exercise to be performed.
  • Page 16 All manuals and user guides at all-guides.com ATTACHING AND REMOVING THE SEAT Set the bracket on the Seat Frame (36) onto the pin on the Front Upright (42). Attach the Seat Frame to the Front Upright with the M8 x 67mm Carriage Bolt (14) and the Seat Knob (40).

  • Page 17: Weight Resistance Chart

    WEIGHT RESISTANCE CHART All manuals and user guides at all-guides.com This chart shows the approximate weight resistance at each weight station. The column labelled “WEIGHT” refers to the amount of weight, in pounds, placed on the weight carriage. The weight resistance shown for the butterfly arm station is for each butterfly arm.

  • Page 18: Troubleshooting And Maintenance

    All manuals and user guides at all-guides.com TROUBLESHOOTING AND MAINTENANCE Make sure all parts are properly tightened each time you use the weight system. Replace any worn parts immedi- ately. The weight system can be cleaned using a damp cloth and mild non-abrasive detergent. Do not use solvents. TIGHTENING THE CABLES Woven cable, the type of cable used on the weight system, can stretch slightly when it is first used.

  • Page 19: Cable Diagram

    CABLE DIAGRAM All manuals and user guides at all-guides.com The cable diagram below shows the proper routing of the Short Cable (23) and the Long Cable (58). Use the diagram to make sure that the two cables and the cable traps have been assembled correctly. If the cables have not been correctly routed, the weight system will not function properly and damage may occur.
  • Page 20 All manuals and user guides at all-guides.com NOTES...
  • Page 21 All manuals and user guides at all-guides.com NOTES...

  • Page 22: Part List

    PART LIST—Model No. WLEVSY98110 All manuals and user guides at all-guides.com R0702A Key No. Qty. Description Key No. Qty. Description M8 x 63mm Carriage Bolt M6 x 50mm Carriage Bolt M6 Nylon Locknut Nylon Strap M8 Nylon Locknut Seat Knob Base Backrest Stabiliser...

  • Page 23: Exploded Drawing

    EXPLODED DRAWING—Model No. WLEVSY98110 All manuals and user guides at all-guides.com R0702A 9 21...
  • Page 24 PART IDENTIFICATION CHART—Model No. WLEVSY98110 All manuals and user guides at all-guides.com R0702A M6 x 16mm Screw (18) M10 Washer (9) 25mm Round Cover Cap (62) M10 x 20mm Bolt (69) M8 Washer (68) M6 x 50mm Screw (24) M6 Washer (10) M10 x 45mm Bolt (71) 25mm Round Inner Cap (49) M10 x 50mm Bolt (12)
  • Page 25 All manuals and user guides at all-guides.com M6 x 63mm Screw (43) M10 x 60mm Bolt (7) M8 x 63mm Bolt (22) 50mm Square Outer Cap (51) M8 x 63mm Carriage Bolt (1) M8 x 67mm Bolt (72) M8 x 70mm Bolt (11) 50mm Square Inner Cap (27) M8 x 67mm CarriageBolt (14) M10 x 87mm Bolt (25)
  • Page 26 All manuals and user guides at all-guides.com 90mm Pulley (15) (Not shown to scale) "V"-Pulley (6) (Not shown to scale)

  • Page 27: Ordering Replacement Parts

    Fax: 0 (044) 113 387 7125 Please provide the following information when ordering replacement parts: • the MODEL NUMBER of the product (WLEVSY98110) • the NAME of the product (WESLO GYM 1000 weight system) ® • the SERIAL NUMBER of the product (see the front cover of this manual) •...
