IMPORTANT NOTICE !!
Read the enclosed instructions carefully before attempting to install this door. Pay close
attention to all warnings and important safety notices.
This manual MUST be attached to the wall in close proximity of the door.
DS-75/DS-100 MINI ROLL-UP DOORS
WINDLOAD RATED
INSTALLATION INSTRUCTIONS
©Copyright 2002 Wayne-Dalton Corp.
P/N 299013, DOC #101-0114-1 REV 00

Advertisement

loading
Need help?

Need help?

Do you have a question about the DS-75 and is the answer not in the manual?

Questions and answers

Related Manuals for Wayne-Dalton DS-75

Summary of Contents for Wayne-Dalton DS-75

  • Page 1 DS-75/DS-100 MINI ROLL-UP DOORS WINDLOAD RATED INSTALLATION INSTRUCTIONS IMPORTANT NOTICE !! Read the enclosed instructions carefully before attempting to install this door. Pay close attention to all warnings and important safety notices. This manual MUST be attached to the wall in close proximity of the door.

  • Page 2: Important Safety Notices

    IMPORTANT SAFETY NOTICES Read the enclosed instructions carefully before attempting installation. If there are any questions about any of the procedures, do not perform the work. Instead, have a qualified door agency do the installation or repairs. 1. Operate the door ONLY when it is properly adjusted and free of all obstructions. 2.
  • Page 3 Reference must be made to construction codes in your area. All Wayne-Dalton DS-75 and DS-100 Windload Rated Mini Roll-Up Doors follow the general instructions contained herein. Additional installation information for the specific door shipped is found with the packing slip and on supplementary drawings.
  • Page 4 IMPORTANT! #7 when to cut tape. No guarantee will be given by Wayne-Dalton Corp. if the door is not erected as instructed. For best operation, follow the instructions step by step. Please review all instructions thoroughly before starting installation. STEP 2 CHECK THE DOOR OPENING Verify the opening measurements with the door packing slip.
  • Page 5 STEP 3 INSTALLING MOUNTING ANGLES AND GUIDES Obtain the appropriate Bolt Line (BL) measurement from the chart below. Use opening width listed on the packing slip. Any variation between the actual opening width and the opening width listed on the packing slip is to be ignored.

  • Page 6: Step 4 Bracket Installation

    Trim the top of each wear strip at a 45° angle as shown and clip onto the appropriate leg of each guide. Be sure that trimmed edges of the wear strips end just below the flare of the guides. Install the bottom bar stops with the same 5/16- 18 x 5/8”...
  • Page 7 STEP 6 SPRING ATTACHMENT Rotate curtain assembly so that the bottom bar is at the top of the curtain roll. While holding the door from rotating, carefully stretch the spring end to the bracket to determine the bracket hole nearest to the loop in the spring end. Position the 5/16-18 x 1”...

  • Page 8: Lift Handle Installation

    STEP 8 LUBRICATE AND ADJUST THE GUIDES Lubricate the insides of guides and wearstrips with weather resistant lubricating spray. Be sure to spray lubricant over the flares at the top of each guide. Move the door up and down to check for proper operation. Adjust the guides and mounting angles if necessary to allow for proper clearance and operation.
  • Page 9 STEP 11 SLIDE BOLT LOCKS (if applicable) Install slide bolt locks, if provided, as shown. STEP 12 INSTALLATION OF TOP DRAFT STOP (if applicable) Close the door and secure it in the down position. Use a pencil mark door panel corrugation that is parallel with the bottom of the header/lintel from the outside of the opening.
  • Page 10 STEP 13 TENSION-PRO SPRING TENSION ADJUSTMENT BRACKET (if applicable) STEP #1: Install the Tension-Pro bracket on the left hand side of the curtain assembly per step #4 of this manual. Insert cotter pin through hole in the axle. Do not use large washer on the Tension-Pro bracket side axle end. STEP #2: Stretch and attach spring end to the spring holder plate of the Tension-Pro bracket using the 5/16-18 nut, washer and lock-washer.
  • Page 11 To Increase Spring Tension: Move the door to the fully opened position and place clamps on the guides to prevent possible door closing. Using a large pipe wrench, grip the tensioning hex plate and rotate the ratchet gear assembly in the direction indicated above until an audible “CLICK”...

  • Page 12: Limited Warranty

    Roll-Up Sheet Door LIMITED WARRANTY Wayne-Dalton Corp P.O. Box 67- Mt. Hope, Ohio 44660 The Manufacturer warrants the ROLL-UP SHEET DOOR and hardware fittings for a period of ONE YEAR from the time of delivery against any defects in workmanship or material. Manufacturer shall, upon notification, correct such nonconformity at its option, by repairing or replacing any defective part or parts.
