IrriGreen 2 Quick Install Manual

Hide thumbs Also See for 2:
Table of Contents

Advertisement

Quick Links

Download this manual
Quick Install Guide
v2 - 11/21

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 2 and is the answer not in the manual?

Questions and answers

Related Manuals for IrriGreen 2

Summary of Contents for IrriGreen 2

  • Page 1 Quick Install Guide v2 - 11/21...
  • Page 2 With our revolutionary all-digital sprinkler system, you use fewer, more efficient heads, that accurately water to the exact shape of your landscape.

  • Page 3: Installation Overview Diagram

    Quick Install Guide Installation Overview Diagram Click or scan for Full Quick Install video Irrigreen 1” Mainline Water Pipe...
  • Page 4 Included in Your Box: 15” FlexPipe Digital Sprinkler(s) 1” MPT to mainline tee 1 per zone, ~2000 sq. ft. Irrigreen 2 WiFi / Cloud Controller Standard: 16 Digital Zones, 12 Valve Zones Pro: 32 Digital Zones, 24 Valve Zones Controller Cable CableLok 50’...
  • Page 5 Quick Install Guide Other Items You’ll Need: 1” Elbows, 1” Tees with 1” 1” Mainline PVC connectors, end caps or Poly Pipe female pipe thread +Any other connectors and end caps needed for your yard PVC Glue Pipe Cutter Teflon Tape Recommended: 6”...
  • Page 6 Irrigreen System Requirements: Constant pressure (between 40-80 psi) Good flow (8+ gpm ) Clean water Well Systems: Water Sources with Particulates: Well Systems require a constant Any water source with particulates pressure pump or regulated constant such as sand and grit, require a 500 pressure supply, e.g.

  • Page 7: Step 1: Measure Pressure

    Connect your pressure gauge to your water spigot. Pressure: 40-80 psi Step 2: Bucket Test (Flow) Click or scan for Step 2 video Make sure you can fill a 5 gallon bucket in less than 45 seconds (8 gallons per minute).
  • Page 8 (Exact placement not critical as you can program the head to the shape of the zone.) 2. Using a tape measure, measure to the farthest corner of each zone to make sure you have enough watering range to reach every part of the zone.
  • Page 9 Quick Install Guide For Narrow Zones: Check minimum throw distance (cannot be less than 5 feet). NOTE: Heads cannot be programmed to distances less than 5 feet, to keep the riser from retracting. *For narrow zones (less than 10’ wide): •...

  • Page 10: Step 4: Controller Placement

    Step 4: Controller Placement Click or scan for Step 4 video Choose a location for your controller that is: Controller Power • Next to an outlet *You will mount the controller in a later step (Step 12). 24 VAC, 40 VA •...
  • Page 11 Quick Install Guide Step 5: Find and Tap into Your Water Line You need to find your water line (mainline) to connect Irrigreen to your water source. Where is my mainline? 2. Near Irrigation 3. Upstream Side of 1. Near a Spigot...
  • Page 12 Step 6: Trenching Click or scan for Step 6 video 1. Trench 1” pipe to sprinkler head locations. 2. Dig ~13” deep hole for head(s). Do not bury trench or heads until Step 15.
  • Page 13 Step 8: Flush out the Pipes for 3 minutes 1. Point the flexpipe outside the hole. Click or Scan for 2. Turn on the mainline to flush out. Step 8 video 3. Let water run for 3 minutes. *This step is very important! •...
  • Page 14 Step 9: Connect Sprinkler Head To Flexpipe Click or scan for Step 9 video 3/4” Elbow connects to Sprinkler: • NO Teflon Tape • NO tools • HAND TIGHT ONLY! Recommended: Use a 6” valve box next to each head for easier maintenance.
  • Page 15 “daisy chain” to the next sprinkler on the line. 1. Align arrows on connectors Sprinkler 2. Push connectors together until they bottom out Larger End Cable Smaller End Align arro...
  • Page 16 1. Align arrows on connectors 3. Place CableLok Top over connectors 2. Push connectors together until they bottom out align ridge with corresponding ridge on connector 2. Push connectors together until they bottom out align ridge with corresponding ridge on connector 1.
  • Page 17 1. Remove top bracket from controller and place it Step 12 video level on the wall. 2. Screw in the top bracket. 3. Put the controller on top bracket and slide it down in place. 4. Put screws in the two holes on bottom bracket to hold the controller box in place.
  • Page 18 Step 13: Controller Box Wiring Click or scan for Step 13 video Controller Cable: Red Wire Digital 1-8 White Wire Common Power Adapter 50 Ft. 24 Volts AC Controller Can repeat up to 8x Cable Sprinklers per line. If more sprinklers are needed, connect a new Drip/Standard line to the controller for...

  • Page 19: Step 14: App Setup

    Quick Install Guide Step 14: App Setup Click or scan for Step 14 video (Make sure you are on the site WiFi). *Be sure to allow “Location Access” for the app. Follow instructions to connect controller to home WiFi. NOTE: Turn off VPN, if any.
  • Page 20 Step 15: Check Sprinkler Connections 1. Make sure all sprinklers are connected with cables. Click or scan for Step 15 video 2. Open the Irrigreen 2 App on your device. 3. Press: 4. Press “Test 5. Press “Test All More Sprinkler Wiring”...

  • Page 21: Step 16: Calibration Setup

    Quick Install Guide Step 16: Calibration Setup 1. Open the app on your ios Device. Click or scan for Step 16 video 2. Get to the Calibration screen: 3. Press 1. Press: 2. Press Digital Recalibrate Zone 1 Zones 3. Follow on-screen instructions for Calibration.
  • Page 22 3. Press Edit 1. Press: 2. Select Zone Zones 2. Follow the on-screen instructions for Setting Watering Shape: *If you want the head to drop down and not water an area, place a point within 4 feet...
  • Page 23 Quick Install Guide Step 18: Setup a Schedule Click or scan for Follow on-screen instructions Step 18 video for Setting up Schedules:...
  • Page 24 Contact Us: (612) 238-7575 service@irrigreen.com...
