9" CIRCULAR SAW W/BLADE
ASSEMBLY AND OPERATING INSTRUCTIONS
Diagrams within this manual may not be drawn proportionally.
Due to continuing improvements, actual product may differ slightly from the product described herein.
Distributed exclusively by Harbor Freight Tools
Visit our website at: http://www.harborfreight.com
Read this material before using this product.
Failure to do so can result in serious injury.
SaVe THiS manual.
Copyright
2003 by Harbor Freight Tools
©
manual or any artwork contained herein may be reproduced in any shape or form
without the express written consent of Harbor Freight Tools.
For technical questions or replacement parts, please call 1-800-444-3353.
PROFESSIONAL
3491 Mission Oaks Blvd., Camarillo, CA 93011
47613
. All rights reserved. No portion of this
®
.
®
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Harbor Freight Tools 47613
Summary of Contents for Harbor Freight Tools 47613
- Page 1 2003 by Harbor Freight Tools © manual or any artwork contained herein may be reproduced in any shape or form without the express written consent of Harbor Freight Tools. For technical questions or replacement parts, please call 1-800-444-3353. 47613 ®...
-
Page 2: Product Specifications
Keep bystanders, children, and visitors away while operating a power tool. Distractions can cause you to lose control. Protect others in the work area from debris such as chips and sparks. Provide barriers or shields as needed. SKU 47613 PRODUCT SPECIFICATIONS 120 VAC, 60 Hz, 1380 watts, 16 peak amps... -
Page 3: Electrical Safety
Dress properly. Do not wear loose clothing or jewelry. Contain long hair. Keep your hair, clothing, and gloves away from moving parts. Loose clothes, jewelry, or long hair can be caught in moving parts. SKU 47613 ELECTRICAL SAFETY PERSONAL SAFETY... - Page 4 Check for misalignment or binding of moving parts, breakage of parts, and any other condition that may affect the tool’s operation. If damaged, have the tool serviced before using. Many accidents are caused by poorly maintained tools. SKU 47613 TOOL USE AND CARE Page 4...
-
Page 5: Specific Safety Rules
Maintain labels and nameplates on the Circular Saw. These carry impor- tant information. If unreadable or missing, contact Harbor Freight Tools for a replacement. Always wear safety impact eye goggles and heavy work gloves when using the Circular Saw. - Page 6 17. After cutting, wait for the saw blade to stop turning before setting the unit down. 18. Only use a 9” saw blade on this Circular Saw. The blade must have a speed rating of 4,000 RPM or greater. WARNING! Some dust created by power sanding, sawing, grinding, drilling, and other construction activities, contain chemicals known (to the State of California) to cause cancer, birth defects or other reproductive harm.
-
Page 7: Grounded Tools: Tools With Three Prong Plugs
Your tool must be plugged into an appropriate outlet, properly installed and grounded in accordance with all codes and ordinances. The plug and outlet should look like those in the following illustration. (See Figure A.) FIGURE A SKU 47613 GROUNDING WARNING! Page 7... -
Page 8: Double Insulated Tools: Tools With Two Prong Plugs
(See Figure C.) If you are using one extension cord for more than one tool, add the nameplate amperes and use the sum to determine the required minimum cord size. (See Figure C.) SKU 47613 FIGURE B EXTENSION CORDS Page 8... - Page 9 3.5 – 5.0 5.1 – 7.0 7.1 – 12.0 12.1 – 16.0 16.1 – 20.0 FIGURE C SKU 47613 (120 VOLT) EXTENSION CORD LENGTH Feet Feet * Based on limiting the line voltage drop to five volts at 150% of the rated amperes.
- Page 10 When unpacking, check to make sure all the parts shown in Figure C are included. If any parts are missing or broken, please call Harbor Freight Tools at the number shown on the cover of this manual as soon as possible.
- Page 11 Figure D Prepare Material Before Cutting Support large panels to minimize risk of blade pinching and saw kickback. Use the supplied Rip Guide (402) when ripping material by sliding it into the Base Assy. and tightening Wing Bold (58). See Figures F and G below.
-
Page 12: Inspection, Maintenance, And Cleaning
If desired for a straight cut, slide the Rip Guide (402) into the side of the Circular Saw and tighten with Wing Bolt (58), or clamp a straight edge to the material to guide the saw on a straight path. - Page 13 They can be cleaned using an ink eraser. Replace the Brush Caps. Installing a New Saw Blade Always use 9 inch saw blades. The saw blade speed rating must be at least 4,000 RPM. Refer to the following table for saw blade applications and types.
-
Page 14: Parts List
Gear Cover Assy. Lock Lever Carbon Brush Brush Cap Rubber Cushion Screw Screw, Socket, Hex Screw, Socket, Hex Needle Bearing Ex Ret. Ring Gear SKU 47613 Parts List Part Description Int. Ret. Ring Ball Bearing Spindle Bearing Housing Screw Screw Spring... -
Page 15: Assembly Diagram
BE UNDERTAKEN BY CERTIFIED AND LICENSED TECHNICIANS, AND NOT BY THE BUYER. THE BUYER ASSUMES ALL RISK AND LIABILITY ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL PRODUCT OR REPLACEMENT PARTS THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION OF REPLACEMENT PARTS THERETO. SKU 47613 Page 15... - Page 16 1 YeaR waRRanTY Harbor Freight Tools Co. makes every effort to assure that its products meet high quality and durability standards, and warrants to the original purchaser that this product is free from defects in materials and workmanship for the period of one year from the date of purchase (90 days if used by a professional contractor or if used as rental equipment).
