- Page 1 HK854400XB 30” Induction Cooktop...
-
Page 2: Electrical Requirements
30” (76cm) induction cooktop 208 / 230 Volt, 60Hz, 40 AMP • • Stainless steel trim AEG Cooktops are supplied with a 5’ long • DirekTouch slide design touch controls electrical cable and must be hard wired to • 4 x 21cm induction zones with 14 power levels the electrical supply. -
Page 3: Cooktop Dimensions
HK854400XB SPECIFICATIONS COOKTOP DIMENSIONS CUT-OUT DIMENSIONS • • 8/16 D: 19 ” x W: 30” D: 19 ” x W: 29 ” • • D: 501mm x W: 761mm D: 495mm x W: 750mm Specifications are subject to change without notice... -
Page 4: Underside View
HK854400XB SPECIFICATIONS SIDE VIEW INSTALLING OVER BUILT-IN OVEN • There must be a minimum of 20mm (13/16”) of space left between the bottom of the cooktop and the oven to allow air to flow. • There must be a minimum of 5mm (3/16”) of space left between the counter top and the door panel of a built-in oven / drawer. - Page 5 HK854400XB SPECIFICATIONS Specifications are subject to change without notice V1.1...
- Page 6 HK854400XB SPECIFICATIONS RECOMMENDED CABINET MINIMUM CLEARANCE * Minimum clearance from cooktop cut-out to combustible materials up to 18” (457mm) above countertop Specifications are subject to change without notice V1.1...
- Page 7 AEG Appliances are designed and manufactured to the highest standards. Each appliance is covered by a comprehensive 2-year parts and labour warranty. Refer to product warranty policy for complete terms and conditions. FOR PARTS AND SERVICE Euro-Parts & Service 39822 Belgrave Road, Belgrave, ON. N0G 1E0 1 800 678 8352 (Canada) •...
