User's Manual
HK854080XB 30" Electric Cooktop -
User's Manual

Advertisement

   Related Manuals for AEG 30" HK854080XB

   Summary of Contents for AEG 30" HK854080XB

  • Page 1

    User’s Manual HK854080XB 30” Electric Cooktop - User’s Manual...

  • Page 2: Table Of Contents

    Contents Thank you for choosing one of our high-quality products. To ensure optimal and regular performance of your appliance please read this instruction manual carefully. It will enable you to navigate all processes perfectly and most efficiently. To refer to this manual any time you need to, we recommend you to keep it in a safe place.

  • Page 3: Correct Operation

    • Product number (Prod. Nr.) ....• Serial number (Ser. Nr.) ....You find the rating plate of the appliance on its lower casing. HK854080X-B 949 593 246 00 220-240 V 50-60-Hz 58 HBD 68 A0 7,8 kW AEG-ELECTROLUX...

  • Page 4: Safety Instructions

    Installation instructions Safety instructions WARNING! You must read these! Make sure that the appliance is not damaged because of transportation. Do not connect a damaged appliance. If it is necessary, speak to the supplier. Only an authorised service technician can install, connect or repair this appliance. Use only original spare parts.

  • Page 5

    Installation instructions Assembly min. 500 mm min. 50 mm min. 50 mm +1 mm min. 25 mm min. 20 mm min. 30 mm If you use a protection box (additional accessory), the protective floor directly below the appliance is not necessary.

  • Page 6: Product Description

    Product description Product description Cooking surface layout Single cooking zone 1200 W 145/210/270 Triple cooking zone 1050/1950/2700 W Multi-purpose zone 1400/2200 W Control panel 120/180 Double cooking zone 700/1700 W Control panel layout Use the sensor fields to operate the appliance. Indicators, displays and sounds tell which functions operate.

  • Page 7: Operating Instructions

    Operating instructions sensor field function a heat setting display shows the heat setting a control bar to set the heat setting starts and stops STOP+GO starts and stops the outer ring Heat setting displays Displays show which functions operate Display Description The cooking zone is off The cooking zone operates...

  • Page 8: The Heat Setting

    Operating instructions Automatic Switch Off times Heat setting Stops after 6 hours 5 hours 4 hours 1.5 hours The heat setting Touch the control bar at the necessary heat setting. Change to the left or the right, if it is necessary. Do not release before you have a correct heat setting.

  • Page 9: Using The Timer

    Operating instructions Using the Timer Count Down Timer Use the Count Down Timer to set how long the cooking zone operates for one cooking session. Set the Count Down Timer after the selection of the cooking zone. You can set the heat setting before or after you set the timer. •...

  • Page 10: The Child Safety Device

    Helpful hints and tips The Timer still operates. Touch the symbol to switch off this function. The heat setting that you set before comes When you switch off the appliance, you also switch off this function. The child safety device This function prevents an accidental operation of the hob.

  • Page 11: Energy Saving

    Helpful hints and tips Energy saving • If possible, always put the lids on the cookware. • Put cookware on a cooking zone before you start it. • Stop the cooking zones before the end of the cooking time to use residual heat. •...

  • Page 12: Care And Cleaning

    Care and cleaning Care and cleaning Clean the appliance after each use. Always use cookware with clean bottom. WARNING! Sharp objects and abrasive cleaning agents will damage the appliance. For your safety, do not clean the appliance with steam blasters or high-pressure cleaners. Scratches or dark stains on the glass ceramic have no effect on how the appliance operates.

  • Page 13: Environment Concerns

    Environment concerns Problem Possible cause and remedy The automatic switch off operates. Stop the appliance and start comes on it again. There is an error in the appliance. and number come on. Disconnect the appliance from the electrical supply for some time.

  • Page 14

    Canada Tel 905-829.3980 Fax 905-829.3985 email marketing@euro-line-appliances.com For Service & Spares: EURO-PARTS 1.800.678.8352 Important: Please record details of your purchase below and mail or fax to AEG -----------------------------------------------------------------------------------------cut along line ------------------------------------------------------------------------------------ Name: TEL No Address: City : State: Zip Code:...

  • Page 15

    AEG appliances are imported and distributed in North America by Euro-Line Appliances Inc. For more information visit www.euro-line-appliances.com / www.elawest.com 871 Cranberry Court 2912 West 4th Ave Oakville, ON L6L 6J7 Vancouver, BC V6K 1R2 Canada Canada Toll Free: 1.800.421.6332 Toll Free: 1.855.352-9378...
