Oct. 2019
Table of Contents
Cautionary Notes ..............................................................2
Specifications .....................................................................3
Location of Control (Top) ................................................4
Location of Control Parts List (Top)...............................4
Location of Control (Rear) ...............................................5
Location of Control Parts List (Rear)..............................5
Exploded View (Cabinet).................................................6
Exploded View Parts List (Cabinet) ...............................7
Disassembly Procedure ....................................................7
Note on Disassembly ........................................................7
Important Notes on Assembly ........................................7
Plain View (Cabinet: 1).....................................................8
Plain View (Cabinet: 2).....................................................9
Exploded View (Chassis) ...............................................10
Exploded View Parts List (Chassis)..............................11
Plain View (Chassis: 1) ...................................................12
Plain View (Chassis: 2) ...................................................13
Copyright © 2019 Roland Corporation
All rights reserved. No part of this publication may be reproduced in any form without the written permission
of Roland Corporation.
Wiring Diagram...............................................................14
Block Diagram .................................................................16
Parts List ...........................................................................18
Verifying the Version......................................................21
Data Backup and Restore Operations ..........................21
System Update Procedure..............................................21
Performing a Factory Reset............................................21
Test Mode .........................................................................22
Circuit Board (Main Board) ...........................................28
Circuit Diagram (Main Board: 1/3)..............................30
Circuit Diagram (Main Board: 2/3)..............................32
Circuit Diagram (Main Board: 3/3)..............................34
Circuit Board (Panel, Amp, Input, Fuse Board)..........36
Circuit Diagram (Panel Board)......................................38
Circuit Diagram (Amp Board).......................................40
Circuit Diagram (Input Board)......................................41
Circuit Diagram (Fuse Board) .......................................41
17057241E0
SERVICE NOTES
Issued by RJA
KTN-50_2
CC-KWS
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Roland BOSS KATANA-50 Mk II
Summary of Contents for Roland BOSS KATANA-50 Mk II
-
Page 1: Table Of Contents
Circuit Diagram (Input Board)........41 Plain View (Chassis: 2) ...........13 Circuit Diagram (Fuse Board) ........41 Copyright © 2019 Roland Corporation All rights reserved. No part of this publication may be reproduced in any form without the written permission of Roland Corporation. -
Page 2: Cautionary Notes
• Because reissuance is restricted. • Because the part is made to order (at current market price). • Because it is carried in electronic data on the Roland web site. • Because it is a package or an accessory irrelevant to the function maintenance of the main body. -
Page 3: Specifications
TREBLE knob MULTI EFFECT Options (sold separately) BOOSTER button Footswitch: BOSS FS-5L, BOSS FS-6, BOSS FS-7 MOD button Expression pedal: Roland EV-5, BOSS EV-30, BOSS FV-500L, BOSS FV-500H FX button DELAY button REVERB button TAP button BOOSTER knob * 0 dBu = 0.775 Vrms MOD knob * Printed matters will not be supplied after the end of the production. -
Page 4: Location Of Control (Top)
Oct. 2019 KTN-50_2 Location of Control (Top) fig.panel-top.eps Location of Control Parts List (Top) Part Code Part Name Description Q’ty 5100052217 C-KEYTOP 01780101 TACT SWITCH SKQKABD010 5100003359 LED(RED) L-34ID (153-L-34IDSLLF) 5100044430 LED SPACER LEDH-1.5 5100052214 R-KNOB INDEX 5100067364 ROTARY POTENTIOMETER RV09BDF-40E1-15F-0B10K-003 ******** VR NUT (M9) -
Page 5: Location Of Control (Rear)
Oct. 2019 KTN-50_2 Location of Control (Rear) fig.panel-rear.eps Location of Control Parts List (Rear) Part Code Part Name Description Q’ty 5100051443 AC INLET M1909-C 5100024419 6.5MM JACK PJ-644C-04-EP(610-11020-01-00) 5100046593 JACK SPACER ******** JACK NUT attached to JACK ******** JACK WASHER attached to JACK 5100009531 USB CONNECTOR B TYPE FEMALE... -
Page 6: Exploded View (Cabinet)
Oct. 2019 KTN-50_2 Exploded View (Cabinet) fig.bunkai-all.eps Refer to Chassis... -
Page 7: Exploded View Parts List (Cabinet)
Oct. 2019 KTN-50_2 Exploded View Parts List (Cabinet) Part Code Part Name Description Q’ty 5100067716 CABINET ASSY * This unit includes the following parts. 5100052235 TRIM SASH 5100049817 HANDLE ******** CABINET ******** NET BOARD 5100052238 CORNER PROTECTOR 5100052237 BOSS BADGE 5100067502 KATANA2 BADGE 5100060776... -
Page 8: Plain View (Cabinet: 1)
Oct. 2019 KTN-50_2 Plain View (Cabinet: 1) fig.heimen1.eps View 1 View 2 View 3 View 4 View 1 Part Code Part Name Description Q’ty 40010689 SCREW 4X25 TRUSS TAPPING A FE BZC View 2 Part Code Part Name Description Q’ty 5100053056 NUT M4 W/SW BZC... -
Page 9: Plain View (Cabinet: 2)
Oct. 2019 KTN-50_2 Plain View (Cabinet: 2) fig.heimen2.eps View 5 View 6 View 7 View 8 View 5, View 6 Part Code Part Name Description Q’ty 5100043887 SCREW 3.5X16 TRUSS TAPPING A NI View 7 Part Code Part Name Description Q’ty 5100033930 SCREW 4X25... -
Page 10: Exploded View (Chassis)
Oct. 2019 KTN-50_2 Exploded View (Chassis) fig.bunkai-chasis.eps... -
Page 11: Exploded View Parts List (Chassis)
Oct. 2019 KTN-50_2 Exploded View Parts List (Chassis) Part Code Part Name Description Q’ty 5100067440 R-KNOB 5100067443 O-KNOB 5100049813 INDEX KNOB 5100052214 R-KNOB INDEX 02897801 SEESAW SWITCH SDDJE13200 94V-0 5100046595 POWER SW ESCUTCHEON 5100046598 POWER SW CUSHION 5100051443 AC INLET M1909-C 5100067407 CHASSIS... -
Page 12: Plain View (Chassis: 1)
Oct. 2019 KTN-50_2 Plain View (Chassis: 1) fig.heimen-chasis1.eps View 1 View 2 View 3 View 4 View 1 Part Code Part Name Description Q’ty 40011423 SCREW M3X6 PAN SEMS FECM View 2 Part Code Part Name Description Q’ty 40011156 SCREW 3X8 FLAT TAPTITE B BZC 40012945 SCREW M3X6... -
Page 13: Plain View (Chassis: 2)
Oct. 2019 KTN-50_2 Plain View (Chassis: 2) fig.heimen-chasis2.eps View 5 View 6 View 7 View 5 Part Code Part Name Description Q’ty 40564556 SCREW M3X15 PAN MACHINE W/SW FW ZC View 6 Part Code Part Name Description Q’ty 40017934 SCREW M3X6 PAN MACHINE W/SW+PW(L) FE ZC 22150501 STANDOFF... -
Page 14: Wiring Diagram
Oct. 2019 KTN-50_2 Wiring Diagram fig.wiring-50.eps Speaker Panel Board Input Board CN400 CN500 CN502 C603 C603 CN600 CN600 CN8 CN11 CN8 CN11 Main Board Main Board CN10 CN10 Power SW Power SW CN901(L) CN901(L) CN904 CN904 CN902(N) CN902(N) CN903(NC) CN903(NC) CN700 CN700 Inlet... - Page 15 Oct. 2019 KTN-50_2 Part Code Part Name Description Q’ty 5100067824 WIRING W4 (1007/2547#28) 5100068454 WIRING W1 (1015#22-RED) 5100068455 WIRING W2 (1015#22-BLK) 5100067825 WIRING 1007#28 15X115-PHR-SAN-F 5100067822 WIRING W3 (2547#28) 5100068458 WIRING W10 (1430#24/1185#26) 5100068456 WIRING W8 (1672#22-BLK/WHT) 5100068457 WIRING W9 (1672#22-BLK) 5100068453 WIRING W17A (1015#18-GRN&YEL)
-
Page 16: Block Diagram
Oct. 2019 KTN-50_2 Block Diagram fig.block-50.eps@L... - Page 17 Oct. 2019 KTN-50_2 fig.block-50.eps@R...
-
Page 18: Parts List
• Supply is prohibited due to copyright restrictions. • Reissuance is restricted. • It is carried in electronic data on the Roland web site. • It is supplied as an assembled part (under a different part code). • The part is made to order (at current market price). - Page 19 Oct. 2019 KTN-50_2 WIRING, CABLE 5100067825 WIRING 1007#28 15X115-PHR-SAN-F 5100068454 WIRING W1 (1015#22-RED) 5100068455 WIRING W2 (1015#22-BLK) 5100067822 WIRING W3 (2547#28) 5100067824 WIRING W4 (1007/2547#28) 5100068456 WIRING W8 (1672#22-BLK/WHT) 5100068457 WIRING W9 (1672#22-BLK) 5100068458 WIRING W10 (1430#24/1185#26) 5100068453 WIRING W17A (1015#18-GRN&YEL) TRANSFORMER 5100051957 POWER TRANSFORMER...
- Page 20 Oct. 2019 KTN-50_2 ACCESSORIES (Standard) 03340956 AC CORD SET PSE (W/ADAPTOR) 100V YA-101/YP-3NB/YC-13 (19) for 100V 00894378 AC CORD SET 120V SP301+IS14 SJT18/3 (22) for 117VU, 117VU/CS 5100029165 AC CORD 115TW 2.5M SP301+IS14 VCTF (25) for 117VTW 5100012292 AC CORD SET 117VBL 2.5M 3P DAIKEI 117VBL (26) for 117VBL 00894389...
-
Page 21: Verifying The Version
Oct. 2019 KTN-50_2 Verifying the Version System Update Procedure Carry out verification in the Test Mode (p. 22). Items Required • Computer Data Backup and Restore • USB cable Operations • Update use file (obtained via Service Net) Procedure All user data and settings of the unit can be backed up completely by procedure described below. -
Page 22: Test Mode
Oct. 2019 KTN-50_2 Test Mode Entering the Test Mode Turn all knobs all the way counterclockwise. Hold down CH1 and CH2 and turn on the power. Items Required Continue to hold down CH1 and CH2 until all LEDs light up, then release •... - Page 23 Oct. 2019 KTN-50_2 1. Model Check As shown in the table below, one of the 5 EFFECTS button lights up in green, and indicates the model. MODEL BOOSTER DELAY REVERB KTN-50 Mk II KTN-100 Mk II KTN-100/212 Mk II KTN-HEAD Mk II G: lights in green, -: goes off * If the model name shown in the table above does not match with the model name sticker on the rear panel, then the wrong main board is being installed.
- Page 24 Oct. 2019 KTN-50_2 4. Selector Check BOOSTER flashes in red. Slowly turn the AMP TYPE knob one click at a time in order of the numbers shown in the table below, and verify the status of the LEDs. Knob Position Button (LED) Procedure Position...
- Page 25 Oct. 2019 KTN-50_2 6. Jack Sense & Foot Switch Check VARIATION flashes. Operate each jack in the number sequence shown in the table below, and verify the status of the LEDs. Operation Procedure Button (LED) VARIA- BOOS Jack Procedure DELAY REVERB PANEL TION...
- Page 26 Oct. 2019 KTN-50_2 9. Signal Level Check Adjust the POWER CONTROL knob to 50 W, and the MASTER knob to maximum. * When feeding the signal, do not leave the POWER CONTROL knob to INPUT -> PHONES L/R positions other than STANDBY for over five minutes, or else the product may get damaged.
- Page 27 Oct. 2019 KTN-50_2 Verify that the waveform of the signal output from the PHONES/REC OUT jack (L) is as follows. fig.test-wave-2.eps Disconnect the plug from the INPUT, and PHONES/REC OUT jacks. Press BOOSTER. BOOSTER lights up green. 10. Noise Check Connect a 1/4-inch monaural phone short cable to the INPUT jack.
-
Page 28: Circuit Board (Main Board)
Oct. 2019 KTN-50_2 Circuit Board (Main Board) fig.b-main-A.eps fig.b-main-B.eps... - Page 29 Oct. 2019 KTN-50_2...
-
Page 30: Circuit Diagram (Main Board: 1/3)
Oct. 2019 KTN-50_2 Circuit Diagram (Main Board: 1/3) fig.d-50-main-1.eps@L D+3.3V D+3.3V R299 D+3.3V EXP-IN_GATE [1/3 7E] R266 EXP-OUT_GATE [1/3 7E] D+3.3V R262 EXP-SW_SEND [1/3 9D] RA17 R242 SCAN_C [1/3 9D] RA18 C110 EXB28V103JX SCAN_B [1/3 9D] EXB28V220JX UnPop SCAN_A [1/3 9D] 10uF UnPop FC-VCC-CTL... - Page 31 Oct. 2019 KTN-50_2 fig.d-50-main-1.eps@R EA(14) R176 EA(13) R238 EA(12) R239 C176 EA(0:14) 10uF D+1.2V 1608 D+3.3V R196 R301 EA(14) 1005 R302 EA(13) EA(12) EA(11) RA23 EA(10) ED(0:15) TC7WU04FU TC7WU04FU EXB28V560JX EA(9) EA(8) EA(7) EA(6) D+1.2V RA22 FA-238 16.9344MHZ EA(5) EXB28V560JX EA(4) 12pF 12pF...
-
Page 32: Circuit Diagram (Main Board: 2/3)
Oct. 2019 KTN-50_2 Circuit Diagram (Main Board: 2/3) fig.d-50-main-2.eps@L UnPop Slave Mode Normal Speed Mode C217 SDTO:MSB justitied SDTI:MSB justified 0.1uF Input Gain:0dB De Emfasis Filter:44.1kHz Digital Filter:Sharp Roll-Off Parallel mode DA FS:3.4Vpp(+3.81dB) INPUT CODEC+5V D+3.3V CODEC+5V +AVCC 1005 C219 CN400 R107 R106... - Page 33 Oct. 2019 KTN-50_2 fig.d-50-main-2.eps@R UnPop to PANEL BOARD(CN501) R667 UnPop MASTER VR ENC-A ENC-B R666 C654 0.01uF CN603 C655 B6B-PH-SM4-TB (LF)(SN) 0.01uF 1005 C183 BKME500ETC100MF11D 1005 4.7k R120 +18+6dB 10uF 1608 SIG-MAIN [3/3 9C] 0.5% C158 1005 R255 47pF R130 C200 C113 MAIN...
-
Page 34: Circuit Diagram (Main Board: 3/3)
Oct. 2019 KTN-50_2 Circuit Diagram (Main Board: 3/3) fig.d-50-main-3.eps@L +PVCC +AVCC C270 0.1uF R236 1005 3225 R652 3225 C150 DVCC 220uF MRT500 TTC011B TP47 UnPop Q604 R649 R651 R646 UnPop C267 R650 C268 2SC4116-GR 0.1uF 0.1uF 1608 1608 1608 1608 UnPop UnPop UnPop... - Page 35 Oct. 2019 KTN-50_2 fig.d-50-main-3.eps@R +PVCC +AVCC +PVCC 0.073W R334 R284 R169 1.2k UnPop 1608 2.7k 0.5W R323 3225 3225 R225 1.8k R231 1608 3225 1.2k 2SA1587-GR 1608 R271 R335 R333 R268 1608 1608 1608 R286 2SA1587-GR 1SS387 1608 3.9k UnPop 0.5W UnPop UnPop...
-
Page 36: Circuit Board (Panel, Amp, Input, Fuse Board)
Oct. 2019 KTN-50_2 Circuit Board (Panel, Amp, Input, Fuse Board) fig.b-50-panel.eps... - Page 37 Oct. 2019 KTN-50_2...
-
Page 38: Circuit Diagram (Panel Board)
Oct. 2019 KTN-50_2 Circuit Diagram (Panel Board) fig.d-50-panel.eps@L VARIATION LED+3.3V_PANEL C530 C549 R516 R517 R544 R502 R503 R505 0.1uF 0.1uF 1608 1608 1608 1608 1608 1608 1005 1005 TP594 TP533 TP534 TP559 TP560 TP595 TP596 DG_PANEL DG_PANEL LED-DATA_L R555 [3A] LED-DATA_R DATA R556... - Page 39 Oct. 2019 KTN-50_2 fig.d-50-panel.eps@R C551 0.1uF LED+3.3V_PANEL 1005 DG_PANEL C512 R510 R520 R552 R506 R508 R551 0.1uF 1608 1608 1608 1608 1608 1608 1005 DG_PANEL TP527 TP531 TP504 TP541 TP542 TP522 TP502 TP501 TP563 R512 DATA R546 1608 CLOCK 1608 R501 R504 1608...
-
Page 40: Circuit Diagram (Amp Board)
Oct. 2019 KTN-50_2 Circuit Diagram (Amp Board) fig.d-50-amp.eps C708 47uF R703 R704 [105 ] +PVCC_AMP to MAIN BOARD(CN4) AG_AMP C703 C706 +PVCC_AMP 0.1uF 330uF 100V 1005 [105 ] Radial TP704 TP703 R710 REF-GND_AMP C709 AG_AMP SPOUT-MONITOR [2D] 12.SENSOR 220pF PG_AMP 1608 11.REF-GND 100V... -
Page 41: Circuit Diagram (Input Board)
Oct. 2019 KTN-50_2 Circuit Diagram (Input Board) fig.d-50-input.eps +AVCC_INPUT C403 C419 0.018uF R405 390pF GUITAR INPUT +AVCC_INPUT C416 1005 0.5% 1005 D400 0.1uF 1SS362FV 1608 1005 R410 R416 0.5% 4.7k 0.5% -AVCC_INPUT 1608 1608 R400 AG_INPUT R420 C423 C421 C410 10uF 15pF 1608...
