- Page 1 POWERED STUDIO MONITORS S E R I E S T W O S E R I E S T W O S E R I E S T W O S E R I E S T W O O W N E R ' S M ANUAL YSM5-2 M A NU EL D E L ' UT IL I S A T EU R YSM6-2...
- Page 2 IM PORTANT SAF E T Y IN ST RU CT I O N S This lightning flash with arrowhead symbol, within The exclamation point within an equilatereal triangle is intended to alert the an equilateral triangle, is intended to alert the user to the presence of user to the presence of important operating and maintenance (servicing) uninsulated “dangerous voltage”...
-
Page 3: Input Section
Yorkville dealer. 2. Input Section Balanced The YSM-2 Series utilizes balanced XLR and 1/4-inch TRS inputs, and an unbalanced RCA input. If you need to use an 1/8-inch input, a Yorkville A210MRY 1/8-inch to RCA cable can be used. -
Page 4: Volume Control
3. Volume Control The Volume control enables the YSM-2 Series monitors to be properly matched to various systems enabling the best calibration between the devices. The Level can be adjusted in two ways, i. as a Volume Control. Connect a line in from the line-level source into the YSM-2 Series monitor’s input located at the back of the unit, proceed to rotate the Level control located at the rear of the monitor counter clockwise for minimum gain/off... - Page 5 Moniteurs de Studio Amplifiés YSM5-2, YSM6-2 et YSM8-2 Félicitations pour votre achat de la nouvelle génération de moniteurs de studio amplifiés Yorkville Sound. En nous appuyant sur nos connais- sances techniques et notre expéri- ence, nous avons développé les meilleurs moniteurs de leur catégorie.
-
Page 6: Commande De Volume
La série YSM-2 utilise des entrées XLR et TRS 1/4 pouce symé- triques, ainsi qu’une entrée RCA asymétrique. Si vous devez utiliser une entrée 1/8 pouce, vous pouvez utiliser un câble Yorkville A210M- RY 1/8 pouce vers RCA. 3. Commande de Volume La commande de volume permet d’adapter correctement les moniteurs... - Page 7 Full Space Placement 1/2 Space Placement 1/4 Space Placement (full area) (against the wall) (in corner) 6. Limiteurs La série YSM-2 est équipée de limiteurs HF et BF intégrés. En plus de protéger contre les sur-excursions, les limiteurs empêchent l’écrêtage de l’amplificateur et la surchauffe des bobines mobiles.
- Page 8 POWERED STUDIO MONITORS S E R I E S T W O Specifica ons Model YSM5-2 YSM6-2 YSM8-2 Ac ve or Passive Ac ve Ac ve Ac ve Power (wa s) Biamp / Configura on Yes-Two Way Yes-Two Way Yes-Two Way Max SPL (dB) Frequency Response (Hz +/- 3dB) 50Hz-22kHz...
- Page 9 POWERED STUDIO MONITORS S E R I E S T W O Spécifica ons Modèle YSM5-2 YSM6-2 YSM8-2 Ac f ou passif Ac f Ac f Ac f Puissance (wa s) Biamp / Configura on Oui-Deux voies Oui-Deux voies Oui-Deux voies NPA maximum (dB) Réponse en fréquence (Hz +/- 3dB) 50Hz-22kHz...
- Page 11 Unlimited Warranty Yorkville's two and ten-year unlimited warranty on this product is transferable and does not require registration with Yorkville Sound or your dealer. If this product should fail for any reason within two years of the original purchase date (ten years for the wooden enclosure), simply return it to your Yorkville dealer with original proof of purchase and it will be repaired free of charge.
- Page 12 WORLD HEADQUARTERS CANADA U.S.A. Yorkville Sound Limited Yorkville Sound Inc. 550 Granite Court 4625 Witmer Industrial Estate Pickering, Ontario Niagara Falls, New York L1W 3Y8 CANADA 14305, USA Voice: 905-837-8481 Voice: 716-297-2920 Fax: 905-837-8746 Fax: 716-297-3689 Manual-Owners-YSM-2-SERIES-00-1v0 • October 13, 2021...
