USER MANUAL
ENGLISH
Thank you very much for choosing the iiyama
LCD monitor.
We recommend that you take a few minutes
to re a d c ar efull y t hrough this brief but
comprehensive manual before installing
and switching on the monitor. Please keep
this manual in a safe place for your future
reference.
Advertisement
Table of Contents
Related Manuals for Iiyama G-Master GB3467WQSU
Summary of Contents for Iiyama G-Master GB3467WQSU
- Page 1 USER MANUAL ENGLISH Thank you very much for choosing the iiyama LCD monitor. We recommend that you take a few minutes to re a d c ar efull y t hrough this brief but comprehensive manual before installing and switching on the monitor. Please keep this manual in a safe place for your future reference.
- Page 3 IIYAMA CORPORATION: Wijkermeerstraat 8, 2131 HA Hoofddorp, The Netherlands Model No. : PL3467WQ We recommend recycling of used product. Please contact your dealer or iiyama service center. Recycle information is obtained via the Internet, using the address: http://www.iiyama.com You can access the Web page of different countries from there.
-
Page 4: Table Of Contents
TABLE OF CONTENTS FOR YOUR SAFETY ................1 SAFETY PRECAUTIONS..............1 SPECIAL NOTES ON LCD MONITORS .........3 CUSTOMER SERVICE ..............3 CLEANING ..................3 BEFORE YOU OPERATE THE MONITOR ..........4 FEATURES..................4 CHECKING THE CONTENTS OF THE PACKAGE ......4 INSTALLATION ................5 FITTING AND REMOVAL OF BASE ..........6 CONTROLS AND CONNECTORS..........7 CONNECTING YOUR MONITOR ...........8 COMPUTER SETTING ..............9... -
Page 5: For Your Safety
DO NOT PUT ANY OBJECT INTO THE MONITOR Do not put any solid objects or liquids such as water into the monitor. In case of an accident, unplug your monitor immediately and contact your dealer or iiyama service center. Using the monitor with any object inside may cause fire, electric shock or damage. - Page 6 CAUTION INSTALLATION LOCATION Do not install the monitor where sudden temperature changes may occur, or in humid, dusty or smoky areas as it may cause fire, electric shock or damage. You should also avoid areas where the sun shines directly on the monitor. DO NOT PLACE THE MONITOR IN A HAZARDOUS POSITION The monitor may topple and cause injury if not suitably located. Please also ensure that you do not place any heavy objects on the monitor, and that all cables are routed such that children may not pull the cables and possibly cause injury.
-
Page 7: Special Notes On Lcd Monitors
CUSTOMER SERVICE NOTE If you have to return your unit for service and the original packaging has been discarded, please contact your dealer or iiyama service center for advice or replacement packaging. CLEANING If you drop any materials or liquids such as water into the monitor when cleaning, WARNING unplug the power cable immediately and contact your dealer or iiyama service center. -
Page 8: Before You Operate The Monitor
CHECKING THE CONTENTS OF THE PACKAGE The following accessories are included in your package. Check to see if they are enclosed with the monitor. If anything is missing or damaged, please contact your local iiyama dealer or regional iiyama office. Power Cable* ... -
Page 9: Installation
INSTALLATION WARNING Before installation, make sure the wall, ceiling or desktop arm is strong enough to hold the necessary weight of the display and the mount. [WALL MOUNTING] WARNING When you use with the wall mounting, in consideration of thickness of the mounting stage, tighten the M4 Screws (4pcs) which “L” length is 8mm to fasten the monitor. -
Page 10: Fitting And Removal Of Base
FITTING AND REMOVAL OF BASE Put the monitor on a stable surface. The monitor may cause injury or damage if it CAUTION falls or is dropped. Do not give a strong impact to the monitor. It may cause damage. Unplug the monitor before removal or installation to avoid an electric shock or a damage. -
Page 11: Controls And Connectors
CONTROLS AND CONNECTORS <Back> <Front> Power Indicator Blue: Normal operation NOTE Orange: Standby mode Speakers Keyhole for Security Lock You can fasten a security lock and cable to prevent the monitor from being removed NOTE without your permission. U SB (3.0) Upstream Connector ( USB (3.0) Downstream Connector ( 5V, 900mA) USB (3.0) Downstream Connector (... -
Page 12: Connecting Your Monitor
An incorrect connection may cause serious damage to both the monitor and the computer. The cable supplied with the monitor is for a standard connector. If a special cable is required please contact your local iiyama dealer or regional iiyama office. -
Page 13: Computer Setting
COMPUTER SETTING Signal Timing Change to the desired signal timing listed on page 28: COMPLIANT TIMING. ADJUSTING THE HEIGHT AND THE VIEWING ANGLE For optimal viewing it is recommended to position yourself directly opposite to the full face 3°... -
Page 14: Operating The Monitor
OPERATING THE MONITOR To create the best picture, your iiyama LCD monitor has been preset at the factory with the COMPLIANT TIMING shown on page 28. You are also able to adjust the picture by following the button operation shown below. -
Page 15: Adjustment Menu Contents
ADJUSTMENT MENU CONTENTS Picture Adjust G-MASTER GB3467WQSU PICTURE ADJUST PICTURE ADJUST INPUT SELECT CONTRAST BRIGHTNESS AUDIO ADJUST STORE USER SETTING OVERDRIVE COLOR SETTINGS ADV. CONTRAST IMAGE ADJUST LANGUAGE BLUE LIGHT REDUCER SETUP MENU BLACK TUNER DISPLAY INFORMATION RESET GAMMA3 GAMMA... - Page 16 The availability of each item depends on which item is activated. See page 23 Function Correlation Matrix for more details. Adjust the Brightness when you are using the monitor in a dark room and feel the screen is too bright. MBR is available only when the refresh rate is higher than 75Hz.
- Page 17 Input Select G-MASTER GB3467WQSU PICTURE ADJUST INPUT SOURCE Direct INPUT SELECT AUTO MANUAL AUDIO ADJUST MANUAL STORE USER SETTING SELECT COLOR SETTINGS SELECT IMAGE ADJUST HDMI1 SELECT HDMI2 SELECT LANGUAGE SETUP MENU DISPLAY INFORMATION RESET Option Adjustment Item Search for an available input source and Auto select automatically.
- Page 18 Audio Adjust G-MASTER GB3467WQSU PICTURE ADJUST VOLUME INPUT SELECT AUDIO ADJUST OPTIONS STORE USER SETTING MUTE COLOR SETTINGS IMAGE ADJUST LANGUAGE SETUP MENU DISPLAY INFORMATION RESET Adjustment Item Problem / Option Button to Press Too soft Direct Volume Too loud Turn off the sound temporarily.
- Page 19 Store User Setting G-MASTER GB3467WQSU PICTURE ADJUST STORE USER SETTING INPUT SELECT USER MODES USER MODE 1 AUDIO ADJUST STORE USER SETTING COLOR SETTINGS IMAGE ADJUST LANGUAGE SETUP MENU DISPLAY INFORMATION RESET Adjustment Item Option User Mode 1 Save the settings of the screen adjustment.
- Page 20 Color Settings * G-MASTER GB3467WQSU PICTURE ADJUST COLOR TEMPERATURE INPUT SELECT COOL NORMAL WARM AUDIO ADJUST 6-AXIS SATURATION STORE USER SETTING USER PRESET COLOR SETTINGS IMAGE ADJUST GREEN LANGUAGE BLUE SETUP MENU DISPLAY INFORMATION RESET Adjustment Item Problem / Option...
- Page 21 Image Adjust G-MASTER GB3467WQSU PICTURE ADJUST IMAGE ADJUST INPUT SELECT I-STYLE COLOR AUDIO ADJUST X-RES TECHNOLOGY STORE USER SETTING SHARP AND SOFT COLOR SETTINGS HDMI RANGE FULL DIRECT DRIVE MODE IMAGE ADJUST LANGUAGE VIDEO MODE ADJUST FULL SETUP MENU DISPLAY INFORMATION...
- Page 22 Image Adjust G-MASTER GB3467WQSU PICTURE ADJUST IMAGE ADJUST INPUT SELECT I-STYLE COLOR AUDIO ADJUST X-RES TECHNOLOGY STORE USER SETTING SHARP AND SOFT COLOR SETTINGS HDMI RANGE FULL DIRECT DRIVE MODE IMAGE ADJUST LANGUAGE VIDEO MODE ADJUST FULL SETUP MENU DISPLAY INFORMATION...
- Page 23 Language G-MASTER GB3467WQSU PICTURE ADJUST CHANGE LANGUAGE INPUT SELECT ENGLISH Italiano Português AUDIO ADJUST Deutsch Рyccкий STORE USER SETTING Español Nederlands Ĉesky COLOR SETTINGS Français Polski IMAGE ADJUST LANGUAGE SETUP MENU DISPLAY INFORMATION RESET Adjustment Item Option Nederlands Dutch English...
- Page 24 Setup Menu G-MASTER GB3467WQSU PICTURE ADJUST SETUP MENU INPUT SELECT OSD HORIZONTAL POSITION AUDIO ADJUST OSD VERTICAL POSITION STORE USER SETTING OSD TIME COLOR SETTINGS OPENING LOGO IMAGE ADJUST LANGUAGE AMD FreeSync Premium SETUP MENU DISPLAY INFORMATION DDC/CI RESET USB STANDBY MODE...
- Page 25 Display Information G-MASTER GB3467WQSU PICTURE ADJUST DISPLAY INFORMATION INPUT SELECT 2560 x 1440 120Hz AUDIO ADJUST STORE USER SETTING COLOR SETTINGS IMAGE ADJUST LANGUAGE SETUP MENU DISPLAY INFORMATION RESET Displays information regarding the current input signal coming from the graphic card in your computer.
- Page 26 ● Lock Mode <OSD> If you turn on the monitor with holding down the MENU Button on the monitor while the monitor is off, the OSD button operations will be locked / unlocked. <Power / OSD> If you keep pressing the MENU Button on the monitor for 10 seconds when the Menu is not displayed, the Power / OSD button operations will be locked / unlocked.
- Page 27 Function Correlation Matrix Selected Picture Adjust Color Image Adjust Setup item i-Style Color Video Mode Blue Cool / Adv. Black Hue / Direct Free Dot by Contrast Brightness Overdrive Light MBR Gamma Normal / R/G/B User X-Res Pre- Full / Contrast Tuner Saturation...
-
Page 28: Standby Feature
STANDBY FEATURE This product features the standby function. When activated, it automatically reduces unnecessary power consumption of the monitor when your computer is not in use. There is a standby step the monitor takes as described below. The standby function, including any timer settings is configured by the operating system. Check your operating system manual for information on how this can be configured. -
Page 29: Trouble Shooting
MONITOR or if the problem persists. 3. If you are experiencing a problem which is not described below or you cannot correct the problem, discontinue using the monitor and contact your dealer or iiyama service center for further assistance. Problem... -
Page 30: Recycling Information
RECYCLING INFORMATION For better environment protection please don't dispose your monitor. Please visit our web site: www.iiyama.com for monitor recycling. 26 RECYCLING INFORMATION... -
Page 31: Appendix
APPENDIX Design and specifications are subject to change without prior notice. SPECIFICATIONS Size Category 34" Panel technology Size Diagonal: 34" (86.4cm) Pixel pitch 0.232mm H × 0.232mm V Brightness 550cd/m (Typical) Panel Contrast ratio 3000 : 1 (Typical), Advanced Contrast Function Available Viewable angle Right / Left : 89 degrees each, Up / Down: 89 degrees each (Typical) MPRT 0.4ms Display Colors Approx. 16.7M HDMI: Horizontal: 30.0-160.0kHz Vertical: 48-120Hz (1920 × 1080 or less) Sync Frequency 48-100Hz (3440 × 1440) DisplayPort: Horizontal: 30.0-250.0kHz Vertical: 48-165Hz Native Resolution... -
Page 32: Dimensions
DIMENSIONS 809.5mm/31.9” 104.0mm/4.1” 801.5mm/31.6” 550.0mm/21.7” ( ) : Maximum adjustment range COMPLIANT TIMING Horizontal Vertical Video Mode Dot Clock Frequency Frequency 37.879kHz 60.317Hz 40.000MHz 800 × 600 46.875kHz 75.000Hz 49.500MHz 48.363kHz 60.004Hz 65.000MHz 1024 × 768 60.023kHz 75.029Hz 78.750MHz 63.981kHz 60.020Hz 108.000MHz 1280 × 1024 79.976kHz 75.025Hz 135.000MHz...
