  • Page 1 DACC2000 User's Manual ENG-015 Rev. 1...
  • Page 2 CONTENTS Kimray, Inc. provides this publication “as is”, without warranty of any kind, either express or implied, including, but not limited to, the implied warranties of merchantability or fitness for a particular purpose. Information in this publication is subject to change without notice. For current revision go to : http://www.kimray.com:8100/Public/Literature/Automation...
  • Page 3 CONTENTS...

  • Page 4: Table Of Contents

    3.1 Port Connections 3.2 RS-485 4.0 Operation 4.1 Internal 4.2 Input/Output 4.2.1 Analog Inputs 4.2.2 Status Inputs 4.2.3 Accumulator Inputs 4.2.4 Relay Outputs 4.2.5 Analog Outputs 4.2.6 Power Switching 4.2.7 Display Interface 4.2.8 Communications 5.0 Specifications DACC2000 USER'S MANUAL (ENG-015 Rev. 1)
  • Page 5 CONTENTS...

  • Page 7: Introduction

    1.0 Overview of The Kimray DACC2000 RTU 1.1 Introduction This document describes the Kimray DACC2000, an RTU for data acquisition, supervisory control and communications designed to handle the requirements of oil and gas field automation. Included in this manual are the following sections: ...
  • Page 8 DACC2000 USER'S MANUAL (ENG-015 Rev. 1)

  • Page 9: Installation

    ANALOG INPUTS KIMRAY 0COM DIGITAL 1COM OUTPUTS 2COM 3COM ANALOG OUT0 POWER ANALOG OUTPUTS FIGURE 2.1 DACC2000 TERMINAL BLOCKS Figure 2.1 shows the locations of the DACC2000 terminal barriers. All process wiring to the DACC2000 USER'S MANUAL (ENG-015 Rev. 1)

  • Page 10: Power Interconnection

    Battery is automatically charged with no external charger controller required. The maximum current for the charger on the DACC2000 is 4 Amp. This limits the maximum size of the solar panel controlled by the DACC2000 to 70 watts. If a larger solar panel is required, an external battery charging regulator must be used.

  • Page 11: Signal Connections

    DACC2000 termination. Twisted pair wire with a minimum of 6 twists per inch will cancel noise induced by 60 Hz AC current by introducing equal and opposite currents in both wires.
  • Page 12 JP1, shown in Figure 2.3. The fuse for this power is F1, also shown in Figure 2.3. Jumpers are provided for each analog channel of the DACC2000, as illustrated in Figure 2.3, to configure shunt resistors for each channel. JP4 through JP7 are used to connect 250 shunt resistors to each channel for using 4 to 20 mA input signals.

  • Page 13: Digital Inputs

    Each digital input is terminated in two compression screws in the terminal barrier located on the left edge of the DACC2000 (refer to Figure 2.4). Open inputs are read as a 1 and closed inputs as a 0. Each closed input causes a corresponding LED to light.

  • Page 14: Relay Outputs

    ACC1. This is illustrated in Figure 2.4 where the input is connected between ACC1- and ACC1-. 2.2.4 Relay Outputs The DACC2000 has 4 relay (digital) output channels, each a set of form C contacts (SPDT). The 0COM RELAY...

  • Page 15: Analog Outputs

    Each channel has an LED to indicate when the channel is energized. 2.2.5 Analog Outputs The two optional Analog outputs of the DACC2000 each generate a 4 to 20 mA DC output (which is normally required for process actuators) or a 1 to 5 volt output. The outputs are normally powered by the DACC2000 but can be powered from an external source.

  • Page 16: Display Connection

    The Potentiometer by the connector controls the contrast of the display. CONTRAST DISPLAY ADJUSTMENT CONNECTOR DISPLAY KIMRAY DACC2000 COMM1 PERIPH COMM2 FIGURE 2.8 DACC2000 DISPLAY DACC2000 USER'S MANUAL (ENG-015 Rev. 1)

  • Page 17: Communications

    COMMUNICATIONS 3.0 Communications This section describes connecting the DACC2000 to communications devices and configuring the DACC2000's communications ports. 3.1 Port Connections The communications connectors are located along the top of the DACC2000 (Figure 3.1). DISPLAY KIMRAY DACC2000 485+ XMIT 485-...

  • Page 18: Rs-485

    3.2 RS-485 The RS-485 port is on the top left of the DACC2000. RS-485 is an enhanced version of the RS- 422 balanced line standard. It allows multiple drivers and receivers (up to 32) on a two wire system.
  • Page 19 COMMUNICATIONS 485+ 485- KIMRAY DACC2000 KIMRAY MULTIVARIABLE CIM KIMRAY I/O CIM FIGURE 3.4 DACC2000 AND KIMRAY CIM CONNECTION DACC2000 USER'S MANUAL (ENG-015 Rev. 1)
  • Page 20 COMMUNICATIONS DACC2000 USER'S MANUAL (ENG-015 Rev. 1)

  • Page 21: Operation

    Withstand Test. 4.2.1 Analog Inputs The DACC2000 has 4 external analog input channels configurable for a range of 1 to 5 Volts or 4 to 20 mA. The DACC2000 also measures two internal signals. These are battery voltage and charger voltage. All inputs are measured by a successive approximation analog-to-digital converter with 12 bits of resolution.

  • Page 22: Status Inputs

    4.2.2 Status Inputs The DACC2000 has 4 optically isolated digital (status) inputs. Figure 4.2 shows the circuit for one channel of the four. Each input is differentially surge protected with Metal-Oxide-Varistors to IEEE 472-1974. The input pull-up current for dry contacts is supplied from the DACC2000 internal power.

  • Page 23: Relay Outputs

    DACC2000 PULSE INPUTS SIMPLIFIED SCHEMATIC 4.2.4 Relay Outputs The DACC2000 provides 4 relay (digital) output channels. These channels are SPDT (Form C) relays with a 10 Amp rating. Each output channel provides both normally open (NO) and normally closed (NC) contacts.

  • Page 24: Analog Outputs

    DACC2000 DIGITAL OUTPUTS SIMPLIFIED SCHEMATIC 4.2.5 Analog Outputs The DACC2000 has 2 analog output channels. Each channel provides a 1 to 5 Volt or 4 to 20 mA output. Output power can be provided by the DACC2000 or Externally. Each Digital-to- Analog converter has a resolution of 12 bits, and the analog output circuit provides an overall accuracy of better than 0.1%.

  • Page 25: Display Interface

    DACC2000 POWER SWITCHING SIMPLIFIED SCHEMATIC 4.2.7 Display Interface The DACC2000 has a display interface to drive a character display. It includes a temperature compensated bias circuit (generating VO in Figure 4.7) to keep the contrast adjusted over ambient temperature variations.

  • Page 26: Communications

    OPERATION 4.2.8 Communications The DACC2000 has 4 serial communications ports (Figure 4.8). Three ports provide for RS-232 voltage levels and use standard DB-9 connector pinouts. Pin 4, the DTR pin, has 6.5 volts DC. This pin can be used either as DTR or can provide low current to a device attached to the port.

  • Page 27: Specifications

    Actuating a Digital Output Relay also increase current consumption. Battery: 12 Volt (10.5 to 18 V.), Charger DACC2000 provides charging control for solar or AC charging sources - Solar: 12 V., 70 Watt maximum AC: 15V, current limited to 3.5 A.
  • Page 28 SPECIFICATIONS Isolation: Input lines optically isolated from DACC2000 electronics on high level input. ANALOG INPUT Channels: 6 Description: 4 high level inputs 1 to 5 V or 4 to 20 mA inputs Single pole 3 Hz hardware filter Protected multiplexing Auto calibrated Common mode range: -3 V.
  • Page 30 D2KHM.DOC 5/19/04 DACC2000 USER'S MANUAL (ENG-015 Rev. 1)
