3. FUNCTIONAL DESCRIPTION
3.2.2 CONFIG interface and configuration plug
Connector type: 25-pin D-sub female connector (DB-25S)

(a) The DB-25S CONFIG interface

The DB-25P configuration plug (see Figure
operating modes of the switch.
Pin Pin Type
1 Output
2 Output
3 Output
4 Output
5 Output
6 Output
7 Output
8 Output
9 Output
10 NC
11 Output
12 NC
13 NC
14 NC
15 NC
16 NC
17 NC
18 Output
19 Output
20 Output
21 NC
© TTTech Computertechnik AG 2020. All rights reserved.
Confidential and Proprietary Information
Figure 6: The CONFIG interface of the TTE-Switch A664 Lab v2.0
6b
Description
Reset push button
Configuration selection 0 dip switch
Configuration selection 1 dip switch
Configuration selection 2 dip switch
Configuration selection 3 dip switch
Configuration selection 4 dip switch
Configuration selection 5 dip switch
Reserved for future use
Dip switch
Not connected
Dip switch
Not connected
Not connected
Not connected
Not connected
Not connected
Not connected
Dip switch
Dip switch
Maintenance dip switch
Not connected
(b) The DB-25P configuration plug
on this page) makes it possible to select configurations and
Dip Switch No.
12
Signal Name
– RESET
1 CON_SEL_0
2 CON_SEL_1
3 CON_SEL_2
4 CON_SEL_3
5 CON_SEL_4
6 CON_SEL_5
9 RFU
7 Shop-Mode
–
8 Write_Prot
–
–
–
–
–
–
10 WD_Disable
11 Grnd-Mode
12 RFU
–
