USB port 1
USB port 2
Input button. This button can be used to activate additional functions. When the input button is held, the Busy LED
will blink at a rate of once per second. Hold the button and release it after a particular number of blinks to activate
the associated function:
•
3 blinks will print a TCP3 configuration page to the attached printer.
•
8 blinks will reset the TCP3 configuration to factory defaults and will force a reboot. Note that this will not reset
the password. That can only be done by reloading the firmware.
USB ports
Users can connect a USB card reader to either of the 2 USB ports on TCP3. Up to two readers can be connected simultaneously.
Currently USB Human Interface Device also known as keyboard mode is supported.
TCP3 can provide up to 1.5 A current shared between the two USB ports. This means if the peripheral connected to one port is drawing
1.0 A, the second peripheral can draw up to 0.5 A before both ports will be turned off by the over current protection circuit. Removing
the second USB peripheral will enable the port to self-reset.
Note that only tested and approved USB devices will be allowed to operate on TCP3. This will enable ELATEC to provide support for
only those devices for which our support team has been trained. Following is the current list of tested and approved devices:
MANUFACTURER
ELATEC
ELATEC
ELATEC
ID Tech
ID Tech
MagTek
MagTek
Honeywell
Honeywell
Honeywell
Symcode
Motorola
Perixx
Perixx
Perixx
HCT
Valley Enterprises
Manhattan
NT-Ware
Lenovo
Targus
Targus
Table 1 - supported USB devices
Ethernet ports
There are also two Ethernet ports on TCP3: the Host port is used to connect TCP3 to the local network and the Printer port is used to
connect a printer to TCP3.
© 2022 ELATEC GmbH – TCP3 user manual DocRev3 – 03/2022
DEVICE
TWN3 RFID Reader
TWN4 RFID Reader
TWN4 SafeCom Reader
MiniMag II™ MagStripe reader
Barcode Reader
Dynamag Reader
MagStripe Reader
Model 3800 Barcode Reader
Model 3800 Barcode Reader
Model 1250G Barcode Reader
Barcode reader
Model DS9208 2D Barcode Reader
Peripad-201 Plus PIN pad
Peripad-201 PIN pad
Peripad-202 PIN pad
Numeric PIN Pad
USB to RS232 converter
28 port USB hub
TWN4 for NT-Ware
KU-9880 USB numeric Pin Pad
AKP10-A USB numeric Pin Pad
AKP10-A USB numeric Pin Pad
USB VID
USB PID
0x09D8
0x0310
0x09D8
0x0410
0x09D8
0x0206
0x0ACD
0x0001
0x0ACD
0x2420
0x0801
0x0520
0x0801
0x0001
0x0536
0x02E1
0x0C2E
0x0B01
0x0C2E
0x0B41
0x0483
0x0011
0x05E0
0x1200
0x2A7F
0x5740
0x1C4F
0x0043
0x04D9
0xA02A
0x1C4F
0x0002
0x0403
0x6001
0x2109
0x2811
0x171B
0x2001
0x04F2
0x3009
0x05A4
0x9840
0x05A4
0x9846
