4 TECHNICAL DATA
Power supply
External power supply 5 V or internal Power over Ethernet
Current consumption
Max. 3 A depending on external load
Hardware
The following LEDs and connectors are located on the TCP3 converter:
"POWER" LED
"Ready" LED
"Busy" LED
"Status" LED
Foreign Device Interface
Ethernet port 1
Ethernet port 2
DC power supply
© 2022 ELATEC GmbH – TCP3 user manual DocRev3 – 03/2022
Page 6 of 14
