- Page 1 INSTRUCTION MANUAL Vacuum Cleaner VC3211H Read before use.
-
Page 2: Specifications
SPECIFICATIONS Model VC3211H Countries Switzerland Voltage Volt 230-240 230-240 230-240 Power consumption Watt 1050 1050 1050 1050 Connected load for appliance 2400 1100 1900 Watt at symbol mode socket 2600 1400 2100 Watt at symbol mode Total connected load Watt... -
Page 3: Ec Declaration Of Conformity
EC Declaration of Conformity metal chips, sharp materials such as razors, needles, broken glass or the like. Makita declares that the following Machine(s): 10. NEVER USE THE CLEANER IN THE VICINITY Designation of Machine: OF GASOLINE, GAS, PAINT, ADHESIVES OR Vacuum Cleaner OTHER HIGHLY EXPLOSIVE SUBSTANCES. -
Page 4: Functional Description
24. CHECK DAMAGED PARTS. Before further use FUNCTIONAL of the cleaner, a guard or other part that is damaged should be carefully checked to deter- DESCRIPTION mine that it will operate properly and perform its intended function. Check for alignment of moving parts, binding of moving parts, break- WARNING: age of parts, mounting, and any other condi-... -
Page 5: Warning Beep
Warning beep There are two types of beeping sound. One is short beeps, and the other is long beep. When the air flow speed falls under 20 m/s, the cleaner emits short warning beeps for safety reasons. When it sounds, check the hose diameter selection dial or if the suction force is not too low. - Page 6 3. Storing the hose The cleaner has a mechanism that prevents water from immersing into the motor when picking up more than a certain amount of water. When the tank is full with liquid, the cleaner emits long warning beep. Switch off the cleaner and empty the tank when this beep sounds.
-
Page 7: Warning Sticker
NOTICE: • When moving the cleaner, make sure that the caster is unlocked. Moving the cleaner with the caster in the locked position may cause damage to the caster. There is a cap on the mounting port. The cap prevents the vacuumed dust from getting out from the cleaner. -
Page 8: Operation
CAUTION: • Always be sure that the tool is switched off and unplugged before attempting to perform inspec- tion or maintenance. • Never use gasoline, benzine, thinner, alcohol or the like. Discoloration, deformation or cracks may result. • Please check with your local authorities for any reg- ulations regarding the use of these vacuum cleaners when working with toxic materials such as Asbestos. - Page 9 Assembling the air filter When you get the air filter components separately, assemble them as follows. ► 1. Stopper lever Remove the screw on the stopper lever. Unlock the filter hooks by flipping the stopper lever. ► 1. Powder filter 2. Damper 3. Prefilter Put the prefilter over the powder filter.
-
Page 10: Installing The Air Filter
Installing the air filter Cleaning the level sensors ► 1. Level sensors The level sensors detect liquid when the tank becomes full with liquid. Clean the level sensors with a soft cloth from time to time when changing the air filters. Storage of power supply cord Wipe off the seal face. -
Page 11: Storage Of Accessories
CAUTION: • These accessories or attachments are recom- mended for use with your Makita tool specified in this manual. The use of any other accessories or attach- ments might present a risk of injury to persons. Only use accessory or attachment for its stated purpose. - Page 12 NOTE: • Some items in the list may be included in the tool package as standard accessories. They may differ from country to country. Makita Europe N.V. Jan-Baptist Vinkstraat 2, 3070 Kortenberg, Belgium Makita Corporation 3-11-8, Sumiyoshi-cho, Anjo, Aichi 446-8502 Japan 885232E224 www.makita.com...
