Generator Specifications; Nominal Resistances Of Generator Windings At 68°F; Torque Requirements; Section 10 - Generac Power Systems Guardian 5410 Repair Manual

TYPE
MODEL
WEIGHT
TYPE OF ROTOR
RATED WATTS
RATED VOLTS
PHASE
RATED MAx.
CONTINUOUS CURRENT
AMPS (240V)
RATED FREqUENCY
OPERATING SPEED
ENGINE MODEL
TYPE OF ENGINE
FUEL SYSTEM
COOLING SYSTEM
OIL SYSTEM
OIL PUMP
AIR CLEANER
STARTER
IGNITION SYSTEM
SPARk PLUG
SPARk PLUG GAP
NOMINAL RESISTANCES OF gENERATOR WINdINgS AT 68°F
TYPE
MODEL
Power Windings
Lead 11 to 22
Lead 11S to 22S
Lead 33 to 44
Excitation "DPE" Winding
Lead 2 to 6
Rotor Winding
Slip Ring to Slip Ring
Stator Bolts ................................................................ 8 ft-lbs
Alternator Pulley ...................................................... 38 ft-lbs
Engine Pulley ........................................................... 38 ft-lbs
Oil Adaptor Bolt ...................................................... 4.5 ft-lbs
Oil Lines .................................................................. 70 in-lbs
Intake Manifold ........................................................ 18 ft-lbs
Exhaust Manifold ..................................................... 18 ft-lbs
M5-0.8 taptite screw into aluminum ................... 25-50 in-lbs
M5-0.8 taptite screw into pierced hole ............... 25-50 in-lbs

gENERATOR SPECIFICATIONS

RV 45G/LP
5410/5411
278/281 pounds
Two-pole
4500
120
1-Phase
37.5 (18.7)
60 Hz
2571 rpm
GT-530
Vertical Shaft
Gasoline/LP
Air-Cooled
Pressurized with Filter
Trochoid Type
Paper element
12 VDC electric
Solid State/Flywheel
Magneto
NGk BPR6HS
0.030 inch (0.76mm)
RV 45G/LP
5410/5411
0.376 - 0.416 ohms
2.59 ohms
13.4 ohms

TORqUE REqUIREMENTS

SPECIFICATIONS & CHARTS
RV 55G/LP
5412/5413
285/288 pounds
Two-pole
5500
120
1-Phase
45.8 (22.9)
60 Hz
2571 rpm
GT-530
Vertical Shaft
Gasoline/LP
Air-Cooled
Pressurized with Filter
Trochoid Type
Paper element
12 VDC electric
Solid State/Flywheel
Magneto
NGk BPR6HS
0.030 inch (0.76mm)
RV 55G/LP
5412/5413
0.28 - 0.32 ohms
1.41 - 1.63 ohms
14.88 ohms
(unless otherwise specified)
M6-1.0 taptite screw into aluminum ................... 50-96 in-lbs
M6-1.0 taptite screw into pierced hole ............... 50-96 in-lbs
M6-1.0 taptite screw into weldnut ...................... 50-96 in-lbs
M8-1.25 taptite screw into aluminum ................. 12-18 ft-lbs
M6-1.0 nylok nut onto stud ................................ 16-65 in-lbs
Dipstick Casting Oil Line ....................................... 250 in-lbs
Note: Torques are dynamic values with ±10 % tolerance
unless otherwise noted.

Section 10

RV 65G/LP
5414/5415
293/296 pounds
Two-pole
6500
120
1-Phase
54.1 (27)
60 Hz
2571 rpm
GT-530
Vertical Shaft
Gasoline/LP
Air-Cooled
Pressurized with Filter
Trochoid Type
Paper element
12 VDC electric
Solid State/Flywheel
Magneto
NGk BPR6HS
0.030 inch (0.76mm)
RV 65G/LP
5414/5415
0.209 - 0.242 ohms
1.59 - 1.84 ohms
10.81 ohms
Page 77
