Generac Power Systems Guardian 5410 Repair Manual page 71

ITEM QTY. DESCRIPTION
1 1 SCrEW HHC M6-1.0 X 25 G8.8
2 2 SCrEW PLaStItE HI-LOW #10X3/8
3 1 BUSHING SNaP SB-1093-937
4 1 WIrE HarNESS C/PNL FraME
5 1 NUt HEX M6 X 1.0 G8 YEL CHr
6 2 WaSHEr FLat 1/4-M6 ZINC
7 1 WaSHEr LOCK SPECIaL 1/4"
8 1 FUEL PUMP MOUNtING BraCKEt
9 28.75" HOSE,1/4" SaE30r7
10 1 CLaMP,HOSE OEtIKr StEPLSS 14.5
11 1 BarBED Str 1/8NPt X 1/4
12 5 NUt FLaNGE M6-1.0 NYLOK
13 1 FUEL PUMP
14 1 ELBOW 90D StrEEt 1/8 BraSS
15 1 FILtEr FUEL 1/8P-1/4H
16 1 SCrEW HHC 1/4-20 X 2-1/4" G5
17 2 WaSHEr LOCK M6-1/4
18 1 aC HarNESS 530rV
19 1 GrOMMEt, DOUBLE SLIt
20 3 NUt HEX JaM 3/8-16 BraSS
21 2 WaSHEr LOCK 3/8
22 1 WaSHEr LOCK SPECIaL 3/8
23 1 StUD 3/8-16 X 2-1/4 BraSS
24 2 NUt HEX 5/16-18 StEEL
25 2 WaSHEr LOCK M8-5/16
26 1 WaSHEr FLat 5/16-M8 ZINC
27 1 StUD, 1/4-20 tO 5/16-18
28 1 NEUtraL CONNECtOr UL
29 2 SCrEW PPHtF #8-18 X 1/2 aB
30 1 CONtrOL PaNEL COVEr
31 1 C/PNL FaCE
ITEM QTY. DESCRIPTION
32 4 SCrEW PPHM #6-32 X 1/4 SEMS
33 1 FUSE 7.5aXBK/aGC7.5NX
34 1 HOLDEr FUSE
35 1 SWItCH rKrSPDt(ON)OFF(ON)ILLUM
36 4 NUt HEX LOCK M5-0.8 NYINS ZINC
37 1 aSSY PCB VrEG aIr COOLED 2006
38 1 aSSY PCB rV CONtrOLLEr
39 1 C/PNL FraME rV
40 2 SCrEW PPHM M4-0.7 X 16
41 2 SCrEW PPHM M3-0.5 X 12
42 1 rELaY 12V 25a SPSt
43 2 WaSHEr FLat #4 ZINC
44 2 NUt HEX LOCK M3-0.5 NY INS
45 4 SCrEW HHC M5-0.8 X 30 G8.8
46 4 SCrEW HHtt M5-0.8 X 10 BP
47 1 BLOCK 1 POSItION, 4 taB
48 2 NUt HEX LOCK M4-0.7 NY INS
49 1 CIrCt BrK 20X1 MaG 10-32 CarL (4500W)
CIrCt BrK 20X1 MaG 10-32 CarL (5500W)
CIrCt BrK 30X1 MaG 10-32 CarL (6500W)
50 1 CIrCt BrK 20X1 MaG 10-32 CarL (4500W)
CIrCt BrK 30X1 MaG 10-32 CarL (5500W)
CIrCt BrK 30X1 MaG 10-32 CarL (6500W)
51 1 EartH StraP
52 1 NYLON SPaCEr .26 X 1.00 X 1.73
53 1 B U L K H E a D
(5410-1/5412-1/5414-1 ONLY)
54 1 B a r B E D
(5410-1/5412-1/5414-1 ONLY)
55 1 P L U G S t D. P I P E ¼ C O U N t E r S I N K
(5410-1/5412-1/5414-1 ONLY)
*HARNESS NOT SHOWN
Section 9
Exploded views
a D a P t E r F I t t I N G
9 0 E L B O W ¼ X ¼
Page 69
N P t
