External View - M-system M6D Series Quick Start Manual

Pollution Degree 2
Max. operating voltage 250 V (relay output circuit)
Input or power to output: Reinforced insulation
Input to power: Basic insulation

EXTERNAL VIEW

(With the cover open)
DIMENSIONS unit: mm (inch)
WIRE INSERTION ANGLE: approx. 7°
8–M3
EURO TERMINAL
5.9 (.23)
SEN TRONIC
AG
Produkte, Support und Service
Power LED
Alarm Monitor LED
Status Indicator LED
Configurator Jack
5 6 7
1 2 3
SCREWDRIVER
INSERTION ANGLE
: approx. 40°
102 (4.02)
• When mounting, no extra space is needed between units.
Rugghölzli 2
CH - 5453 Busslingen
DIN RAIL HOOK
8
DIN RAIL
35mm wide
4
[0.5 (.02)]
Tel. +41 (0)56 222 38 18
Fax +41 (0)56 222 10 12
MODEL: M6DXAT
