Digital Watchdog DWC-MBTJUNC Quick Start Manual

Junction box for bullet cameras

Ceiling Mount Bracket Mounting Screws and Anchors (PA4x25mm, head diameter 8mm)

Waterproof Rings for Mounting Screws

Mounting Template

Camera Mounting screws (PM4x10mm, head diameter 6.6mm)

Cable Gland Connector

NOTE:

Download all your support materials and tools in one place.

Go to: http://www.digital-watchdog.com/resources

Search your product by entering the part number in the 'Search by Product' search bar. Results

for applicable part numbers will populate automatically based on the part number you enter.

Click 'Search'. All supported materials, including manuals

and quick start guide (QSGs) will appear in the results.

Tel: +1 (866) 446-3595 / (813) 888-9555

Technical Support Hours: 9:00AM – 8:00PM EST, Monday through Friday

Junction box for bullet cameras

WHAT'S IN THE BOX

DWC-MBTJUNC

Quick Start Guide

digital-watchdog.com
