Digital Watchdog DWC-V1JUNCW Quick Start Manual

Junction box for vandal dome cameras
1. Dimension & Accessories
Please check if all the camera and accessories are included in the package.
Junction Box
4.5
Outdoor Dome Camera
Quick Manual
Manual
Ver. 1.0 / 2021.05
Before installing and using the Camera, please read this manual carefully.
Be sure to keep it handy for future reference.
4-Ø 10
Camera Mounting Screws
Screws and Plastic Anchors
2. Installation
Hexagonal Wrench
Allen Wrench
NOTE: Download all your support materials and tools in one place.
1. Go to: http://www.digital-watchdog.com/resources
Search your product by entering the part number in the 'Search by Product' search bar. Results
2.
for applicable part numbers will populate automatically based on the part number you enter.
3. Click 'Search'. All supported materials, including manuals
and quick start guide (QSGs) will appear in the results.
Tel: +1 (866) 446-3595 / (813) 888-9555
Technical Support Hours: 9:00AM – 8:00PM EST, Monday through Friday
