Angle mount for micro dome cameras
Manual
Mounting Screws
NOTE:
Download all your support materials and tools in one place.
1.
Go to: http://www.digital-watchdog.com/resources
Search your product by entering the part number in the 'Search by Product' search bar. Results
2.
for applicable part numbers will populate automatically based on the part number you enter.
3.
Click 'Search'. All supported materials, including manuals
and quick start guide (QSGs) will appear in the results.
Tel: +1 (866) 446-3595 / (813) 888-9555
Technical Support Hours: 9:00AM – 8:00PM EST, Monday through Friday
Mount the angle mount on the wall.
1
80
57
WHAT'S IN THE BOX
Mount
Screw 3ea
1. Dimension & Accessories
Please check if all the camera and accessories are included in the package.
DWC-MCAM
80
57
3
Quick Setup Guide
Manual
Quick Start Guide
4-Ø 4.0
46
Mount
Screw 3ea
Manual
digital-watchdog.com
66
4-TAP
M4.0xP0.7 DP9
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Digital Watchdog DWC-MCAM
Summary of Contents for Digital Watchdog DWC-MCAM
- Page 1 Quick Start Guide 1. Dimension & Accessories Angle mount for micro dome cameras Please check if all the camera and accessories are included in the package. DWC-MCAM 4-Ø 4.0 4-TAP M4.0xP0.7 DP9 Manual e Camera ad this manual carefully. WHAT’S IN THE BOX...
