- Page 1 OPERATION MANUAL DIESEL POWERED GENERATORS YDG series YDG3700N-6BYI2 YDG3700N-6EBYI2 YDG3700V-5BYI2 YDG3700V-5EBYI2 YDG5500N-6BYI2 YDG5500N-6EBYI2 YDG5500V-5BYI2 YDG5500V-5EBYI2 original instructions...
- Page 2 We reserve the right to make any change at any time without notice. YANMAR is a registered trade- mark of YANMAR POWER TECHNOLOGY CO., LTD. in Japan, the United States and/or other countries.
-
Page 3: Yanmar Warranties
How Long is the Warranty Period? The YANMAR standard limited warranty period begins on the date of the delivery of the new YANMAR YDG diesel generator to the first retail purchaser and extends for a period of twenty-four (24) months or two-thousand (2000) engine operation hours, whichever occurs first. -
Page 4: What The Generator Owner Must Do
• Choose the Product Category from the pull down menu. • “Click” on “Search” to browse YANMAR dealer or distributor. • You may also contact YANMAR by clicking on “Contact” icon in the website heading and typing in your question or comment. -
Page 5: What Is Not Covered By This Warranty
Failure to follow the requirements for submitting a claim under this warranty may result in a waiver of all claims for damages and other relief. In no event shall YANMAR or any authorized industrial engine dealer or distributor be liable for incidental, special or consequential damages. - Page 6 At the time of purchase, YANMAR highly recommends registering the retail purchaser’s information through website http://www.yanmar.co.jp as soon as possible. If it is not possible to access the website, please contact the nearest authorized YANMAR industrial engine dealer or distributor.
- Page 7 Welcome to the world of YANMAR! • Constant efforts are made to improve the quality and performance of YANMAR products, so some YANMAR has been the leader in industrial diesel details included in this Operation Manual may engines for over 90 years. We developed the differ slightly from your generator.
- Page 8 INTRODUCTION RECORD OF OWNERSHIP Take a few moments to record the information you need when you contact YANMAR for service, parts or literature. YDG model:__________________________________________________________________________ YDG serial No.:_______________________________________________________________________ Date purchased:______________________________________________________________________ Dealer:______________________________________________________________________________ Dealer phone:________________________________________________________________________ YDG Operation Manual...
- Page 9 YANMAR ITALY s.p.a. Manufacturer: Address: Via Camperio, 9 - 20123 Milano (MI) We DECLARE hereby, under our sole responsibility That the machine named: YANMAR DIESEL GENERATOR Model: Serial Number: Year of construction: IS IN CONFORMITY With the provisions of the following European Directives:...
- Page 10 INTRODUCTION This Page Intentionally Left Blank viii YDG Operation Manual...
-
Page 11: Table Of Contents
What is Covered by this Warranty? ..........i How Long is the Warranty Period? ..........i What the Generator Owner must Do: ........... ii To Locate an Authorized YANMAR Industrial Engine Dealer or Distributor: ..................ii What YANMAR will Do: ..............ii What is not Covered by this Warranty? ........ - Page 12 TABLE OF CONTENTS Safety ....................... 1 Safety Precautions ................2 Foreseeable Misuse................10 Product Overview.................. 11 YANMAR YDG Diesel Generator Features and Applications ... 11 Component Identification ..............12 Location of Labels ................14 Safety Decals ................14 Generator Set Decal..............15 Description of Generator Set Model Number ......
- Page 13 Keep a Log of Generator Hours and Daily Checks ..... 44 YANMAR Replacement Parts............44 Tools Required ................44 Ask Your Authorized YANMAR Industrial Engine Dealer or Distributor for Help............... 44 Tightening Fasteners..............45 Tightening Torques for Standard Bolts and Nuts ......46 Periodic Maintenance Schedule............
- Page 14 TABLE OF CONTENTS This Page Intentionally Left Blank YDG Operation Manual...
-
Page 15: Safety
[ F I "Qr gtcv k qp"Ocpwcn SAFETY YANMAR considers safety of great importance and CAUTION recommends that anyone that comes into close contact with its products, such as those that install, Indicates a hazardous situation which, if not operate, maintain or service YANMAR products,... -
Page 16: Safety Precautions
• See your authorized YANMAR dealer or • Never place diesel fuel, flammable material distributor for additional training. such as oil, hay or dried grass or chemical... - Page 17 SAFETY 341 27 connected to the sockets of the gen-set, DANGER unless double insulated ones (class II), must be equipped with PE conductor in order to Electric Shock Hazard ensure equipotential bonding between the • Always have a licensed conductive structural parts of gen-set and the electrician connect the generator appliances.
- Page 18 SAFETY DANGER WARNING Fire Hazard Explosion Hazard • Never use metal pipe that carries • Avoid serious personal injury or combustible materials or gases to equipment damage. While the ground the generator. engine is running or the battery is charging, hydrogen gas is being produced and can be easily ignited.
- Page 19 SAFETY 341 27 WARNING WARNING Entanglement Hazard Electrical Hazard • Rotating parts can cause severe • Make welding repairs safely. injury or death. Never wear jewelry, unbuttoned cuffs, ties or loose fitting clothing and always tie long hair back when working near moving/rotating parts such •...
- Page 20 SAFETY WARNING WARNING Alcohol and Drug Hazard Burn Hazard Never operate the generator set • Avoid serious injury. Some of the while you are under the influence of generator set surfaces become alcohol or drugs or are feeling ill. very hot during operation and shortly after shut down.
- Page 21 Any alterations to this generator injure your eyes. set may avoid its warranty. Always use YANMAR genuine replacement parts. • Avoid personal injury. Always wear eye protection when servicing the engine or when using compressed air or high-pressure water.
- Page 22 Sparks may cause damage • The standard range of ambient temperatures for to the generator's electronic circuits the normal operation of YANMAR engines is from +5 °F (-15 °C) to +113 °F (+35 °C). Never operate the generator if it vibrates at high •...
- Page 23 SAFETY 341 27 If any indicator illuminates during engine operation, stop the engine immediately. Determine the cause and repair the problem before you continue to operate the engine. Never operate the generator if: • Engine speed changes greatly • Engine misfires often •...
-
Page 24: Foreseeable Misuse
- Any unauthorized modification of or removal of safety equipment. - Use of spare parts and accessories that are unsuitable or have not been approved by Yanmar. - Operation in flammable or hazardous environments. - Operation in closed-off or poorly ventilated rooms. -
Page 25: Product Overview
YANMAR CO., LTD. developed the LV series single cylinder, air-cooled, diesel engine for applications such as YANMAR YDG generators. YANMAR’s series of LV engines use one of the most advanced single cylinder technologies available. Yanmar YDG generators are designed to supply power to a wide variety of applications including: •... -
Page 26: Component Identification
PRODUCT OVERVIEW COMPONENT IDENTIFICATION YDG3700V-5(E)BYI2 and YDG3700N-6(E)BYI2 (Typical model) 1 – Muffler 13 – Generator set model and serial number decal 2 – Starter solenoid (only for electric version) 14 – Engine control lever 3 – Starter motor (only for electric version) 15 –... - Page 27 PRODUCT OVERVIEW 341 27 YDG5500V-5(E)BYI2 and YDG5500N-6(E)BYI2 (Typical model) 19 18 06346 -00X00 1 – Muffler 13 – Generator set model and serial number decal 2 – Starter solenoid (only for electric version) 14 – Engine control lever 3 – Starter motor (only for electric version) 15 –...
-
Page 28: Location Of Labels
PRODUCT OVERVIEW LOCATION OF LABELS Safety Decals YDG3700V-5(E)BYI2, YDG5500V-5(E)BYI2, YDG3700N-6(E)BYI2, YDG5500N-6(E)BYI2 D I E S E L F U E L ONL Y DO NOT USE GASOLINE C A U T I O N CHECK THE ENG DO NOT OPERATE D I E S E L F U E L -INE OIL (CC CLASS) THE ENGINE IN... -
Page 29: Generator Set Decal
341 27 Generator Set Decal The YDG generator set model and serial number information decal is located inside the top front frame rail. Yanmar Italy S.p.A Via Camperio, 9 - 20123 Milano, Italia Low power generating set model: Made in Italy:... -
Page 30: Generator Decal
PRODUCT OVERVIEW Generator Decal Engine Nameplate (Typical) The generator decal is located on the left side of The engine nameplate (Figure 7) is located on the the generator body. cooling shroud on the PTO side of engine above the starter (1, Figure 6). View Z Figure 6 Figure 5... -
Page 31: Function Of Major Components
PRODUCT OVERVIEW 341 27 FUNCTION OF MAJOR COMPONENTS Components Functions The air cleaner prevents airborne contaminants from entering the engine. Periodic Air cleaner replacement of the air cleaner filter element is necessary. See Periodic Maintenance Schedule on page 47 for the replacement frequency. If the engine is equipped with electric start, a charging dynamo is located Dynamo under the engine flywheel. -
Page 32: Generator Control Panel
PRODUCT OVERVIEW GENERATOR CONTROL PANEL YDG3700V-5BYI2, YDG5500V-5BYI2, YDG3700N-6BYI2, YDG5500N-6BYI2 1 – Voltage meter 4 – 12 VDC output receptacle 2 – AC circuit breaker (For 12 VDC battery charging only) (Generator main switch-circuit breaker) 5 – Grounding terminal 3 – DC circuit breaker (12 VDC output) 6 –... - Page 33 PRODUCT OVERVIEW 341 27 YDG3700V-5EBYI2, YDG5500V-5EBYI2, YDG3700N-6EBYI2, YDG5500N-6EBYI2 1 – Voltage meter 5 – 12 VDC output receptacle 2 – AC circuit breaker (For 12 VDC battery charging only) (Generator main switch-circuit breaker) 6 – Grounding terminal 3 – Engine start key switch 7 –...
-
Page 34: Air Cooled Engine
PRODUCT OVERVIEW AIR COOLED ENGINE The engine is air-cooled by a cooling fan. The cooling system consists of a fan attached to the flywheel. The fan blows air past the cooling fins on the cylinder head and cylinder, which are enclosed by shrouds that direct the air flow. -
Page 35: Engine Controls - Electric Starter
PRODUCT OVERVIEW 341 27 ENGINE CONTROLS - ELECTRIC START (3, Figure 11) - Turn the key to this position to start the engine. As soon as the engine starts, STARTER release the key and it will automatically return to the ON position. Key Switch The generator is equipped with a three position key switch - OFF, ON, and START. - Page 36 PRODUCT OVERVIEW This Page Intentionally Left Blank YDG Operation Manual...
-
Page 37: Before You Operate
BEFORE YOU YDG Operation Manual OPERATE INTRODUCTION This section of the Operation Manual describes activating a new battery, diesel fuel and engine oil specifications and how to replenish them. It also describes the proper way to connect the electrical loads to the generator and the daily engine checkout. -
Page 38: Battery
• If the engine cranking speed is so slow that the engine does not start, recharge the battery. • If the engine still will not start after charging, have your authorized YANMAR industrial engine dealer or distributor check the battery and the engine’s starting system. -
Page 39: Charging The Battery
BEFORE YOU OPERATE 341 27 Charging the Battery 1. Disconnect the battery cables from the battery. See Disconnecting and Connecting Battery Cables on page 25. 2. Clean terminals on the battery and clamps on the end of the cables. 3. Connect the positive (+) clamp from the charger to the positive (+) terminal on the battery. -
Page 40: Diesel Fuel
The table lists several worldwide specifications for diesel fuels. Always use diesel fuels recommended by YANMAR for the best engine performance, to prevent engine damage. Only use clean diesel fuel. Figure 3 3. When connecting cables to battery connect the positive (+) cable (1, Figure 4) first. - Page 41 YANMAR approves the use of bio-diesel fuels that bio-diesel fuels that have degraded as per the do not exceed a blend of 7 % (by volume) of FAME...
-
Page 42: Filling The Fuel Tank
See the SAE service grade viscosity chart Never overfill the fuel tank. (Figure 6). • YANMAR does not recommend the use of engine 4. Replace the fuel cap and hand-tighten. oil “additives”. Over-tightening the fuel cap will damage it. -
Page 43: Engine Oil Viscosity
BEFORE YOU OPERATE 341 27 Additional technical engine oil Checking Engine Oil requirements: 1. Make sure engine is level. The engine oil must be changed when the Total 2. Remove oil cap/dipstick (1, Figure 7) from Base Number (TBN) has been reduced to 2.0. TBN either location and wipe with clean cloth. -
Page 44: Adding Engine Oil
Ampere ft (m) Engine Oil Capacity load 50 (15) 100 (30) 150 (46) The following table shows engine oil capacities for YANMAR YDG generators. Dipstick Engine/generator model upper limit/lower limit Engine L70V(N) 1.11/0.69 qt generator YDG3700V(N) (1.05/0.65 L) Engine L100V(N) 1.7/1.06 qt... - Page 45 BEFORE YOU OPERATE 341 27 (1, Figure 9) shows the main AC switch on the YDG3700V-5B generator. • Attach the ground wire to the grounding point (1, Figure 8). You must supply the ground wire YDG3700V-5B, YDG5500V-5B and grounding point. These are not supplied with the generator.
-
Page 46: Selecting The Proper Load
1100 watts 3 = 3300 watts: Starting Watts Different manufacturers of certain products may require more wattage. See your authorized YANMAR industrial engine dealer or distributor with any questions. When figuring the generator load for motors, you must use the Starting Watts and not the Running Decide what electrical load your generator can Watts. - Page 47 BEFORE YOU OPERATE 341 27 Typical electrical appliance wattages Application/equipment Running/rated watts Starting/surge watts Light bulb (100 W) AM/FM radio 50 - 200 50 - 200 CB radio Television 300 - 400 300 - 400 Microwave oven 1000 Air conditioner (12,000 BTU) 3250 5000 Furnace fan (1/3 hp blower motor)
-
Page 48: Initial Engine Start Up
DAILY CHECKS 3. Check for damaged or missing parts. Before you operate, make sure the YANMAR YDG generator is in good operating condition. Make sure 4. Check for loose, missing or damaged fasteners. you check the following items before you start your 5. -
Page 49: Generator Operation
GENERATOR [ F I "Qr gtcv k qp"Ocpwcn OPERATION INTRODUCTION This section of the Operation Manual describes the procedures for starting the generator, checking generator performance during operation and shutting the generator down. Before performing any storage procedures within this section, review the Safety section on page 1. YDG Operation Manual... -
Page 50: Starting The Generator
GENERATOR OPERATION STARTING THE GENERATOR 5. Move the engine control lever (1, Figure 24) to the RUN position (2, Figure 24). CAUTION During manual starting operation, a knockback from recoil could happen, with risk of serious injuries, if proper starting procedure is not carried on. -
Page 51: Electric Start
GENERATOR OPERATION 341 27 Electric Start Use the following procedure to start the engine using the electric starter. 1. Make sure you follow the procedures stated in Daily Checks on page 34. 2. Fill fuel tank with clean, fresh fuel. See Filling the Fuel Tank on page 28. -
Page 52: Checking The Generator Set During Operation
2. Check for abnormal sounds or vibration. If the abnormal sounds or vibration cannot be resolved, shut down the engine and have the necessary repairs performed. Contact your authorized YANMAR industrial engine dealer or START distributor. 3. Check for white or black smoke from the STARTER exhaust system. -
Page 53: Low Load Operation
Avoid low load operation as much as possible. Always operate at 1/4 load or greater when possible. For maximum engine life, YANMAR recommends that when shutting the engine down, you allow the Always run the engine at full speed. Never run engine to run, without load, for five minutes. -
Page 54: Ac Application
GENERATOR OPERATION AC APPLICATION 2. Plug in the appliance. 1. Start the engine. See Starting the Generator on CAUTION page 36. Once the engine is started, make sure Always ensure that all appliances are in good the voltage meter (1, Figure 29) or working order before connecting them to the (1, Figure 30) indicates the voltage. -
Page 55: Dc Application
GENERATOR OPERATION 341 27 DC APPLICATION YDG3700V-5EB, YDG5500V-5EB YDG3700N-6EB, YDG5500N-6EB DC terminals should be used for charging 12 VDC batteries only. Using the DC terminals for any other type of 12 VDC appliance may cause damage to generator and appliance. The DC terminal (1, Figure 31) may be used for charging 12 volt automotive-type batteries only. - Page 56 GENERATOR OPERATION This Page Intentionally Left Blank YDG Operation Manual...
-
Page 57: Periodic Maintenance
PERIODIC YDG Operation Manual MAINTENANCE INTRODUCTION This section of the Operation Manual describes the procedures for proper care and maintenance of the generator set. Before performing any storage procedures within this section, review the Safety section on page 1. YDG Operation Manual... -
Page 58: Precautions
See YANMAR Replacement Parts YANMAR Limited Warranty on page i. Consult Yanmar recommends that you use genuine your authorized YANMAR industrial engine YANMAR parts when replacement parts are dealer or distributor for assistance when needed. -
Page 59: Tightening Fasteners
PERIODIC MAINTENANCE 341 27 Tightening Fasteners CAUTION Use the correct amount of torque when you tighten Before starting any maintenance procedure, fasteners on the machine. Applying excessive ensure that the engine is cold and the speed torque may damage the fastener or component and control lever is set on STOP position. -
Page 60: Tightening Torques For Standard Bolts And Nuts
PERIODIC MAINTENANCE TIGHTENING TORQUES FOR STANDARD BOLTS AND NUTS Use the correct amount of torque when you tighten fasteners on the machine. Applying excessive torque may damage the fastener or component and not enough torque may cause a leak or component failure. The tightening torque in the following chart should be applied only to the bolts with a “7”... -
Page 61: Periodic Maintenance Schedule
The following should be treated only as a general guideline. : Check : Replace : Contact your authorized YANMAR industrial engine dealer or distributor for these maintenance services Periodic maintenance interval Every Every Every Every... - Page 62 PERIODIC MAINTENANCE : Check : Replace : Contact your authorized YANMAR industrial engine dealer or distributor for these maintenance services Periodic maintenance interval Every Every Every Every Every System Check item Daily Every 1000 1500 2000 50 hours...
-
Page 63: Periodic Maintenance Procedures
See Checking Engine Oil on page 29. Check for engine oil leakage Before you operate the engine check for any engine oil leaks. If you discover any engine oil leaks, contact your authorized YANMAR industrial engine dealer or distributor for service. YDG Operation Manual... - Page 64 Avoid being burned by contact with hot engine Always use a piece of wood or cardboard. Have oil. your authorized YANMAR dealer or distributor repair the damage. Check for fuel leakage ...
- Page 65 PERIODIC MAINTENANCE 341 27 After Initial 50 Hours of Operation Perform the following maintenance after the initial 50 hours of operation. • Replace engine oil • Clean/inspect engine oil filter Replace engine oil The engine oil on a new engine becomes Figure 32 contaminated from the initial break-in of internal parts.
- Page 66 PERIODIC MAINTENANCE 8. Dispose of used oil properly. Never overfill. Overfilling may result in white exhaust smoke, engine overspeed or internal Always be environmentally responsible. Follow damage. the guidelines of the governmental agencies for the proper disposal of hazardous materials such as engine oil, diesel fuel and engine coolant.
- Page 67 PERIODIC MAINTENANCE 341 27 Clean/inspect engine oil filter Never overfill. Overfilling may result in white exhaust smoke, engine overspeed, or internal damage. 9. Warm up the engine by running it for five minutes and check for any engine oil leaks. 10.
- Page 68 PERIODIC MAINTENANCE Every 50 Hours of Operation Every 200 Hours of Operation Perform the following maintenance every 50 hours Perform the following maintenance every 200 hours of operation. of operation. • Clean inlet fuel screen • Clean air cleaner element •...
- Page 69 8. Clean the inside of the air cleaner cover limit screw. This may impair the safety and (2, Figure 36). performance of the machine and shorten its life. If adjustment is ever required, contact your authorized YANMAR industrial engine dealer or distributor. YDG Operation Manual...
- Page 70 Always be environmentally responsible. Follow indicated or adjustment is needed, see your the guidelines of the governmental agencies for authorized YANMAR industrial engine dealer or the proper disposal of hazardous materials such distributor for service. as engine oil, diesel fuel and engine coolant.
- Page 71 7. Install a new filter into the tank using a new noisily, resulting in poor engine performance and O-ring (7, Figure 38). engine damage. See your authorized YANMAR 8. Reinstall the three fuel filter nuts and tighten industrial engine dealer or distributor for this securely.
- Page 72 AVR to ensure generator performance is maintained at an • Check compression optimum. See your authorized YANMAR industrial • Check engine/frame dampers for wear, engine dealer or distributor for this service. damage and tightness Check main and sub-frames for damage ...
- Page 73 2000 hours of engine operation, whichever comes performance. See your authorized YANMAR first, even if the engine has been out of service. industrial engine dealer or distributor for this Rubberized fuel lines tend to dry out and become service.
-
Page 74: Dismantling
PERIODIC MAINTENANCE PERIODIC MAINTENANCE PROCEDURES Dismantling The user is in charge of all the operations that must be done when the generator’s life is over and must follows laws and local regulation. Dismantling operations must be done by qualified technicians. YDG Operation Manual... -
Page 75: Troubleshooting
If your generator does not operate properly, refer to • Type of diesel fuel the Troubleshooting Chart on page 62 or see your authorized YANMAR industrial engine dealer or • Type of engine oil distributor. You can refer to Troubleshooting Chart •... -
Page 76: Troubleshooting Chart
Drain the fuel tank and Clogged fuel filter Replace fuel filter replace outlet fuel filter on page 56 Poor fuel injection – See authorized YANMAR Compressed air leakage from industrial engine dealer or – intake/exhaust valves distributor Faulty engine stop solenoid –... - Page 77 Turn main switch on page 30 Equipment incorrectly connected Connect the equipment correctly – to generator Defective AVR – See authorized YANMAR industrial engine dealer or Winding short circulated or loose – distributor connections Electrical load too high Reduce electrical load –...
-
Page 78: Electrical Wiring Diagram
TROUBLESHOOTING ELECTRICAL WIRING DIAGRAM YDG3700V-5B, YDG5500V-5B, YDG3700N-6B, YDG5500N-6B STOP SOLENOID ALTERNATOR RELAY PRESSURE FREQ. JUMPER SWITCH VOLTAGE TRIMMER AC COIL AC COIL TERMINALS COIL DC BREAKER ROTOR COIL COIL VOLTMETER BREAKER Black Blue YE/GR EARTH Brown TERMINAL Grey YE/GR YE/GR Yellow/Green YE/GR... - Page 79 STOP SOLENOID SWITCH ALTERNATOR STARTER RELAY GR/WH RECTIFIER BL/RE PRESSURE FREQ. JUMPER SWITCH VOLTAGE TRIMMER GR/WH AC COIL AC COIL BATTERY COIL TERMINAL DC BREAKER ROTOR COIL GR/WH COIL CHARGE COIL VOLTMETER GR/WH AC BREAKER GR/WH Black Yellow Green KEY SWITCH OPERATION DIAGRAM Blue IG BAT ST YE/GR...
-
Page 80: Electrical Equipment Connection
TROUBLESHOOTING ELECTRICAL EQUIPMENTS’ CONNECTIONS (under “Electrical Separation” condition) THE GENSET MUST BE PLACED ON A NON CONDUCTIVE SURFACE (SEE ASIDE FIGURE) INSULATING MATERIAL (I.E. WOOD, RUBBER, ETC.) - x2 CLASS II EQUIPMENT; - NO GROUNDING; - x1 CLASS I EQUIPMENT; - NO GROUNDING;... - Page 81 TROUBLESHOOTING 341 27 YDG Operation Manual...
- Page 82 TROUBLESHOOTING This Page Intentionally Left Blank YDG Operation Manual...
-
Page 83: Long-Term Storage
LONG-TERM [ F I "Qr gtcv k qp"Ocpwcn STORAGE INTRODUCTION This section of the Operation Manual describes the procedures necessary to place the generator into long-term storage (three months or longer) and how to prepare it for operation. YDG Operation Manual... -
Page 84: Before You Place The Generator In Long-Term Storage
See Replace engine Always use a piece of wood or cardboard. oil on page 51. Have your authorized YANMAR dealer or distributor repair the damage. 4. Push the decompression lever down and hold it while slowly pulling the recoil starter two or three times. -
Page 85: Specifications
[ F I "Qr gtcv k qp"Ocpwcn SPECIFICATIONS PRINCIPAL SPECIFICATIONS Generator Model YDG3700N-6(E)BYI2 YDG5500N-6(E)BYI2 Type Revolving field-type AC generator (with brush) Excitation Self-excited Voltage regulation Automatic Voltage Regulator (AVR) Hz ±1% (±2% on transient) Frequency 3.4 kVA 5.2 kVA Rated output DC12 V - 10 A V ±2%... - Page 86 SPECIFICATIONS Model YDG3700V-5(E)BYI2 YDG5500V-5(E)BYI2 Type Revolving field-type AC generator (with brush) Excitation Self-excited Voltage regulation Automatic Voltage Regulator (AVR) Hz ±1% (±2% on transient) Frequency 3.0 kVA 4.5 kVA Rated output DC12 V - 10 A V ±2% Rated voltage Rated current 13 A 19.6 A...
- Page 87 SPECIFICATIONS 341 27 Engine Engine model L70N6-G(E)YDG2 L100N6-G(E)YDG2 (Generator) YDG3700N-6(E)B YDG5500N-6(E)B Type 4-stroke, vertical cylinder, air-cooled diesel engine Combustion system Direct injection No. of cylinders Bore × stroke 78 × 67 mm 86 × 75 mm Displacement 0.320 L 0.435 L Compression ratio RPM (min...
- Page 88 750 mm Hg), relative humidity 30 % • Fuel temperature at fuel injector pump inlet: 104 °F (40 °C) • With cooling fan, air cleaner, muffler: YANMAR standard • After engine break-in period. Output allowable deviation: ±3 % • 1 PS = 0.7355 kW •...
- Page 89 SPECIFICATIONS 341 27 Engine model L70V5-G(E)YDG2 L100V5-G(E)YDG2 (Generator) YDG3700V-5(E)B YDG5500V-5(E)B Type 4-stroke, vertical cylinder, air-cooled diesel engine Combustion system Direct injection No. of cylinders Bore × stroke 78 × 67 mm 86 × 75 mm Displacement 0.320 L 0.435 L Compression ratio 21.1 21.2...
- Page 90 750 mm Hg), relative humidity 30 % • Fuel temperature at fuel injector pump inlet: 104 °F (40 °C) • With cooling fan, air cleaner, muffler: YANMAR standard • After engine break-in period. Output allowable deviation: ±3 % • 1 PS = 0.7355 kW •...
- Page 91 1101-1106 Gopher Center Building, No.757 Meng Zi Road Shanghai, China P.R.C. 200023 TEL: +86-21-2312-0688 FAX: +86-21-6880-8682 http://www.yanmar-china.com/cn/ Yanmar South America Industria De Maquinas Ltda. Av. Presidente Vargas 1400, Indaiatuba, S.P., Brazil, CEP: 13338-901 TEL: +55-19-3801-9224 FAX: +55-19-3875-3899, 2241 https://www.yanmar.com/br/ As of December 31, 2020...
- Page 92 YANMAR ITALY S.p.A YIYDG-EN0000 http://www.yanmaritaly.it 2021.10...
