DVD Player/ Video Cassette Recorder
NV-VP60GL
NV-VP60GC
NV-VP60GCS
R4-MECHANISM
© 2006 Matsushita Electric Industrial Co., Ltd. All
rights
reserved.
distribution is a violation of law.
ORDER NO. MAV0604001CE
Unauthorized
copying
and

Advertisement

Table of Contents
loading

Related Manuals for Panasonic NV-VP60GL

Summary of Contents for Panasonic NV-VP60GL

  • Page 1 All manuals and user guides at all-guides.com ORDER NO. MAV0604001CE DVD Player/ Video Cassette Recorder NV-VP60GL NV-VP60GC NV-VP60GCS R4-MECHANISM © 2006 Matsushita Electric Industrial Co., Ltd. All rights reserved. Unauthorized copying distribution is a violation of law.

  • Page 2: Table Of Contents

    NV-VP60GL / NV-VP60GC / NV-VP60GCS All manuals and user guides at all-guides.com CONTENTS Page Page 1 INTRODUCTION 5 PREVENTION OF STATIC ELECTRICITY DISCHARGE 1.1. INTRODUCTION 5.1. Grounding for electrostatic breakdown prevention 1.2. ABOUT LEAD FREE SOLDER (PbF) 5.2. Handling Precautions for Traverse Unit (Optical Pickup) 7...
  • Page 3 NV-VP60GL / NV-VP60GC / NV-VP60GCS All manuals and user guides at all-guides.com 6.5. SERVICE CAUTION-2 15 BLOCK DIAGRAMS 6.6. SELF-DIAGNOSIS & SERVICE INFORMATION DISPLAY 15.1. POWER BLOCK DIAGRAM 15.2. SYSTEM CONTROL & SERVO BLOCK DIAGRAM 6.7. INTRODUCTION OF VIDEO HEAD CLEANING 15.3.

  • Page 4: Introduction

    NV-VP60GL / NV-VP60GC / NV-VP60GCS All manuals and user guides at all-guides.com 1 INTRODUCTION 1.1. INTRODUCTION This service manual contains technical information which will allow service personnel to understand and service this model. If the circuit is changed or modified, this information will be followed by supplementary service manual to be filed with original service manual.

  • Page 5: Safety Precautions

    NV-VP60GL / NV-VP60GC / NV-VP60GCS All manuals and user guides at all-guides.com 2 SAFETY PRECAUTIONS 2.1. GENERAL GUIDELINES 1. When servicing, observe the original lead dress. If a short circuit is found, replace all parts which have been overheated or damaged by the short circuit.

  • Page 6: Precaution Of Laser Diode

    NV-VP60GL / NV-VP60GC / NV-VP60GCS All manuals and user guides at all-guides.com 8. Minimize bodily motions when handling unpackaged replacement ES devices. (Otherwise harmless motion such as the brushing together of your clothes fabric or the lifting of your foot from a carpeted floor can generate static electricity (ESD) sufficient to damage an ES device).

  • Page 7: Prevention Of Static Electricity Discharge

    NV-VP60GL / NV-VP60GC / NV-VP60GCS All manuals and user guides at all-guides.com 5 PREVENTION OF STATIC ELECTRICITY DISCHARGE The laser diode in the traverse unit (optical pickup) may break down due to static electricity of clothes or human body. Use due caution to electrostatic break down when servicing and handling the laser diode.

  • Page 8: General Description

    NV-VP60GL / NV-VP60GC / NV-VP60GCS All manuals and user guides at all-guides.com 6 GENERAL DESCRIPTION 6.1. OPERATING INSTRUCTIONS...
  • Page 9 NV-VP60GL / NV-VP60GC / NV-VP60GCS All manuals and user guides at all-guides.com...

  • Page 10: Service Caution-1

    NV-VP60GL / NV-VP60GC / NV-VP60GCS All manuals and user guides at all-guides.com 6.2. SERVICE CAUTION-1 6.2.1. REPLACING PROCEDURE [IC6001] When the Microprocessor IC6001 and/or Back-up battery B7751 are replaced, read the following procedure carefully and [1.PREPARATION] proceed it. Before replacing IC6001: [REASONS] 1.
  • Page 11 NV-VP60GL / NV-VP60GC / NV-VP60GCS All manuals and user guides at all-guides.com STEP4.LINE-IN SETTING & ACTIVATE PLUG-IN A.T.P. 1. Press Channel down keys simultaneously for more than 3 seconds until the channel on the unit’s display changes to 1, under the condition of the no tape is in the unit.

  • Page 12: Caution For Ac Mains Lead (Nv-Vp60Gc)

    NV-VP60GL / NV-VP60GC / NV-VP60GCS All manuals and user guides at all-guides.com 6.3. CAUTION FOR AC MAINS LEAD (NV-VP60GC) For your safety please read the following text carefully How to replace the Fuse This appliance is supplied with a moulded three pin mains plug ¡There are two types of the AC Mains Lead assembly:...

  • Page 13: How To Replace The Lithium Battery

    NV-VP60GL / NV-VP60GC / NV-VP60GCS All manuals and user guides at all-guides.com 6.4. HOW TO REPLACE THE LITHIUM BATTERY 6.4.1. GENERAL DESCRIPTION 2. Unsolder the Lithium Battery: B7751 and then replace it with a new one (See Fig. B1). There is a RAM in the IC6001, which is backing up the following...

  • Page 14: Service Caution-2

    NV-VP60GL / NV-VP60GC / NV-VP60GCS All manuals and user guides at all-guides.com 6.5. SERVICE CAUTION-2 6.5.2. REMOVAL OF CASSETTE TAPE When the cassette tape could not be uninstalled from an 6.5.1. CAUTION FOR AUTO TUNING electrical malfunction, There are 2 ways to remove a cassette PROCEDURE tape.
  • Page 15 NV-VP60GL / NV-VP60GC / NV-VP60GCS All manuals and user guides at all-guides.com c. Stop unloading just before unloading would be completed as shown in Fig. S2. Fig. S5 f. Then unload again to remove the cassette tape as shown in Fig. S6.
  • Page 16 NV-VP60GL / NV-VP60GC / NV-VP60GCS All manuals and user guides at all-guides.com 6.5.3. CYLINDER UNIT REPLACEMENT c. Rotate the Main Cam Gear counter-clockwise (Fig. S8) NOTE: until just before the unloading would be completed as Since securing of RT gap is impossible to be done outside shown in Fig.

  • Page 17: Self-Diagnosis & Service Information Display

    NV-VP60GL / NV-VP60GC / NV-VP60GCS All manuals and user guides at all-guides.com 6.5.4. ATTENTION FOR REPLACING THE NOTE: CYLINDER UNIT 1. When removing the FPC HOLDER, push stopper portion of the FPC HOLDER with a small minus screw CAUTION: driver and so on. And then pay attention for not to Handle the Cylinder Flexble Card with care.

  • Page 18: Introduction Of Video Head Cleaning Cassette(Polishing Type)

    6.7. INTRODUCTION OF VIDEO HEAD CLEANING CASSETTE (POLISHING TYPE) 1. We are pleased to introduce Panasonic Video Head Cleaning Cassette, VFK0923FT [for service purposes] and VFK0923FSE [ for end users] for all VHS/S-VHS VCP and VCR. 2. These cleaning cassettes are exclusively to remove hard and sticky clogging on video heads.

  • Page 19: Disassembling The Casing Parts And Circuit Boards

    NV-VP60GL / NV-VP60GC / NV-VP60GCS All manuals and user guides at all-guides.com 7 DISASSEMBLING THE CASING PARTS AND CIRCUIT BOARDS 7.1. DISASSEMBLY FLOW CHART This flow chart indicates disassembly steps of the casing parts and the circuit boards in order to find the necessary items for servicing.

  • Page 20: Detail Of The Disassembly

    NV-VP60GL / NV-VP60GC / NV-VP60GCS All manuals and user guides at all-guides.com 7.3. DETAIL OF THE 3. REMOVAL OF THE BACK PANEL DISASSEMBLY Remove 4 Screws (D) 1. REMOVAL OF THE PANEL Remove Screw (E) Release 2 Bosses (F) Remove...
  • Page 21 NV-VP60GL / NV-VP60GC / NV-VP60GCS All manuals and user guides at all-guides.com 5. REMOVAL OF THE DVD MECHANISM UNIT 6. REMOVAL OF THE VCR MECHANISM UNIT Remove 4 Screws (K) Remove Screw (L) Remove 3 Screws (M) Remove Screw (N)
  • Page 22 NV-VP60GL / NV-VP60GC / NV-VP60GCS All manuals and user guides at all-guides.com 7. REMOVAL OF THE DVD MODULE C.B.A. 9. REMOVAL OF THE POWER C.B.A. Remove Screw (P) Remove 2 Screws (T) Unlock Tab (Q) Unlock 2 Tabs (U) Unlock Locking Portion (R) Fig.

  • Page 23: Service Position

    NV-VP60GL / NV-VP60GC / NV-VP60GCS All manuals and user guides at all-guides.com 7.4. SERVICE POSITION 7.4.3. SERVICE POSITION OF DVD MODULE C.B.A. & DVD 7.4.1. SERVICE POSITION OF MAIN MECHANISM C.B.A. 7.4.2. SERVICE POSITION OF POWER C.B.A. 7.4.4. EXTENSION CABLE LIST...

  • Page 24: Assembling And Disassembling The Mechanism Unit

    NV-VP60GL / NV-VP60GC / NV-VP60GCS All manuals and user guides at all-guides.com 8 ASSEMBLING AND 8.2. Motor C.B.A. DISASSEMBLING THE 1. Remove the solders. MECHANISM UNIT 8.1. Disassembly Procedure 8.3. Clamp Plate Unit 1. Spread the stopper by hand to slide the tabs and remove...

  • Page 25: Tray

    NV-VP60GL / NV-VP60GC / NV-VP60GCS All manuals and user guides at all-guides.com 8.4. Tray 1. Lift the tray. <Precautions in reassembling the tray> lReassemble the tray so that it is in the backmost position. 1. Turn traverse gear until cam gear leaver comes to the lever adjusting position at the end of mechanical chassis unit.

  • Page 26: Traverse Block

    NV-VP60GL / NV-VP60GC / NV-VP60GCS All manuals and user guides at all-guides.com 8.5. Traverse Block b. Inch the tray frontward until convex phase and 1. Lift the traverse block while spreading the hook of the concave phase mate. mechanical chassis unit.

  • Page 27: Traverse Gear

    NV-VP60GL / NV-VP60GC / NV-VP60GCS All manuals and user guides at all-guides.com 8.6. Traverse Gear 1. Disengage the tabs from the traverse gear. 2. Remove the traverse gear B. <Precautions in reassembling the traverse block> lTake the following precautions when reassembling the traverse block.

  • Page 28: Optical Pickup Unit

    NV-VP60GL / NV-VP60GC / NV-VP60GCS All manuals and user guides at all-guides.com 8.7. Optical Pickup Unit 8.7.1. Precautions in optical pickup replacement 1. Unscrew the screws. 2. Remove the spring holders and the springs. The optical pickup can be damaged by static electricity from your body.
  • Page 29 NV-VP60GL / NV-VP60GC / NV-VP60GCS All manuals and user guides at all-guides.com 8.7.2. Disassembling the Optical Pickup Unit 1. Remove the 2 screws A and remove the TRV feed rack. 2. Remove the screw B and remove the FFC fixed plate and the Terminal FPC.
  • Page 30 NV-VP60GL / NV-VP60GC / NV-VP60GCS All manuals and user guides at all-guides.com 3. Install the optical pickup unit, spring, drive shaft, guide shaft, rubber cushion, and spring holder on the traverse block. Fig. 3 Cautions to be taken when assembling the unit: Install the pickup unit so that it is located at the rear end of the guide shaft.)
  • Page 31 NV-VP60GL / NV-VP60GC / NV-VP60GCS All manuals and user guides at all-guides.com 4. Cut the antistatic flexible sheet for the optical pickup unit. Fig. 4...

  • Page 32: Disassembling The Middle Chassis

    NV-VP60GL / NV-VP60GC / NV-VP60GCS All manuals and user guides at all-guides.com 8.8. Disassembling the Middle 8.10. Disassembling the Spindle Chassis Motor Unit 1. Remove the holder pins. 1. Remove the floating rubbers. 2. Remove the tab. 3. It lifts while pulling it in the direction of the arrow.

  • Page 33: Self-Diagnosis Function And Service Modes

    NV-VP60GL / NV-VP60GC / NV-VP60GCS All manuals and user guides at all-guides.com 9 SELF-DIAGNOSIS FUNCTION AND SERVICE MODES 9.1. Optical Pickup Breakdown Diagnosis The optical pickup self-diagnosis function and tilt adjustment check function have been included in this unit. When repairing, use the following procedure for effective Self-diagnosis and tilt adjustment.Be sure to use the self-diagnosis function before replacing...

  • Page 34: Service Mode Table

    NV-VP60GL / NV-VP60GC / NV-VP60GCS All manuals and user guides at all-guides.com 9.2. Service Mode Table 1 The service modes can be activated by pressing various button combination on the player and remote control unit. Player buttons Remote control unit buttons...

  • Page 35: Last Error Code Saved During No Play

    NV-VP60GL / NV-VP60GC / NV-VP60GCS All manuals and user guides at all-guides.com Error Code Error Content Additional error explanation Defect 1 Defect 2 Defect 3 Defect 4 F610 ODC abnormality No permission for command execution DV3.2 (IC8001) F611 6626 QCODE don’t...

  • Page 36: Service Mode Table

    NV-VP60GL / NV-VP60GC / NV-VP60GCS All manuals and user guides at all-guides.com 9.5. Service mode table 2 Pressing various button combinations on the player and remote control unit can activate the service modes.
  • Page 37 NV-VP60GL / NV-VP60GC / NV-VP60GCS All manuals and user guides at all-guides.com...

  • Page 38: Vcr Self-Diagnosis Result Display

    NV-VP60GL / NV-VP60GC / NV-VP60GCS All manuals and user guides at all-guides.com 9.6. VCR Self-Diagnosis Result Display Refer to the Service Manual for R4-Mechanism CHassis. (Order No.: VRD0202010C8) 9.7. Handling After Completing Repairs Use the following procedure after completing repairs.

  • Page 39: Service Precautions

    NV-VP60GL / NV-VP60GC / NV-VP60GCS All manuals and user guides at all-guides.com 10 SERVICE PRECAUTIONS 10.1. Recovery after the DVD player is repaired · When FROM and/or DVD module P.C.B. has been replaced, carry out the recovering process to optimize the drive.

  • Page 40: Adjustment Procedures

    NV-VP60GL / NV-VP60GC / NV-VP60GCS All manuals and user guides at all-guides.com 11 ADJUSTMENT PROCEDURES 11.1. Service Tools and Equipment Application Name Number Tilt adjustment DVD test disc DVDR-S15 or DVDT-S01 Hex wrench Available on sales route. Inspection Extension cable (MAIN C.B.A. to Power C.B.A.) VFK1729 Extension cable (DVD Module C.B.A.

  • Page 41: Dvd Optical Adjustment

    NV-VP60GL / NV-VP60GC / NV-VP60GCS All manuals and user guides at all-guides.com 11.4. DVD Optical adjustment 11.4.1. Optical pickup tilt adjustment Measurement point Adjustment point Mode Disc Tangential adjustment screw T01 (inner periphery) play DVDR-S15 or DVDT-S01 Tilt adjustment screw...
  • Page 42 NV-VP60GL / NV-VP60GC / NV-VP60GCS All manuals and user guides at all-guides.com 11.4.1.3. Check after adjustment Play test disc or any other disc to make sure there is no picture degradation in the inner, middle and outer peripheries, and no audio skipping.

  • Page 43: Vcr Electrical Adjustment Procedures

    NV-VP60GL / NV-VP60GC / NV-VP60GCS All manuals and user guides at all-guides.com 11.5. VCR ELECTRICAL ADJUSTMENT PROCEDURES This section provides complete adjustment procedures PG SHIFTER AUTOMATIC ADJUSTMENT SELF-DIAGNOSIS required for electric circuits of VCR. INDICATION NG1 in the PG Shifter Automatic Adjustment 11.5.1.

  • Page 44: Abbreviations

    NV-VP60GL / NV-VP60GC / NV-VP60GCS All manuals and user guides at all-guides.com 12 ABBREVIATIONS [DVD SECTION] INITIAL/LOGO ABBREVIATIONS INITIAL/LOGO ABBREVIATIONS A0~UP ADDRESS ERROR TORQUE CONTROL ACLK AUDIO CLOCK ERROR TORQUE CONTROL AD0~UP ADDRESS BUS REFERENCE ADATA AUDIO PES PACKET DATA...
  • Page 45 NV-VP60GL / NV-VP60GC / NV-VP60GCS All manuals and user guides at all-guides.com INITIAL/LOGO ABBREVIATIONS INITIAL/LOGO ABBREVIATIONS READ ENABLE VBLANK V BLANKING RFENV RF ENVELOPE COLLECTOR POWER SUPPLY RF PHASE DIFFERENCE OUTPUT VOLTAGE (CD-ROM) REGISTER SELECT VCDCONT VIDEO CD CONTROL (TRACKING...
  • Page 46 NV-VP60GL / NV-VP60GC / NV-VP60GCS All manuals and user guides at all-guides.com [VCR SECTION] 4.43 NTSC L 443NT [L] BILINGUAL BILINGUAL L A. COMP AUDIO COMPONENT SIGNAL BIL [L] BILINGUAL H BIL. [H] A. COMPO AUDIO COMPONENT SIGNAL BILINGUAL L...
  • Page 47 NV-VP60GL / NV-VP60GC / NV-VP60GCS All manuals and user guides at all-guides.com CYL GND CYLINDER GND FULL. E. 12V FULL ERASE 12V DELAIED FM RECORDING H D.F.M. REC [H] GND (ANALOG) GND [A] DELAIED FM RECORDING L D. FM REC [L]...
  • Page 48 NV-VP60GL / NV-VP60GC / NV-VP60GCS All manuals and user guides at all-guides.com POWER OFF H LINE IN [R] LINE INPUT (R) P-OFF [H] POWER OFF L LINE OUT [L] LINE OUTPUT (L) P-OFF [L] LINE OUTPUT (R) LINE OUT [R] P.
  • Page 49 NV-VP60GL / NV-VP60GC / NV-VP60GCS All manuals and user guides at all-guides.com SYSTEM CONTROL 5V RF OUT RF OUTPUT SYSCON 5V SYSTEM SW RF Y RF LUMINANCE SIGNAL SYSTEM RF LUMINANCE SIGNAL INPUT TAKE-UP PHOTO TRANSISTOR RF. Y. IN T-PHOTO RF.

  • Page 50: Input/ Output Chart 13.1. Input/ Output Chart For Ic6001

    NV-VP60GL / NV-VP60GC / NV-VP60GCS All manuals and user guides at all-guides.com 13 INPUT/ OUTPUT CHART 13.1. INPUT/ OUTPUT CHART FOR IC6001 Reset/ No. Terminal Name Description P. OFF failure Releas - Unused terminal. Model setting terminal. CODE1 AD Input terminal 1.
  • Page 51 NV-VP60GL / NV-VP60GC / NV-VP60GCS All manuals and user guides at all-guides.com Linear Audio record timing terminal When recording linear audio, take (H) as output Output mode: REC,(ADUB,AV-INSERT) 26 BIAS (H) When start recording, set BIAS(H), R.REC(H) output range 140~160msec recording time When finish recording, BIAS(L) = Output, D.REC(L) Time = 0 ~ 20 msec...
  • Page 52 NV-VP60GL / NV-VP60GC / NV-VP60GCS All manuals and user guides at all-guides.com 53 5V (OSD) - OSD circuit Power supply Terminal 54 HLF Slicer LPF Connection Terminal 55 V HOLD Capacitor Connection terminal of Slicer Ref Voltage Generator Circuit 56 CV IN (EDS) Slicer Composite Video Signal Input Terminal.
  • Page 53 NV-VP60GL / NV-VP60GC / NV-VP60GCS All manuals and user guides at all-guides.com Capstan motor control voltage supply terminal High High 76 CAP ET When higher than Drive Reference Voltage: Accelerated PWM= PWM= When lower than Drive Reference Voltage : Current off...

  • Page 54: Waveform Table & Voltage Chart

    NV-VP60GL / NV-VP60GC / NV-VP60GCS All manuals and user guides at all-guides.com 14 WAVEFORM TABLE & VOLTAGE CHART 14.1. WAVEFORM TABLE T1150-11 STOP T1150-15 STOP T1150-2 STOP T1150-9 STOP T1150-10 STOP 15Vp-p (5usec.div.) 10Vp-p (5usec.div.) 3.8Vp-p (2msec.div.) 100Vp-p (5usec.div.) 40Vp-p (5usec.div.)
  • Page 55 NV-VP60GL / NV-VP60GC / NV-VP60GCS All manuals and user guides at all-guides.com IC33501-14 PLAY (DVD) IC33501-16 PLAY (DVD) IC33501-18 PLAY (DVD) IC33501-21 PLAY (DVD) IC33501-24 PLAY (DVD) 0.48Vp-p (20µsec.div.) 0.48Vp-p (20µsec.div.) 1.0Vp-p (20µsec.div.) 1.0Vp-p (20µsec.div.) 2.0Vp-p (20µsec.div.) IC34301-1,7 PLAY (DVD)

  • Page 56: Voltage Chart

    NV-VP60GL / NV-VP60GC / NV-VP60GCS All manuals and user guides at all-guides.com 14.2. VOLTAGE CHART SYSTEM CONTROL & SERVO ICs DC VOLTAGE CHART (SP MODE) IC1511 IC1512 Ref. No. MODE STOP PLAY Ref. No. IC2501 MODE STOP 12.2 16.2 PLAY 12.2...

  • Page 57: Block Diagrams

    All manuals and user guides at all-guides.com NV-VP60GL / NV-VP60GC / NV-VP60GCS 15 BLOCK DIAGRAMS 15.1. POWER BLOCK DIAGRAM Q36330, QR1361 5V SW REG. LED 5V TO TIMER TL1034 P34301 P8003 POWER TO DVD QR1363 MODULE TRANSFORMER IC1290 T1150 P.SAVE FROM IC36001 SW REG.

  • Page 58: System Control & Servo Block Diagram

    All manuals and user guides at all-guides.com NV-VP60GL / NV-VP60GC / NV-VP60GCS 15.2. SYSTEM CONTROL & SERVO BLOCK DIAGRAM IC0201 IC6001 IC36001 (CAPSTAN MOTOR DRIVE) (SYSTEM CONTROL & SERVO) (SUB CPU) UNREG DP37501 P0201 P2571 CAPSTAN TL2502 (TIMER DISPLAY) MOTOR...

  • Page 59: Luminance & Chrominance Block Diagram

    All manuals and user guides at all-guides.com NV-VP60GL / NV-VP60GC / NV-VP60GCS 15.3. LUMINANCE & CHROMINANCE BLOCK DIAGRAM VIDEO MAIN SIGNAL PATH IN REC MODE VIDEO MAIN SIGNAL PATH IN PLAYBACK MODE Q7601 FROM TUNER IC6001 IC3001 (AUDIO/VIDEO SIGNAL PROCESSOR)

  • Page 60: Audio Block Diagram

    All manuals and user guides at all-guides.com NV-VP60GL / NV-VP60GC / NV-VP60GCS 15.4. AUDIO BLOCK DIAGRAM MAIN SIGNAL PATH IN REC MODE MAIN SIGNAL PATH IN PLAYBACK MODE AV2 IN IC4501 JK4801 (FRONT JACK) PP4802 PS33001 FRONT AUDIO (R) TL4501...

  • Page 61: Dvd Interface Block Diagram

    All manuals and user guides at all-guides.com NV-VP60GL / NV-VP60GC / NV-VP60GCS 15.5. DVD INTERFACE BLOCK DIAGRAM VCR VIDEO MAIN SIGNAL PATH IN REC MODE DVD VIDEO MAIN SIGNAL PATH IN PLAYBACK MODE VCR AUDIO MAIN SIGNAL PATH IN REC MODE...

  • Page 62: Dvd (Servo) Block Diagram

    All manuals and user guides at all-guides.com NV-VP60GL / NV-VP60GC / NV-VP60GCS 15.6. DVD (SERVO) BLOCK DIAGRAM RF SIGNAL MOTOR DRIVE SIGNAL TRACKING ERROR SIGNAL FOCUS ERROR SIGNAL IC8001 IC8251 OPTICAL PICK UP UNIT (DV LSI) (MOTOR DRIVE) TRAY DRV...

  • Page 63: Dvd (Video/Audio) Block Diagram

    All manuals and user guides at all-guides.com NV-VP60GL / NV-VP60GC / NV-VP60GCS 15.7. DVD (VIDEO/AUDIO) BLOCK DIAGRAM RF SIGNAL PATH VIDEO MAIN SIGNAL PATH IC8001 IC8420 (DV LSI) (AUDIO D/A CONVERTER) AUDIO MAIN SIGNAL PATH VOUTL AUDIO(L) P8003 P34301 SRCK...
  • Page 64 All manuals and user guides at all-guides.com NV-VP60GL / NV-VP60GC / NV-VP60GCS...

  • Page 65: Schematic Diagrams

    All manuals and user guides at all-guides.com NV-VP60GL / NV-VP60GC / NV-VP60GCS 16 SCHEMATIC DIAGRAMS 16.1. POWER SCHEMATIC DIAGRAM C1122 T1150 100P ETS29AK7W6AC IP1280 TL1008 K5G102A00039 D1280 B0JAME000025 P1101 D1140 K2AA2B000009 B0KB00000054 C1280 R1280 LB1216 10V220 5600 L1120 ELF18N005A D1240...

  • Page 66: Power Supply/Rf Section In Main Schematic Diagram

    All manuals and user guides at all-guides.com NV-VP60GL / NV-VP60GC / NV-VP60GCS 16.2. POWER SUPPLY/RF SECTION IN MAIN SCHEMATIC DIAGRAM :TO TIMER SECTION VIDEO MAIN SIGNAL PATH IN REC MODE AUDIO MAIN SIGNAL PATH IN REC MODE :TO SYSTEM CONTROL & SERVO SECTION...

  • Page 67: Timer Section In Main Schematic Diagram

    All manuals and user guides at all-guides.com NV-VP60GL / NV-VP60GC / NV-VP60GCS 16.3. TIMER SECTION IN MAIN SCHEMATIC DIAGRAM DP37501 :TO POWER SUPPLY/RF SECTION B3CZS0000004 (TIMER LED DISPLAY) :TO SYSTEM CONTROL & SERVO SECTION :TO DVD INTERFACE SECTION D IN...

  • Page 68: System Control & Servo Section In Main Schematic Diagram

    All manuals and user guides at all-guides.com NV-VP60GL / NV-VP60GC / NV-VP60GCS 16.4. SYSTEM CONTROL & SERVO SECTION IN MAIN SCHEMATIC DIAGRAM CAPSTAN SERVO SPEED LOOP CAPSTAN SERVO PHASE LOOP CYLINDER SERVO SPEED LOOP CYLINDER SERVO PHASE LOOP :TO POWER SUPPLY/RF SECTION :TO TIMER SECTION :TO LUMINANCE &...
  • Page 69 All manuals and user guides at all-guides.com NV-VP60GL / NV-VP60GC / NV-VP60GCS VIDEO 5V SW 36V R2519 8200 C2520 D2503 MAZ4160NMF P1531 (TO LOADING MOTOR) LOAD MOTOR (-) LOAD MOTOR (+) IC6301 C2507 C2515 C2505 C2504 C2506 R6401 R6400 C2519...

  • Page 70: Luminance & Chrominance/Audio Section In Main Schematic Diagram

    All manuals and user guides at all-guides.com NV-VP60GL / NV-VP60GC / NV-VP60GCS 16.5. LUMINANCE & CHROMINANCE/AUDIO SECTION IN MAIN SCHEMATIC DIAGRAM VIDEO MAIN SIGNAL PATH IN REC MODE VIDEO MAIN SIGNAL PATH IN PLAYBACK MODE AUDIO MAIN SIGNAL PATH IN REC MODE...
  • Page 71 All manuals and user guides at all-guides.com NV-VP60GL / NV-VP60GC / NV-VP60GCS C3041 R3013 C3040 C3038 R3012 C3037 L3004 0.022 0.47 4700P 50V2.2 C3039 C3034 0.033 X3002 X3001 H0D443400039 H0D357400067 C3036 C3035 C3033 C3030 R3011 C3029 L3303 50V3.3 0.01 3300 0.01...

  • Page 72: Hi-Fi Audio Section In Main Schematic Diagram

    All manuals and user guides at all-guides.com NV-VP60GL / NV-VP60GC / NV-VP60GCS 16.6. Hi-Fi AUDIO SECTION IN MAIN SCHEMATIC DIAGRAM AUDIO MAIN SIGNAL PATH IN REC MODE AUDIO MAIN SIGNAL PATH IN PLAYBACK MODE :TO POWER SUPPLY/RF SECTION :TO SYSTEM CONTROL & SERVO SECTION :TO LUMINANCE &...

  • Page 73: Decorder Section In Main Schematic Diagram (Nv-Vp60Gl)

    All manuals and user guides at all-guides.com NV-VP60GL / NV-VP60GC / NV-VP60GCS 16.7. DECORDER SECTION IN MAIN SCHEMATIC DIAGRAM (NV-VP60GL) :TO POWER SUPPLY/RF SECTION AUDIO SIGNAL PATH :TO SYSTEM CONTROL & SERVO SECTION :TO LUMINANCE & CHROMINANCE/AUDIO SECTION :TO Hi-Fi AUDIO SECTION...

  • Page 74: Dvd Interface Section In Main Schematic Diagram

    All manuals and user guides at all-guides.com NV-VP60GL / NV-VP60GC / NV-VP60GCS 16.8. DVD INTERFACE SECTION IN MAIN SCHEMATIC DIAGRAM :TO POWER SUPPLY/RF SECTION VCR VIDEO MAIN SIGNAL PATH IN REC MODE DVD VIDEO MAIN SIGNAL PATH IN PLAYBACK MODE...

  • Page 75: Front Sw Schematic Diagram

    All manuals and user guides at all-guides.com NV-VP60GL / NV-VP60GC / NV-VP60GCS 16.9. FRONT SW SCHEMATIC DIAGRAM OPEN/CLOSE S7585 EVQ11L07B DVD-RAM COPYING D.STOP D.PLAY AV ENHANCER S7581 S7582 S7583 S7584 EVQ11L07B EVQ11L07B EVQ11L07B EVQ11L07B PP7581 R7582 R7583 R7581 KEY 3...

  • Page 76: Dvd Module Schematic Diagram

    All manuals and user guides at all-guides.com NV-VP60GL / NV-VP60GC / NV-VP60GCS 16.11. DVD MODULE SCHEMATIC DIAGRAM LB8530 R8219 R8220 J0JHC0000045 7500 7500 LB8011 C8271 0.1 C8270 0.1 J0JHC0000045 C8530 RX8531 56x2 LB8001 C8001 C8011 J0JHC0000045 6V100 6V100 C8532 220P...
  • Page 77 All manuals and user guides at all-guides.com NV-VP60GL / NV-VP60GC / NV-VP60GCS EXADR16 RX8011 RX8019 82x4 22x2 CL8654 CL8651 MDQ15 DQM0 MDQ0 DQM1 CL8653 MDQ14 MDQ1 RX8018 22x2 C8651 NCAS NRAS RX8012 82x4 MDQ13 RX8020 MDQ2 22x2 MDQ12 MDQ3 RX8015...
  • Page 78 All manuals and user guides at all-guides.com NV-VP60GL / NV-VP60GC / NV-VP60GCS RF SIGNAL PATH VIDEO MAIN SIGNAL PATH AUDIO MAIN SIGNAL PATH R8013 R8012 MOTOR DRIVE SIGNAL PATH TRACKING ERROR SIGNAL PATH C8014 C8015 FOCUS ERROR SIGNAL PATH C8004...

  • Page 79: Motor Schematic Diagram

    All manuals and user guides at all-guides.com NV-VP60GL / NV-VP60GC / NV-VP60GCS 16.12. MOTOR SCHEMATIC DIAGRAM TRAVERS SPINDLE TRAVERS INNER MOTOR MOTOR SW2601 M2601 M2602 K0L1BB000026 TC2603 TC2604 TC2605 C2601 C2602 FP2601 TRV INNER SW GND (FG) SPD MOTOR (-)
  • Page 80 All manuals and user guides at all-guides.com NV-VP60GL / NV-VP60GC / NV-VP60GCS...

  • Page 81: Circuit Board Assemblies

    All manuals and user guides at all-guides.com NV-VP60GL / NV-VP60GC / NV-VP60GCS 17 CIRCUIT BOARD ASSEMBLIES 17.1. POWER C.B.A. (VEPV0049A) IMPORTANT SAFETY NOTICE: COMPONENTS IDENTIFIED WITH THE MARK HAVE THE SPECIAL CHARACTERISTICS FOR SAFETY. WHEN REPLACING ANY OF THESE COMPONENTS, USE ONLY THE SAME TYPE.

  • Page 82: Main C.b.a

    All manuals and user guides at all-guides.com NV-VP60GL / NV-VP60GC / NV-VP60GCS 17.2. MAIN C.B.A. (VEPV0069A: NV-VP60GL)(VEPV0069C: NV-VP60GC)(VEPV0069D: NV-VP60GCS) IC33501 IC2501 IC4501 IC3001 IC6301 IC6001 (GCS/GL) (GL) (GL) (GL) (GL) (GL) IC34301 (GL) IC1290 (GL) (GL) IC7301 (GL) (GL) IC1511...
  • Page 83 All manuals and user guides at all-guides.com NV-VP60GL / NV-VP60GC / NV-VP60GCS IMPORTANT SAFETY NOTICE: COMPONENTS IDENTIFIED WITH THE MARK HAVE THE SPECIAL CHARACTERISTICS FOR SAFETY. WHEN REPLACING ANY OF THESE COMPONENTS, USE ONLY THE SAME TYPE. MAIN C.B.A. Transistor...

  • Page 84: Front Sw C.b.a

    All manuals and user guides at all-guides.com NV-VP60GL / NV-VP60GC / NV-VP60GCS 17.3. FRONT SW C.B.A. (VEPV0059A) FRONT SW C.B.A. Connector PP7581 ADDRESS INFORMATION NV-VP60GL/GC/GCS FRONT SW C.B.A. 17.4. FRONT JACK C.B.A. (VEPV0050A) FRONT JACK C.B.A. Connector PP4802 ADDRESS INFORMATION NV-VP60GL/GC/GCS FRONT JACK C.B.A.

  • Page 85: Dvd Module C.b.a

    All manuals and user guides at all-guides.com NV-VP60GL / NV-VP60GC / NV-VP60GCS 17.5. DVD MODULE C.B.A. (REPV0084B: NV-VP60GL/GC)(REPV0084C: NV-VP60GCS) IC8611 IC8606 IC8651 IC8001 IC8251 IC8051 IC8420 (FOIL SIDE) (COMPONENT SIDE) NV-VP60GL/GC/GCS DVD MODULE C.B.A.

  • Page 86: Motor C.b.a

    All manuals and user guides at all-guides.com NV-VP60GL / NV-VP60GC / NV-VP60GCS 17.6. MOTOR C.B.A. DVD MODULE C.B.A. Transistor Test Point Q8551 CL8511 Q8552 CL8512 Q8561 CL8551 Q8562 CL8554 CL8561 Transistor & Resistor CL8611 QR8420 CL8612 QR8571 CL8651 CL8652 Integrated Circuit...

  • Page 87: Exploded Views

    NV-VP60GL / NV-VP60GC / NV-VP60GCS All manuals and user guides at all-guides.com 18 EXPLODED VIEWS 18.1. VCR MECHANISM CHASSIS PARTS SECTION...

  • Page 88: Dvd Mechanism Chassis Parts Section

    NV-VP60GL / NV-VP60GC / NV-VP60GCS All manuals and user guides at all-guides.com 18.2. DVD MECHANISM CHASSIS PARTS SECTION...

  • Page 89: Casing Parts Section

    NV-VP60GL / NV-VP60GC / NV-VP60GCS All manuals and user guides at all-guides.com 18.3. CASING PARTS SECTION...

  • Page 90: Packing Parts Section

    NV-VP60GL / NV-VP60GC / NV-VP60GCS All manuals and user guides at all-guides.com 18.4. PACKING PARTS SECTION...

  • Page 91: Replacement Parts List

    NV-VP60GL / NV-VP60GC / NV-VP60GCS All manuals and user guides at all-guides.com 19 REPLACEMENT PARTS LIST 19.1. VCR MECHANISM CHASSIS Ref. Part No. Part Name & Description Remarks PARTS SECTION PARTS LIST VHD1117 SCREW VHD1117 SCREW Note: VHD1117 SCREW *All parts except parts mentioned [PAVC-CSG] in the...

  • Page 92: Casing Parts Section Parts List

    NV-VP60GL / NV-VP60GC / NV-VP60GCS All manuals and user guides at all-guides.com Ref. Part No. Part Name & Description Remarks 19.3. CASING PARTS SECTION PARTS LIST B234 RHD26045 SCREW B235 RHD26045 SCREW B236 RHD26045 SCREW Note: *All parts except parts mentioned [PAVC-CSG] in the Remarks column are supplied by PAVCSG.

  • Page 93: Electrical Parts List

    NV-VP60GL / NV-VP60GC / NV-VP60GCS All manuals and user guides at all-guides.com Ref. Part No. Part Name & Description Remarks 19.5. ELECTRICAL PARTS LIST C2501 F1H1C104A008 CHIP CAPASITOR Note1: C2502 ECEA0JKA221B ELECTROLYTIC CAPACITOR C2504 F1H1E223A002 CHIP CAPACITOR All parts except parts mentioned [PAVC-CSG] in the...
  • Page 94 NV-VP60GL / NV-VP60GC / NV-VP60GCS All manuals and user guides at all-guides.com Ref. Part No. Part Name & Description Remarks Ref. Part No. Part Name & Description Remarks C33507 F1H0J1050010 CHIP CAPACITOR C4512 ECJ1VB1A224K CHIP CAPACITOR C33508 F1H0J1050010 CHIP CAPACITOR...
  • Page 95 NV-VP60GL / NV-VP60GC / NV-VP60GCS All manuals and user guides at all-guides.com Ref. Part No. Part Name & Description Remarks Ref. Part No. Part Name & Description Remarks C7321 ECJ1VB1H152K CHIP CAPACITOR IC7552 PNA4618M09VT IR RECEIVER C7324 F1H1H103A219 CHIP CAPACITOR...
  • Page 96 NV-VP60GL / NV-VP60GC / NV-VP60GCS All manuals and user guides at all-guides.com Ref. Part No. Part Name & Description Remarks Ref. Part No. Part Name & Description Remarks R2520 D0GB183JA007 CHIP RESISTOR Q1240 B1BCCG000002 TRANSISTOR R2521 D0GB102JA007 SMT CHIP RESISTOR...
  • Page 97 NV-VP60GL / NV-VP60GC / NV-VP60GCS All manuals and user guides at all-guides.com Ref. Part No. Part Name & Description Remarks Ref. Part No. Part Name & Description Remarks R36059 D0GB103JA007 SMT CHIP RESISTOR R6005 D0GB103JA007 SMT CHIP RESISTOR R36061 D0GB153JA007...
  • Page 98 NV-VP60GL / NV-VP60GC / NV-VP60GCS All manuals and user guides at all-guides.com Ref. Part No. Part Name & Description Remarks Ref. Part No. Part Name & Description Remarks W700 ERJ3GEY0R00V CHIP JUMPER W701 ERJ3GEY0R00V CHIP JUMPER C1105 F1B3A471A009 CERAMIC CAPACITOR...
  • Page 99 NV-VP60GL / NV-VP60GC / NV-VP60GCS All manuals and user guides at all-guides.com Ref. Part No. Part Name & Description Remarks Ref. Part No. Part Name & Description Remarks R1207 ERJ6GEYG123V CHIP RESISTOR C8007 ECJ0EF1C104Z CHIP CAPACITOR R1208 ERJ6GEYG154V CHIP RESISTOR...
  • Page 100 NV-VP60GL / NV-VP60GC / NV-VP60GCS All manuals and user guides at all-guides.com Ref. Part No. Part Name & Description Remarks Ref. Part No. Part Name & Description Remarks C8521 F1G1A1040006 CHIP ERAMIC CAPACITOR LB8306 J0JBC0000014 CHIP COIL C8522 F1G1A1040006 CHIP ERAMIC CAPACITOR...
  • Page 101 NV-VP60GL / NV-VP60GC / NV-VP60GCS All manuals and user guides at all-guides.com Ref. Part No. Part Name & Description Remarks R8421 ERJ2GE0R00X CHIP JUMPER R8531 ERJ2GEJ152X CHIP RESISTOR R8532 ERJ2GEJ222X CHIP RESISTOR R8533 ERJ2GE0R00X CHIP JUMPER R8541 ERJ2GEJ153X CHIP RESISTOR...
