Boyard KR322 Assembly Instructions

MAX pullout waste basket assembly instructions
KR32/2/3/350
designed for setting into the box by means of KRK06 front wall holder plates (optional)
KR32/2/3/350 COMPONENT PARTS
Picture Code
Name
Basket
A
B
Plastic buckets
C
Self-tapping screws, ST4×16
Guide rails
D
Holder plates of KRK06 front wall are bought separately
Decorative plug
E
Lower holder plates
F
of front wall
Upper holder plates
G
of front wall
Screw, M5×7 H
Screw, M5×6
Self-tapping screws,
J
ST4×16
Master plate of guide rail
K
Master plate of front
L
wall holder plates
350/400
290
290
347/397
1
Attach the lower holder plates of front wall F to the basket frame A with the help of screws H.
Quantity
2
Attach the upper holder plates of front wall G to the basket frame A with the help of screws I.
1 pc
2 pcs
8 pcs
F
1 set
1 set
1 set
1 set
6 pcs
Attach the lower holder plates of front wall F
to the basket frame A with the help of screws H
I
2 pcs
H
8 pcs
1 pc
4
Mark out and then set the removable parts of front wall holder plates F and G
with the help of self-tapping screws J. It is possible to use the master plate (L)
1 pc
for application of markings.
5
Attach the front wall to the basket adjusting its proper position and fix it on each
holder plate with the help of screws.
Loosen the adjusting and demount the removable part of front wall holder plates before mounting on front wall
Front wall
inclination adjustment
Loosen the adjusting screws and then carry out the wall adjustment while solving the cam mechanism
3
Mark out and then assemble the guide rails D
on the box bottom with the help of self-tapping
screws C. It is possible to use the master plate
(K) for application of markings. Insert the basket
A A into the guide rails D until the specific clips click
is heard.
G
I
D
6 If the final adjustments are carried out, insert the decorative
plugs E into the lower holder plates of front wall and place the
plastic buckets B in the basket.
B
E
350/400
C
196
279
