FURUNO
This equipment is used for distribution of navaids data from navigation equipment. It provides
six outputs each from two independent inputs. Alarm signal is also available to distribute three
outputs from two independent inputs.
1.
Port
2.
Alarm signal
3.
Rated voltage/Current
4.
Coating Color
5.
Ambient Temperature
6.
Relative Humidity
7.
Water proofing
SPECIFICATIONS OF INTERFACE UNIT
Input: 2 ports (IEC61162-1)
Output: 6 ports (IEC61162-1 or Current loop)
Alarm signal Output: 3 ports (Relay contact)
Receiving Error Alarm, Cross Track Error Alarm, Arrival Alarm
12-24 VDC: 0.16-0.08 A
2.5GY 5/1.5 Newtone No.5
-15 to 55℃
95%RH(40℃)
IPX0
IF-2500
SP-1
E4408S01C
