Overview

The interface for the dual GPS navigator receives data from two GPS navigators and chooses
one to output in accordance with priority order. Output data is converted to NMEA current loop,
IEC 61162-1 or contact signal and output.
12-24 VDC
Outputs data in accordance
with priority order
Input 1
(GPS navigator)
Input 2
(GPS navigator)
Output 1
Output 2
Output 3
Output 4
Output 5
Output 6
Receiving Error Alarm
Cross Track Error Alarm
Arrival Alarm
1
