- Page 1 IN00352(rev A) Curved Bath Screen • Instruction suitable for both Right and Left Hand fi xing variations.
- Page 2 Before You Start • Check that the bath has been installed correctly and that it is level (Fig. A), tiled down onto and Fig.A. sealed to the manufacturerʼs guidelines. Please Note: All product supplied without bath. • Check that there is suffi cient space on the bath for the product and that the screen movement does not foul other items such as sinks and taps.
- Page 3 Parts & Fittings Supplied Please notify the retailer immediately Keep small parts away from children of any damage or faults. The manufacturer cannot be held responsible for any installation costs that may arise from a damaged or faulty product being installed. Curved Glass Panel Horizontal Seal...
- Page 4 Wall Channel Wall Channel Loose Screws & Fittings Supplied No.7 x 1½” Pan Head Screws (actual size) Wall Plugs (actual size) No.7 x ½” CSK Screws (actual size) Screw Snap Cap (actual size)
-
Page 5: Important Note
Ensure Glass Fig. B Plan View Screen is level Mark Wall Channel position IMPORTANT NOTE: Ensure radius of Bath Screen matches Bath, (refer to Fig. B for details). DO NOT push Bath Screen fully into Wall Channel to ensure adjustment when fi... - Page 6 Tip: To push fi t Horizontal Seal, start in the corner and work the seal across the Curved Glass Panel. INSIDE OF BATH OUTSIDE OF BATH Please Note: Ensure Horizontal Seal is positioned with the ʻEdge Bladeʼ on the inside face of the bath. IMPORTANT NOTE: Ensure radius of Bath Screen matches Bath, (refer to Fig.
- Page 7 Inside View Inside View *3mm dia. holes through pre-drilled holes using HSS drill bit. 5.1* Ensure Bath Screen is level prior to fi xing, adjust to suit. Push fi t Wall Channel Cap into position. Take Care not to let Wall Channel Cap slip down the Wall Channel.
- Page 8 Inside View Apply Silicone Sealant, (not supplied). Product Care: Use a non abrasive cleaner. Water marks may be removed with a proprietary limescale remover or household vinegar. Apply Silicone Sealant, (not supplied). 150mm...
