  • Page 1 USER MANUAL Document Number: PD196-426R1 PD295-004 BELLA-HD Set Top Box ™ Interface Module mymedTV.com...
  • Page 2: Table Of Contents

    Appendix C - Factory Defaults ..............25 STB Link ......................14 Limited Warranty ................... 27 TV COM ......................14 LINK ......................... 14 www.PDiarm.com www.mymedTV.com PDi Communication Systems, Inc. ▪ 40 Greenwood Ln ▪ Springboro, Ohio 45066 USA ▪ ▪ Phone 800.628.9870...
  • Page 3: Cautions And Warnings

    PDi Communication Systems, Inc. ▪ 40 Greenwood Ln ▪ Springboro, Ohio 45066 USA ▪ ▪ Phone 800.628.9870...
  • Page 4: Important Safety Instructions

    PDi Communication Systems, Inc. ▪ 40 Greenwood Ln ▪ Springboro, Ohio 45066 USA ▪ ▪ Phone 800.628.9870...
  • Page 5: Introduction

    TV nearby will also change. The PDi Interface Module is designed to improve the patient experience interacting with a TV at a facility in which the channels come from a cable/satellite set-top-box. It allows direct access to all set-top-box functions via PDi TV keypad, IR remote, and pillow speaker.
  • Page 6: Connections

    When it is more desirable to have the set-top-box and interface module located near the TV, the module may be used in a stand-alone configuration without the need for a mini-mod chassis. In this case the PDi PD106-747 power adapter (not included) should be used to power the interface module.
  • Page 7 MODEL: Document Number: PDi BELLA-HD Interface PD196-426R1 User Manual Page 7 of 27 www.PDiarm.com www.mymedTV.com PDi Communication Systems, Inc. ▪ 40 Greenwood Ln ▪ Springboro, Ohio 45066 USA ▪ ▪ Phone 800.628.9870...
  • Page 8: Wall Mounted Tv - Rf Cable Installation

    Arm Mounted Televisions The PD295-004 interface module is also compatible with several of the PDi Arm Mounted televisions that incorporate a BELLA interface. Models such as the medTV and medTAB can be used successfully with the interface module when ordered with the BELLA option.
  • Page 9: Arm Mounted Tv - Rf Cable Installation

    Arm Mounted TV - RF Cable Installation Unlike AC powered wall mounted TV’s, PDi arm mounted television models receive their RF signal and TV power combined along a connecting coax cable from an external power source. Special consideration must be used in handling the low voltage AC power found on the RF signal coax cable.
  • Page 10 Central Style PDI -772HE Power Supply - RF Cable Installation Low voltage AC TV power is present on each central power supply TV coax cable. A PDi Power Passer (part number PD167-003) is required to route the AC power on the coax cable around any externally connected device such as the Satellite Box. A Power Passer is required for each TV/STB connection.
  • Page 11 Remove power from the TV at the central power supply. Connect a coaxial cable from the set-top-box “OUT TO TV” to one of the 10 “RF IN” ports on the PDI-772HE-IND. Connect the coaxial cable from the TV to “RF OUT”. The TV coax should be limited to 150’ to accommodate the central power supply coax length limitations.
  • Page 12: Tv Setup - Most Pdi Tvs

    Tuner” must be enabled. If the cable/satellite channels are delivered over an alternate method such as HDMI, then that source must be enabled. All unused sources should be disabled. www.PDiarm.com www.mymedTV.com PDi Communication Systems, Inc. ▪ 40 Greenwood Ln ▪ Springboro, Ohio 45066 USA ▪ ▪ Phone 800.628.9870...
  • Page 13: Tv Setup - A-Series

    Page 13 of 27 TV Setup – A-Series To establish communication to interface module the CCI port on the TV must be active and you must have a PDi programming remote PD108-420 (not included). From the TV, open the TV Setup Menu by pressing SETUP on the programming remote.
  • Page 14: Power

    1. No HDMI input from set-top-box. 2. No HDMI connection inside of TV. 1. Press RESET button on set-top-box. Wait 2 minutes for STB to reboot. www.PDiarm.com www.mymedTV.com PDi Communication Systems, Inc. ▪ 40 Greenwood Ln ▪ Springboro, Ohio 45066 USA ▪ ▪ Phone 800.628.9870...
  • Page 15: Interface Module Setup Menus

    NOTE: FAILURE TO EXIT the interface module setup menu by following this step 6 could result in patient access to interface module setup menus. www.PDiarm.com www.mymedTV.com PDi Communication Systems, Inc. ▪ 40 Greenwood Ln ▪ Springboro, Ohio 45066 USA ▪ ▪ Phone 800.628.9870...
  • Page 16: Menus 1 ~ 5

    Next Track Advance BLUE Recall/Star ( * ) Prev Channel Exit: Exit Back (Nav) Back Return: SETUP/OK/LAST Return: SETUP/OK/LAST Return: SETUP/OK/LAST www.PDiarm.com www.mymedTV.com PDi Communication Systems, Inc. ▪ 40 Greenwood Ln ▪ Springboro, Ohio 45066 USA ▪ ▪ Phone 800.628.9870...
  • Page 17: Menu 6

    Set “STB Model” to match the actual model of the STB. Perform a factory reset (See Restoring Factory Default Settings later in this manual). Return: SETUP/OK/LAST www.PDiarm.com www.mymedTV.com PDi Communication Systems, Inc. ▪ 40 Greenwood Ln ▪ Springboro, Ohio 45066 USA ▪ ▪ Phone 800.628.9870...
  • Page 18: Keypad Programming (Mapping) Instructions

    For each “TV Key” on the left column, set the matching “STB COMMAND” on the right column to the desired STB function. www.PDiarm.com www.mymedTV.com PDi Communication Systems, Inc. ▪ 40 Greenwood Ln ▪ Springboro, Ohio 45066 USA ▪ ▪ Phone 800.628.9870...
  • Page 19: Programming For Off-Air Non-Satellite Channels Using Off-Air Rf Pass-Thru

    STB’s channel as well. For example, if the STB is set for channel 3 output, the same channel could be omitted from the TV’s channel table, if no local channel 3 is available. Please see the programming instructions specific to the model PDi TV being used.
  • Page 20: Programming The Stb Signal Input Type

    Connected Return: SETUP/OK/LAST Operation PDi Interface Module operation is straight forward once configured. Site installations that involve a secondary “Off Air” signal require additional instruction to provide a worry-free patient viewing experience. Cable/Satellite TV Operation Turn the TV on. A channel from the set-top-box should be displayed.
  • Page 21: Off-Air Tv Operation (Optional)

    Check the wiring. The signal loop must be correct and complete. The CCI cable from the TV must connect to the Interface Module which is in turn connected by www.PDiarm.com www.mymedTV.com PDi Communication Systems, Inc. ▪ 40 Greenwood Ln ▪ Springboro, Ohio 45066 USA ▪ ▪ Phone 800.628.9870...
  • Page 22 Press RECORD on the Dish remote. The TV screen should update. Make sure the Primary Remote Address shown on the System Information screen is now '1'. Press SELECT to remove the System Information screen. www.PDiarm.com www.mymedTV.com PDi Communication Systems, Inc. ▪ 40 Greenwood Ln ▪ Springboro, Ohio 45066 USA ▪ ▪ Phone 800.628.9870...
  • Page 23: Appendix A - Control Device (Tv) Key Reference

    Please refer to sections “TV Setup” and “Understanding Interface Module Setup Menus” for programming details. NOTE: A “Control Device Key” (also referenced as a ‘TV Key’) is a key located on the front panel of a PDi TV and/or on a PDi TV compatible controller (IR remote control, pillow speaker, or wireless control device).
  • Page 24: Appendix B - Stb Command Reference

    Fast Forward Fast Forward Fast Forward Fast Forward ON DEMAND ON DEMAND ON DEMAND ON DEMAND ON DEMAND Skip Fwd Skip Fwd www.PDiarm.com www.mymedTV.com PDi Communication Systems, Inc. ▪ 40 Greenwood Ln ▪ Springboro, Ohio 45066 USA ▪ ▪ Phone 800.628.9870...
  • Page 25: Appendix C - Factory Defaults

    Pause Pause Pause Pause Stop Stop Stop Stop Stop Stop Stop Eject Record Rewind Rewind Rewind Rewind Back Rewind Rewind Rewind www.PDiarm.com www.mymedTV.com PDi Communication Systems, Inc. ▪ 40 Greenwood Ln ▪ Springboro, Ohio 45066 USA ▪ ▪ Phone 800.628.9870...
  • Page 26 Legacy Cisco Stingray Mantaray DTA250 TV Input for Tuner Tuner Tuner Tuner Tuner Tuner Tuner Tuner TV Chan for Power Save www.PDiarm.com www.mymedTV.com PDi Communication Systems, Inc. ▪ 40 Greenwood Ln ▪ Springboro, Ohio 45066 USA ▪ ▪ Phone 800.628.9870...
  • Page 27: Limited Warranty

    PDi Communication Systems Inc., (“PDi”) standard warranty information is found at PDiarm.com. For information regarding authorized servicing and all other information pertaining to this warranty, please contact PDi COMMUNICATION SYSTEMS, INC. at 40 Greenwood Ln, Springboro, Ohio 45066 or phone 800-628-9870 and ask for the PDi ProServices team.
