Frigidaire 2020266A0107 Use And Care Manual

Frigidaire dehumidifier use & care guide.
Hide thumbs


Advertisement

All about the
Use &Care
of your
Important Safety Instructions ............................... 2
..............................................................
.......................................................
Operating Instructions ..........................................
www.frigidaire.com USA 1-800-944-9044
Dehumidifier
TA B L E O F C O N T E N T S
2
2
3-7
www.frigidaire.ca Canada 1-800-265-8352
Care And Cleaning .............................................. 8
Storage .............................................................
Before You Call ................................................... 9
Major Appliance Warranty ................................... 10
8

Advertisement

   Related Manuals for Frigidaire 2020266A0107

   Summary of Contents for Frigidaire 2020266A0107

  • Page 1: Table Of Contents

    Important Safety Instructions ... 2 Location How It Works Operating Instructions ... www.frigidaire.com USA 1-800-944-9044 TA B L E O F C O N T E N T S Care And Cleaning ... 8 Storage ... Before You Call ... 9 Major Appliance Warranty ...

  • Page 2: Important Safety Instructions

    4. The dehumidifier must be installed on a level floor that will support it with a full bucket of water. 5. There should be a minimum of 12 inches clearance around the dehumidifier.

  • Page 3: Operating Instructions

    Operating Instructions Allow the unit to reach room temperature before operating. To begin operating the dehumidifier, follow these steps: NOTE: Unit must be upright for one hour prior to operating. 1. Plug the power cord into a properly grounded 115 volt AC outlet. The POWER indicators will illuminate.

  • Page 4

    Operating Instructions Operating Instructions (continued) 3. After a few days when the Relative Humidity has declined, press the HUMIDITY between 35% to 85%, so the room is kept at a comfortable concentration. Pressing the change the humidity selection in 5% increments. After you have set the desired humidity, the readout will display the actual room humidity.

  • Page 5

    Operating Instructions (continued) 6. The TIMER function enables you to either Delay Start or Delay Stop the unit in the choice from 0.5 hour to 24 hours. If the unit is running then selecting Timer will turn the unit off after setting hours (Delay Stop). If the unit is off then selecting Timer will turn the unit on after setting hours (Delay Start).

  • Page 6: Fault Codes

    Operating Instructions Fault Codes 1. If the display reads "AS" or "ES" , a sensor has failed. Contact your Authorized Frigidaire Service Center. Removing Collected Water 1. Emptying the Bucket: a. When the bucket is full the unit will shut down and the BUCKET FULL indicator light will illuminate.

  • Page 7: Operating Instructions

    Removing Collected Water (continued) If the bucket full light does not extinguish, check that the float is correctly snapped in place as indicated by the diagram. 2. Continuous Drainage: a. For constant drainage operation, you will need a garden hose and a drain nearby to discharge the water into. b.

  • Page 8: Care And Cleaning

    Care And Cleaning & Storage Care And Cleaning 1. Filter a. Remove the filter every two weeks based on normal operating conditions. b. To remove the filter, remove Bucket then pull filter downwards. c. Wash the filter with clean water then dry. d.

  • Page 9: Before You Call

    Dehumidifier has been installed or restarted recently. The higher the moistuire in the room, the longer the dehumidifier will operate. Dehumidifier is in the CONT mode and will remain on in this mode use the humidity button or knob to set a RH% higher level.

  • Page 10: Major Appliance Warranty

    Major Appliance Warranty Your appliance is covered by a full one-year warranty and a limited 2-5 year warranty(sealed system). For one year from your original date of purchase, Electrolux will pay all costs for repairing or replacing any parts of this appliance that prove to be defective in materials or workmanship when such appliance is installed, used and maintained in accordance with the provided instructions.

This manual also for:

Fad504tdd, Fad704tdp, Cad251ntd
