ISINK0/1 provide a constant infrared emission current, A0PI and A0NI process the infrared
received signal
ISINK0/1 constant current output is adjustable
Two sets of ISINK for use by different types of smoke – white/black smoke
RF circuit includes the antenna and input/output matching circuit
Time-division duplex (TDD) method must be used for RF signal transmission and reception -
only transmission or reception can be performed at a time
RF transmission
Digital packet regulator → Gaussian filter → ΣΔ Modulator → Frequency synthesis → High
power amplifier → Antenna
RF reception
Antenna → Low noise amplifier → Intermediate frequency(IF) → Intermediate frequency
composite band-pass filter → Signal strength detector → Digital packet demodulator
Operating Principles
Communication Pin Description
AN0571EN V1.00
BA45F56xx Wireless Transceiver Application
46
45
44
43
42
41
40
39
1
NC
2
CLDO
3
GIO4
NC
4
BA45F5640
5
BA45V5640
NC
46 QFN-A
V_LNA
6
7
RFIN
RFOUT
8
VSSRF
9
10 11 12 13 1415 161718 19 20 21 22
Figure 2. BA45F5640 Pin Assignment
2 / 14
38
37
36
35
34
33
32
VSS
31
VSS
30
VDD
NC
29
28
NC
27
A0NI
26
A0PI
25
PB0/INT0/SCS/STP/A0PB
24
PA5/STCK/A1O
23
November 5, 2020
